- Page 1 Desigo® Room Automation Room Pressure Indicator (RPI) Installation and User Guide RPI... A6V14811694_en--_a Smart Infrastructure 2024-04-01 Building Products...
- Page 2 Mounting Hardware ● Elbow Connectors ● 250ohm resistor (If wiring inputs for 4-20mA current loops) Dual Alert Unit (RPI.00-SD) ● LED alarm indicator 18” pigtail prewired ● Pressure Pickup Port ● Mounting Hardware ● Elbow Connectors Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 3 Dimensions Main Unit Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 4 4. If unit will not be installed directly into wall, a single-gang electrical box 5. If pressure tap plate will not be installed directly into the wall, additional single-gang electrical box per pressure tap plate Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 5 (typically a hallway). For the Inside Room ("IR" on the startup screen under the Siemens logo), the pressure tap plate should be installed in the reference area, and the base unit should be installed inside the primary monitored room. 1/8” ID soft platinum-cured silicon tubing is typically used to bring the pressure signal from the pressure tap plate to the pressure fitting on the back of main unit.
- Page 6 4. If using a Dual Alert, attach the LED cable connector to the port on the outside of the unit. Thread the LED cable through the wall and into the pressure pickup port box or hole on the opposite side of the wall. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 7 The unit contains a small air valve to allow for one-touch zeroing via the configuration menu. 8. Prior to installing the faceplate, be sure the rubber seal is properly installed on the back of the faceplate. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 8 10. After configuration is completed, align and engage the top two snaps. Then, align and install the front lens to the faceplate by inserting top snap first, followed by the bottom snap. Note: The left and right snaps will only attach to the unit if they are properly aligned. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 9 Pressure Tap Plate Installation Standard Siemens Pressure Plate (547-100) 1. Install onto the end of the 0.25” field tubing: (1) supplied silicone tube (with integrated external spring) and (2) attached barbed tube adapter on the rear face of the unit . This short length of tubing is used as a safety to prevent any kinking inside tight spaces.
- Page 10 3. Prior to installing the faceplate, be sure the rubber seal is properly installed on the back of the faceplate. 4. Thread the tubing and wire lead through the front cover and snap the front cover into place. Note: Press the plate in at a slight angle, leading with the bottom edge Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 11 7. Be careful not to kink the tubing or wire push the pressure pickup lens into the center of the front cover. This can cause the front cover to snap.. Ensure the Siemens logo on the front cover is properly oriented.
- Page 12 A 250 Ohm resistor is included for this output type in the event you need to convert to volts (1-5V). The AO generates a 0-5 VDC, 0-10 VDC, or 4-20 mA output signal, as configured. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 13 Press the LEFT button (↶) to navigate to the previous screen and eventually exit the configuration menu. To change a setting, navigate to the desired setting screen, and press and hold the RIGHT button(↷). The screen text should flash 3 times, indicating ability adjust the setting. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 14 Press and hold the RIGHT button (✓) to adjust the alarm door delay (i.e. number of seconds before the LED ring will turn red when pressure alarm limits are exceeded); the screen text will flash 3 times to indicate that the setting is ready to be adjusted. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 15 ("NO") or outside the room ("YES"). When finished, press the RIGHT button (✓) to save the setting. The screen text should flash 3 times to indicate that you have returned to the main configuration selection screens . Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 16 Use the LEFT (←) and MIDDLE (→) buttons to adjust between pascals ("Pa") and inches of water ("WC"). When finished, press the RIGHT button (✓) to save the setting. The screen text should flash 3 times to indicate return to the main configuration selection screens. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 17 RING menu. View Pressure Reading If the DISPLAY is set to "OFF", the LCD display will display the Siemens logo under normal operation. To see a digital pressure reading, simply press on the lens of the device.
- Page 18 In the event the RPI needs to be removed, first remove the front lens. To remove the front lends, grab the front lens from the left and right side edges, and pull the lens away from the wall. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 19 Be sure to include a brief description of the problem plus any relevant application notes. Contact customer service to receive a return goods authorization number before shipping. Smart Infrastructure A6V14811694_en--_a Siemens 2024-04-01...
- Page 20 Issued by © Siemens 2024 Siemens Industry, Inc. Technical specifications and availability subject to change without notice. Smart Infrastructure 1000 Deerfield Pkwy Buffalo Grove IL 60089 +1 847-215-1000 Document ID A6V14811694_en--_a Installation and User Guide Edition 2024-04-01...
