www.nordictrack.com
Model No. NTL19007.7
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-888-825-2588
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTL19007.7 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTL19007.7

Summary of Contents for NordicTrack NTL19007.7

  • Page 1 All manuals and user guides at all-guides.com www.nordictrack.com USER'S MANUAL Model No. NTL19007.7 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE;...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. NordicTrack is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    13. To purchase a surge suppressor, see persons with pre-existing health problems. your local NordicTrack dealer or call the tele- phone number on the front cover of this man- 2. It is the responsibility of the owner to ensure...
  • Page 4 All manuals and user guides at all-guides.com 21. Do not attempt to raise, lower, or move the 29. Do not store the television in temperatures treadmill until it is properly assembled. (See below -40° F (-40° C) or above 140° F (60° C). ASSEMBLY on page 7, and HOW TO FOLD Do not operate the television in temperatures AND MOVE THE TREADMILL on page 28.) You...
  • Page 5 All manuals and user guides at all-guides.com 34. Upon completion of any service or repairs to • Use a jumper wire not smaller than No. 6 the treadmill or the television, ask the service AWG (13.3 mm ) copper, or the equivalent technician to perform safety checks to con- when a separate antenna-grounding elec- firm that the unit is in proper operating condi-...

  • Page 6: Before You Begin

    All manuals and user guides at all-guides.com BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack ing this manual, please see the front cover of this man- ® ELITE 7500 treadmill. The ELITE 7500 treadmill offers ual. To help us assist you, note the product model an impressive selection of features designed to make number and serial number before contacting us.

  • Page 7: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 8 All manuals and user guides at all-guides.com 2. Identify the Right Upright (74) and the Left Upright (73). Hold the Right Upright near the Right Base Cover (77). See the inset drawing. Locate the wire tie in the rectangular hole in the lower end of the Right Upright.
  • Page 9 All manuals and user guides at all-guides.com 4. With the help of a second person, hold the con- sole assembly near the Uprights (73, 74). Console Assembly Connect the Upright Wire Harness (75) to the Console Wire Harness (71). See the inset draw- ing.
  • Page 10 All manuals and user guides at all-guides.com 7. Slide the Right Upright Sleeve (96) up against the console assembly. Attach the Right Upright Sleeve with two 3/4" Screws (4). Attach the Left Upright Sleeve (not shown) to Console the console assembly in the same way. Assembly 8.
  • Page 11 All manuals and user guides at all-guides.com Before operating the television, you must connect an antenna or a 75 ohm CATV cable to the 75 ohm ter- minal or the Audio/Video Wire Harness to the audio/video input jacks. No CATV cable, antenna, or adapter is included.

  • Page 12: How To Use The Chest Pulse Sensor

    All manuals and user guides at all-guides.com HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR may remain activated longer than necessary, drain- ing the battery prematurely. The chest pulse sensor consists of two components: the chest strap and the sensor unit.

  • Page 13: Operation And Adjustment

    All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT that is properly installed and grounded in accor- dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with Your treadmill features a walking belt coated with high- performance lubricant.

  • Page 14: Console Diagram

    All manuals and user guides at all-guides.com CONSOLE DIAGRAM FEATURES OF THE CONSOLE the treadmill. iFit cards are available separately. To purchase iFit cards at any time, go to www.iFit.com or call the telephone number on the The treadmill console offers an impressive array of front cover of this manual.

  • Page 15: How To Use The Manual Mode

    All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power.
  • Page 16 All manuals and user guides at all-guides.com 5. Follow your progress with the displays. console will not display your heart rate accu- rately. See page 12 for information about the chest The matrix—When you pulse sensor. select the manual mode, the matrix will Before using display a track that rep- the handgrip...
  • Page 17 All manuals and user guides at all-guides.com HOW TO USE AN EVENT TRAINING WORKOUT To stop the workout at any time, press the Stop button. To restart the workout, press the Start but- 1. Insert the key into the console. ton.
  • Page 18 All manuals and user guides at all-guides.com HOW TO USE A PRESET WORKOUT segment of the workout. The height of the flashing segment indicates the speed setting for the current 1. Insert the key into the console. segment. At the end of each segment, a series of tones will sound and the next segment of the profile See HOW TO TURN ON THE POWER on page 15.
  • Page 19 All manuals and user guides at all-guides.com HOW TO CREATE A CUSTOM WORKOUT the first segment, simply adjust the speed and in- cline of the treadmill as desired by pressing the 1. Insert the key into the console. speed and incline buttons. See HOW TO TURN ON THE POWER on page 15.
  • Page 20 All manuals and user guides at all-guides.com HOW TO USE A CUSTOM WORKOUT If desired, you can redesign the workout while using it. To change the speed setting or the in- 1. Insert the key into the console. cline setting for the current segment, simply press the speed or incline buttons.
  • Page 21 All manuals and user guides at all-guides.com HOW TO USE AN IFIT CARD 3. Press the Start button to start the workout. To purchase iFit cards at any time, see the front cover A moment after you press the Start button, the of this manual or go to www.iFit.com.
  • Page 22 All manuals and user guides at all-guides.com HOW TO USE A HEART RATE WORKOUT buttons to change the maximum target heart rate setting (see EXERCISE INTENSITY on page 33). CAUTION: Note: If you change the maximum target heart rate setting, the intensity level of the entire workout will If you have heart prob- change.
  • Page 23 All manuals and user guides at all-guides.com If your pulse is not detected during the program, Your television can receive analog and digital sig- the letters “PLS” will flash in the display and the nals. For the television to operate properly, good speed and/or incline of the treadmill may automati- reception is necessary.
  • Page 24 All manuals and user guides at all-guides.com HOW TO USE THE REMOTE CONTROL Press the EPG button to view the electronic program guide. Note: The electronic program guide is only The first time you use the re- available when viewing ATSC digital television. mote control, insert batteries (see HOW TO REPLACE THE Press the Info button to view information about the cur-...
  • Page 25 All manuals and user guides at all-guides.com HOW TO ADJUST THE TELEVISION SETTINGS 4. Adjust the time settings. You must use your remote control to adjust television Adjust the OSD (on-screen display) duration, sleep settings. Press the Menu button to enter the main timer, time zone, or daylight saving time settings.
  • Page 26 All manuals and user guides at all-guides.com 6. Scan and save channels. After all valid chan- nels available in Select CATV or AIR. Select CATV to receive chan- your area have been nels through the 75 ohm terminal on the treadmill. saved into the televi- Program Name Skip...
  • Page 27 All manuals and user guides at all-guides.com THE INFORMATION MODE HOW TO USE THE SOUND SYSTEM The console features an information mode that keeps To play music or audio books through the consoleʼs track of the total distance that the walking belt has sound system, you must connect your MP3 player, CD moved and the total number of hours that the treadmill player, or other personal audio player to the console...

  • Page 28: How To Fold And Move The Treadmill

    All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill.

  • Page 29: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 30 All manuals and user guides at all-guides.com Next, locate the Reed Switch (20) and the Magnet (12) on the left side of the Pulley (11). Turn the Pulley View until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and 1/8 in.
  • Page 31 All manuals and user guides at all-guides.com PROBLEM: The incline of the treadmill does not change correctly SOLUTION: a. With the key in the console, press one of the Incline buttons. While the incline is changing, re- move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level.
  • Page 32 All manuals and user guides at all-guides.com PROBLEM: The remote control does not function correctly SOLUTION: a. Make sure that you are standing on the treadmill, holding the remote control near the television and pointing the remote control directly at the console. b.

  • Page 33: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician.

  • Page 34: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. NTL19007.7 R0610A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description Foot Rail Cover Right Rear Foot...
  • Page 35 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Latch Warning Decal Console Clamp AV Wire Nut Upper Latch Bolt Ferrite Box Handrail Cap Chest Pulse Strap Filter Wire Idler Roller Washer Left Grip Incline/Controller Wire Right Grip Incline Stop Bracket...

  • Page 36: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. NTL19007.7 R0610A...
  • Page 37 All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. NTL19007.7 R0610A...

  • Page 38: Ordering Replacement Parts

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
