  • Page 1 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...
  • Page 2 • Setup Guide First Edition (March 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...

  • Page 3: Table Of Contents

    Storage drive bracket ... Lenovo Vantage....7 M.2 solid-state drive ...
  • Page 4 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 5: About This Documentation

    As a result, some information in this documentation might become outdated. Refer to Microsoft resources for the latest information. • This guide applies to the Lenovo product models listed below. Illustrations in this guide may look slightly different from your product model.
  • Page 6 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 7: Chapter 1. Meet Your Computer

    • Blinking: The computer is in sleep mode. Related topics • “Use the optical drive (for selected models)” on page 8. • “Use a media card (for selected models)” on page 9. • “USB specifications” on page 3. © Copyright Lenovo 2021...

  • Page 8: Rear

    Rear 2. PCI-Express card area 1. Ethernet connector 3. Padlock loop 4. Power cord connector 5. Security-lock slot 6. USB 2.0 connectors (4) 8. HDMI™ 2.0 connector (HDMI 1.4 connector for 7. VGA-out connector IdeaCentre 5 14ACN6) 9. Audio line-out connector Related topics •...

  • Page 9: Features And Specifications

    Features and specifications For detailed specifications of your computer, go to https://psref.lenovo.com 1. Right-click the Start button to open the Start context menu. Hardware configuration 2. Click Device Manager. Type the administrator password or provide confirmation if prompted. Power supply 260-watt automatic voltage-sensing power supply •...
  • Page 10 – USB-C to DP: 3840 x 2160 pixels, 60 Hz • Connect to USB-C accessories to help expand your • USB-C (3.2 Gen 1) connector computer functionality. To purchase USB-C accessories, go to https://www.lenovo.com/accessories • USB-C (3.2 Gen 2) connector • Thunderbolt 3 connector (USB-C) •...

  • Page 11: Chapter 2. Get Started With Your Computer

    Click the network icon in the Windows notification area, and then select a network for connection. Provide required information, if needed. Manage cables with a smart cable clip Note: You can purchase a smart cable clip from Lenovo. © Copyright Lenovo 2021...
  • Page 12 To manage cables of devices (such as the keyboard and the mouse) with a smart cable clip: 1. Pull the cables through the dents in the clip. 2. Install the clip as shown. IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 13: Chapter 3. Explore Your Computer

    Access Lenovo Vantage Open the Start menu and click Lenovo Vantage. You also can type Lenovo Vantage in the search box. To download the latest version of Lenovo Vantage, go to Microsoft Store and search by the app name.

  • Page 14: Set The Power Plan

    Set the power plan ® For ENERGY STAR compliant computers, the following power plan takes effect when your computers have been idle for a specified duration: • turn off the display: After 10 minutes • put the computer to sleep: After 25 minutes To awaken the computer from Sleep mode, press any key on your keyboard.

  • Page 15: Use A Media Card (For Selected Models)

    3. Press the card and remove it from your computer. Store the card safely for future use. Purchase accessories Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your computer. Options include memory modules, storage devices, network cards, power adapters, keyboards, mice, and more.
  • Page 16 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 17: Chapter 4. Troubleshooting, Diagnostics, And Recovery

    3. See Chapter 4 “Troubleshooting, diagnostics, and recovery” on page 11 to resolve the problem you are experiencing, run the diagnostic program, and recover your operating system. 4. If the problem persists, contact Lenovo. See Chapter 6 “Help and support” on page 43. Troubleshooting Use the troubleshooting information to find solutions to problems that have definite symptoms.

  • Page 18: Startup Problems

    Startup problems Problem Solution • Ensure that the power cord is correctly connected to the rear of the computer and to a working electrical outlet. • If the computer has a secondary power switch on the rear of the The computer does not start up when you computer, ensure that it is switched on.

  • Page 19: Audio Problems

    Audio problems Problem Solution • If you are using powered external speakers that have an On/Off control, ensure that: – The On/Off control is set to the On position. – The speaker power cable is connected to a properly grounded, functional ac electrical outlet.
  • Page 20 Problem Solution • Connect the cable from the Ethernet connector to the RJ45 connector of the hub. • Enable the Ethernet LAN feature in UEFI BIOS. • Enable the Ethernet LAN adapter. 1. Go to Control Panel and view by large icons or small icons. 2.
  • Page 21 Problem Solution • Enable the Bluetooth feature in UEFI BIOS. • Enable all Bluetooth devices. 1. Right-click the Start button to open the Start context menu. 2. Click Device Manager. Type the administrator password or provide confirmation if prompted. 3. Expand Bluetooth to display all Bluetooth devices. Right-click each Bluetooth device, and then click Enable device.

  • Page 22: Performance Problems

    Performance problems Problem Solution Note: Depending on the volume of the storage drives and amount of data stored on the storage drives, the disk-defragmentation process might take up to several hours. 1. Close any open programs and windows. 2. Open the Start menu. Excessive fragmented files exist on the 3.

  • Page 23: Storage Drive Problems

    Storage drive problems Problem Solution • Ensure that the signal cables and power cables for all the storage drives are connected correctly. • Ensure that the computer is configured correctly to support the storage drives. Some or all storage drives are missing from –...

  • Page 24: Serial Connector Problems

    Recovery This section introduces the recovery information of the Windows 10 operating system. Ensure that you read and follow the on-screen recovery instructions. The data on your computer might be deleted during the recovery process.

  • Page 25: Restore System Files And Settings To An Earlier Point

    Restore system files and settings to an earlier point 1. Go to Control Panel and view by large icons or small icons. 2. Click Recovery ➙ Open System Restore. Then, follow the on-screen instructions. Restore your files from a backup Note: If you use the File History tool to restore your files from a backup, ensure that you backed up your data earlier with the tool.

  • Page 26: Update The Device Driver

    Download and install the latest driver by one of the following methods: • From Lenovo Vantage: Open Lenovo Vantage to check the available update packages. If the latest UEFI BIOS update package is available, follow the on-screen instructions to download and install the package.

  • Page 27: Chapter 5. Cru Replacement

    If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU.

  • Page 28: Remove Or Replace A Cru

    • Power supply assembly * for selected models Remove or replace a CRU This section provides instructions on how to remove or replace a CRU. Power cord Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Before you open the computer cover, turn off the computer and wait several minutes until the computer is cool.

  • Page 29: Computer Cover

    4. Reinstall all removed parts. 5. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. Computer cover Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.

  • Page 30: Front Bezel

    5. Install the new computer cover and secure the cover with the screws. 6. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. Front bezel Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
  • Page 31 4. Install the front bezel by securing the three plastic tabs as shown. 5. Reinstall all removed parts. 6. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. Chapter 5 CRU replacement...

  • Page 32: Storage Drive

    Storage drive Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Attention: The internal storage drive is sensitive. Inappropriate handling might cause damage and permanent loss of data. When handling the internal storage drive, observe the following guidelines: •...
  • Page 33 8. Install the storage drive and secure it with screws. 9. Pivot the drive bay assembly downward until it snaps into position. Chapter 5 CRU replacement...

  • Page 34: Storage Drive Bracket

    10. Reinstall all removed parts. 11. Place the computer in an upright position. Then, reconnect the data cable and power cable to the computer. Note: If a locking device is available, use it to lock the computer. Storage drive bracket Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
  • Page 35 8. Remove the storage drive bracket. 9. Install the new storage drive bracket and pivot the drive bay assemble downward. Chapter 5 CRU replacement...

  • Page 36: M.2 Solid-State Drive

    Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Attention: To replace the Optane memory in the M.2 solid-state drive slot, go to https://support.lenovo.com/ for details. docs/tg_ssd The following illustration shows the location of the M.2 solid-state drive on the system board.
  • Page 37 2. Remove the computer cover. See “Computer cover” on page 23. 3. Remove the front bezel. See “Front bezel” on page 24. 4. Remove the screw from M.2 solid-state drive. 5. Slide the M.2 solid-state drive out. 6. Install the M.2 solid-state drive in. 7.

  • Page 38: Power Supply Assembly

    Power supply assembly Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Attention: Do not open your computer or attempt any repairs before reading the Important Product Information Guide. Although there are no moving parts in your computer after the power cord has been disconnected, the following warnings are required for your safety and proper Underwriters Laboratories (UL) certification.

  • Page 39: Coin-Cell Battery

    7. Connect the new power supply assembly cables to the system board. 8. Install the power supply assembly and then, install the screws. 9. Reinstall all removed parts. 10. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer.
  • Page 40 If the coin-cell battery is incorrectly replaced, there is danger of an explosion. The coin-cell battery contains a small amount of harmful substance. To avoid possible injury: • Replace only with a battery of the type recommended by Lenovo. • Keep the battery away from fire.
  • Page 41 5. Install the coin-cell battery. 6. Secure the coin-cell battery with the latch. 7. Reinstall all removed parts. 8. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. Chapter 5 CRU replacement...

  • Page 42: Optical Drive

    Optical drive Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Replacement procedure 1. Remove the computer cover. See “Computer cover” on page 23. 2. Remove the front bezel. See “Front bezel” on page 24. 3.

  • Page 43: Heat Sink Assembly

    7. Install the optical drive and reconnect the cables. 8. Reinstall all the removed parts. 9. Reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. Heat sink assembly Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.

  • Page 44: Pci-Express Card

    6. Install the heat sink and secure it with screws. 7. Reinstall all removed parts. 8. Place the computer in an upright position. Then, reconnect the power cord and all disconnected cables to the computer. Note: If a locking device is available, use it to lock the computer. PCI-Express card Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.

  • Page 45: Memory Module

    6. Install the PCI-Express card then, secure it by closing the card latch. 7. Reinstall all removed parts. 8. Reconnect all disconnected cables to the computer and reconnect the power cord to the electrical outlet. Note: If a locking device is available, use it to lock the computer. Memory module Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
  • Page 46 Attention: Do not touch the contact edge of the memory module. Otherwise, the memory module might get damaged. Replacement procedure 1. Turn off the computer and remove all connected devices and cables. 2. Remove the computer cover. See “Computer cover” on page 23. 3.
  • Page 47 6. Reinstall all removed parts. 7. Reconnect all disconnected cables to the computer and reconnect the power cord to the electrical outlet. Note: If a locking device is available, use it to lock the computer. Chapter 5 CRU replacement...
  • Page 48 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 49: Chapter 6. Help And Support

    Use Lenovo Vantage to: • Configure device settings. • Download and install UEFI BIOS, drivers and firmware updates. • Open the Start menu and click Lenovo Vantage. • Secure you computer from outside threats. • Use Windows Search. • Diagnose hardware problems.

  • Page 50: Call Lenovo

    Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the following before you contact Lenovo: 1. Record the problem symptoms and details: •...

  • Page 51: Purchase Additional Services

    • Installation and maintenance of network operating systems (NOS) • Installation and maintenance of programs For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, see “Warranty information” in the Safety and Warranty Guide that comes with your computer.
  • Page 52 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 53: Appendix A. Accessibility And Ergonomic Information

    This chapter provides information about accessibility and ergonomics. Accessibility information Lenovo is committed to providing users who have hearing, vision, and mobility limitations with greater access to information and technology. This section provides information about the ways these users can get the most out of their computer experience.
  • Page 54 keyboard with all the standard keys. You can select keys using the mouse or another pointing device, or you can tap to select the keys if your computer supports multi-touch screen. • High Contrast High Contrast is a feature that heightens the color contrast of some text and images on your screen. As a result, those items are more distinct and easier to identify.
  • Page 55 Your computer provides industry-standard connectors that enable you to connect assistive devices. Documentation in accessible formats Lenovo provides electronic documentation in accessible formats, such as properly tagged PDF files or HyperText Markup Language (HTML) files. Lenovo electronic documentation is developed to ensure that visually impaired users can read the documentation through a screen reader.
  • Page 56 Display: Position the display to maintain a comfortable viewing distance of 510 mm to 760 mm (20 inches to 30 inches). Avoid glare or reflections on the display from overhead lighting or outside sources of light. Keep the display screen clean and set the brightness to levels that enable you to see the screen clearly. Press the brightness control keys to adjust display brightness.

  • Page 57: Appendix B. Compliance Information

    • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to operate the equipment.
  • Page 58 이상의 거리에서 사용할 수 있습니다. Enable or disable the ErP LPS compliance mode Lenovo computers meet the eco-design requirements of the ErP Lot 3 regulation. For more information, go https://www.lenovo.com/us/en/compliance/eco-declaration You can enable the ErP LPS compliance mode to reduce the consumption of electricity when the computer is off or in sleep mode.
  • Page 59 • Press the power button. • Enable the Wake Up on Alarm feature to make the computer wake up at a set time. To meet the off mode requirement of ErP compliance, you need to disable the Fast Startup function. 1.
  • Page 60 IdeaCentre 5i (14L, 6), IdeaCentre 5 (14L, 6) User Guide...

  • Page 61: Appendix C. Notices And Trademarks

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 62 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
