- Page 1 TSTATCCEWF-01 Carrier Smart Thermostat Installation Instructions Designed in the USA. NOTE: Read the entire instruction manual before starting the installation. WARNING: Contains strong magnets; can be harmful to pacemaker wearers. Magnets are permanently installed; swallowing risk if removed.
-
Page 2: Table Of Contents
Safety Considerations ..................4 Introduction ...................... 5 How to Connect in 3 Easy Steps ..............5 Get to Know Your New Carrier Smart Thermostat .......... 6 Installation Considerations ................8 Installation ...................... 10 Thermostat Setup with the Service Technician App ........14 Manual Setup of Thermostat HVAC Configuration ........ -
Page 3: Safety Considerations
4 capacitive touch buttons to control temperature setpoints and may damage thermostat. heating/cooling/fan modes of operation from the thermostat. Homeowners can remotely, via the Carrier Home app, set temperature Recognize safety information. This is the safety-alert symbol . as well as set daily/weekly programmable schedules with 4 comfort When you see this symbol on the equipment and in the instruction profiles - home/sleep/wake/away. -
Page 4: Get To Know Your New Carrier Smart Thermostat
Get to Know Your SMART HOME READY. After Wi-Fi onboarding is complete via the Carrier Home Carrier Smart Thermostat app, you can use your desired smart home app to scan the Smart Home QR code on the back of the thermostat... -
Page 5: Installation Considerations
Installation Considerations Power Accessory Output and Connections This thermostat is powered by 24VAC only. It requires 24VAC This thermostat is equipped with a dry contact output for the (Rh and/or Rc and C terminals) of the low-voltage transformer to management of humidifiers, dehumidifiers and ventilation equipment. be connected to it for proper operation. -
Page 6: Installation
Installation Thermostat Location CAUTION Thermostat should be mounted: UNIT DAMAGE HAZARD Failure to follow the recommended wiring practices • Approximately 5 ft (1.5m) from floor. could result in damage to the wall control and personal • Close to or in a frequently used room, preferably on an inside property. -
Page 7: Install Thermostat
Install Thermostat 3. Route wires through large hole in the wall mount. Level wall mount WARNING against wall (for aesthetic value only—thermostat need not be ELECTRICAL OPERATION HAZARD leveled for proper operation) and Failure to follow this warning could result in personal injury mark wall through the two mounting or death. -
Page 8: Thermostat Setup With The Service Technician App
After making your selection, you will be asked if you want to 1. To begin setup of your smart provide contact information (email address) for the homeowner. thermostat, open the Carrier Service This will streamline the onboarding process for them through the Technician App on your phone. -
Page 9: Manual Setup Of Thermostat Hvac Configuration
Manual Setup of Thermostat HVAC Configuration on the Thermostat • 1 Heat 1 Cool (11) 1. HVAC configuration can be done via thermostat display. – If selected, you will be presented with additional choices a. Use the Mode button to go back. to include Fan. - Page 10 Manual Setup of Thermostat HVAC Configuration on the Thermostat (cont.) iii. Dual Fuel (L3). ii. Heat Pump (L2). Dual Fuel supports the following sub-system types: Heat Pump supports the following sub-system types: • 1 Stage HP, 1 Heat (11) • 1 Stage (10) –...
-
Page 11: System Start-Up And Checkout
Manual Setup of Thermostat HVAC Configuration on the end by selecting a new test (will start the new selected test), thermostat or via the Carrier Service Technician app. selecting stop testing, or 20 minute timeout. While testing the... -
Page 12: Operational Information
Operational Information Timers User Interface Five--Minute Compressor Timeguard The display is a dead front display. All digits, icons, and perimeter lighting will be off unless the proximity sensor is activated, a key This timer prevents compressor from starting unless it has been off is pressed by the user, or unless a heating or cooling call occurs. - Page 13 Operational Information Programmable Fan Heat/Cool Setpoints (Desired Temperature) The fan output can be programmed based on period of the day. A minimum difference of 3°F and maximum of 15°F is enforced When programming for each day and period the fan can be set to between heating and cooling desired temperatures.
-
Page 14: Troubleshooting
Troubleshooting If the display doesn’t power up after power is applied, check the Rc/Rh and C terminals for 24VAC. Reset There are 2 different resets available for the thermostat: • Factory reset will restore all settings and operation to original out of the box settings. -
Page 15: Equipment Configuration Outputs
Equipment Configuration Outputs HVAC Terminals (10) HVAC System \ Label Names Rc Rh C W1/A1 W2/O G Y1 Y2/A2 Standard 1C a. Rc – 24VAC Power (Cooling for two-transformer system) Standard 2C b. Rh – 24VAC Power (Heating for two-transformer system) Standard 1H c. -
Page 20: Compliance And Certification
Compliance and Certification UL Statement: FCC: • Purpose of control: Room Thermostat This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. • Pollution Degree 2 These limits are designed to provide reasonable protection against •... - Page 21 © 2024 Carrier. All rights reserved. Catalog No: TSTATCCEWF-01SI Edition Date: 04/24 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
