Contents Contents Chapter 1: About This Guide................. 1 Chapter 2: Package Content................2 Chapter 3: Access Point Overview............... 4 3.1 Front Panel............................4 3.2 Side Panel - Left..........................5 3.3 Bottom Panel............................. 7 Chapter 4: Installing the Access Point............9 4.1 Pole Mount the AP..........................
To receive important news on product updates, please visit our website at Arista Product Documentation. We continuously enhance our product documentation based on customer feedback FCC Advisory The FCC prohibits the use of the O-435 for control of or communications with unmanned aircraft systems, including drones.
Chapter 2 Package Content Note: The AP needs to be installed by a Certified Professional Installer. The access point (AP) package contains the components shown in the following figure: Figure 2-1: Package Components...
Page 7
Important: Locate the MAC address of the AP on a label at the bottom of the product and the packaging box. Note down the MAC address before mounting the AP on the ceiling or at a location difficult to access. If the package is not complete, please contact the Arista Networks Technical Support Team at support- campus@arista.com...
Chapter 3 Access Point Overview O-435 is a multi-radio 802.11be (Wi-Fi 7) access point. Refer the datasheet for more information. Note: This equipment is suitable for use in environment air spaces (plenums). This chapter provides an overview of the access point (AP) and describes: •...
Page 9
Access Point Overview Table 2: Labels: Front Panel LEDs Label Description Power 2.4 GHz Radio 5 GHz Radio 6 GHz Radio LAN1 PoE PD LAN2 PoE PSE (802.3af) Power LED: The following table describes the Power LED states. Table 3: Power LED States Description Green Solid Running at full capability...
Side Panel - Left The side panel of the AP has a reset pinhole and console port. Figure 3-2: Side Panel Table 4: Labels: Side Panel Label Description Reset Console Port Description Connector Type Speed/Protocol Console RJ-45 Establish ‘config shell’ •...
Access Point Overview • Erases the server discovery value and changes it to the default, redirector.online.spectraguard.net (primary) and wifi-security-server (secondary). • Lose all the VLAN configurations. • If the AP has a static IP, reset function erases the IP address and sets the AP to DHCP mode. The factory default IP address of the AP uses 169.254.11.74.
Page 12
Table 6: Port Details Connector Port Description Speed/Protocol Type LAN 1 5Gbps RJ-45 10M/100M/1000Mbps/2.5G/5Gbps Ethernet Ethernet with 802.3bt compliant PoE PD. LAN 1 powers the AP. LAN 2 5Gbps RJ-45 10M/100M/1000Mbps/2.5G/5Gbps Ethernet Ethernet with 802.3af compliant PoE PSE. LAN 2 is used to power other connected devices.
(TCP) bidirectional traffic on the firewall. This port number is assigned to Arista Networks. Zero- configuration does not support setting up multiple devices to connect to multiple servers. In this case, you must manually configure the APs. See the Access Point Configuration Guide on the Arista website at Arista Product Documentation.
Page 14
2. Fix the bracket to a pole. You can position the pole-mount bracket for use on a vertical or horizontal pole.
Page 15
Installing the Access Point 3. Fasten the two metal clamps into the slotted driver.
Page 17
Installing the Access Point 5. Tighten the thumb screw using Philips# 2 screwdriver. Table 7: Labels: Parts Label Description Use a Philips #2 screwdriver to fasten the screw.
Chapter 5 Power the Access Point On Plug one end of the Ethernet cable into the PoE++ switch or compatible PoE injector (a Single-port High Power Midspan, 802.3bt compliant, up to 5Gigabit PoE with PD54V in power output) and the other end into the LAN1 (PoE++) on the AP.
Figure 5-3: Lug Nut Dimensions Note: The O-435 APs are intended to be supplied with UL-listed PoE+ power source suitable for use at 65 degree Celsius, and whose output meets LPS requirements or PS2, with a rating of 54V DC (0.8A or 800mA minimum).
Page 20
Warning: Use the O-435 AP with a UL-listed PoE power source suitable for use at 45ºC. The power output should meet LPS requirements or PS2, with a rating of 48V DC (1A minimum). The current supplied by PoE+ + should be 850mA. If not using PoE++, be sure to use only an AC power adapter supported by the AP. The power adapter should be suitable for use at 45ºC.
5. Log on to the server using SSH and run the get sensor list command. The command returns a list of all Arista devices recognized by the server. Single Sign-On users can go to the Monitor tab in CloudVision Cognitive Unified Edge and check if the access point appears on the Monitor tab.
Content Filter between the AP and the Internet, ensure that the settings allow communication between the AP and Arista Cloud Services. • If your configuration requires you to specify an exact IP address or IP range for Arista Cloud Services, please contact support- campus@arista.com.
You must manually configure the new communication key on an AP if not connected to the server when the key changes on the server. Note: Arista Networks does not recommend installing older versions of APs on newer versions of servers.
