Installation, Start-Up, and
Operating Instructions
NOTE: Read the entire instruction manual before starting the
installation.
This symbol --->indicates a change since the last issue.
INDEX
Page
SAFETY CONSIDERATIONS ........................ 1
SYSTEM CONSIDERATIONS ........................ 1
INTRODUCTION .................................. 1
APPLICATION .................................... 2
DESCRIPTION OF OPERATION ...................... 2
INSTALLATION CONSIDERATIONS ................. 3
INSTALLATION ................................... 3
Thermostat Location ............................... 3
Set DIP Switches .................................. 4
Install Thermostat ................................. 4
Set Thermostat Configuration ........................ 5
Check Thermostat Operation ......................... 6
Final Settings .................................... 7
Checklist ........................................ 7
OPERATIONAL INFORMATION .................... 10
THERMOSTAT CONFIGURATION RECORD .......... 12
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical shock or
other conditions which may cause personal injury or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses and work gloves.
Have fire extinguisher available. Read these instructions
thoroughly and follow all warning or cautions attached to the
unit. Consult local building codes and National Electrical Code
(NEC) for special requirements.
It is important to recognize safety information. This is the
safety-alert symbol /_ . When you see this symbol on the unit
and in instructions or manuals, be alert to the potential for
personal injury. Understand the signal words DANGER,
WARNING, and CAUTION. These words are used with the
safety-alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or death.
WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe practices
which may result in personal injury or product and property
damage. NOTE is used to highlight suggestions which will result
in enhanced installation, reliability, or operation.
SYSTEM CONSIDERATIONS
The HybridHeat _' thermostat is designed to be used only in
HP/furnace installations. It replaces a conventional 2-stage HP
thermostat and an HP/furnace interface kit. An outdoor
temperature sensor, Part No. TSTATXXSEN01-B must be used
with this thermostat. It is supplied with the thermostat.
As an ENERGY STAR Pa_tnel, C;arfie_ Coq)o_ation has determined that this p_oduct meets the
ENERGY STAR glfidelines for energy efficiei_cy
f
O
A98426
Fig. 1 - Carrier ProgrammableThermostat
Height (In.) Width (In.) Depth (In.)
4-1/4 7-I/2 1-3/8
INTRODUCTION
Carrier's 7-day programmable HybridHeat _ thermostat is a wall
mounted, low voltage thermostat that provides proper control of a
heat pump (HP) and furnace combination without using an
HP/furnace interface kit. Separate heating and cooling set points.
plus auto changeover allow setback programming for maximum
energy savings. Up to 4 time/temperature settings per 24 hour
1
