Item # 000 000
Model # FRS60490
USE AND CARE GUIDE
BROADVIEW CLUB CHAIR-2PK
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY FRS60490
Summary of Contents for HAMPTON BAY FRS60490
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Package Contents ..............4 Safety Warnings ..............2 Assembly ............... 5 Warranty ................ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Right arm Left arm Backrest Seat Back cushion Seat cushion Pillow... -
Page 5: Assembly
Assembly Attaching the right arm to the backrest Attach the right arm (A) to the backrest (C) using M6x20 bolts (AA) and M6 washers (DD) as shown below. NOTE : Loosely tighten all bolts using the hex wrench (EE). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly (continued) Attaching the left arm to the backrest Attach the left arm (B) to the backrest (C) using M6x20 bolts (AA) and M6 washers (DD) as shown below. NOTE : Loosely tighten all bolts using the hex wrench (EE).
- Page 7 Assembly (continued) Attaching the seat to the backrest and the chair arms Attach the seat (D) to the backrest (C) using M6x35 bolts (CC) and M6 washers (DD). Attach the seat (D) to the right arm (A) and left arm (B) using M6x30 bolts (BB) and M6 washers (DD). NOTE : Loosely tighten all bolts using the hex wrench (EE).
-
Page 8: Care And Cleaning
Assembly (continued) Completing the assembly Once all bolts are in place, fully tighten all bolts. Turn the chair right side up. Ensure all connections are secure before use. Place the back cushion (E), the seat cushion (F) and the pillow (G) to nish the assembly of the chair. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
