Thank you for choosing another quality product from Amperes Electronics.
IP PoE speakers provide a convenient way to place your speakers in whatever locations, be it for BGM or Paging purpose in
IP PA setup. Home run of speaker cables is not necessary and what it need is availability of network port, thus a great savings
in cabling cost plus faster deployment of the audio point.
Amperes offers four types of IP PoE speakers to suit your needs, ranging from ceiling mounted, horn, full range speaker to
hanging type pendant ball. The speakers are driven by high efficiency Class D amplifier circuit and compatible with all IP
equipment from Amperes.
INSTRUCTION MANUAL
Ethernet IP PoE Speakers
iFS4020
iCS6020
iPS8020
iHS8020
VER 1 / 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iFS4020 and is the answer not in the manual?

Questions and answers

Related Manuals for Amperes iFS4020

Summary of Contents for Amperes iFS4020

  • Page 1 Amperes offers four types of IP PoE speakers to suit your needs, ranging from ceiling mounted, horn, full range speaker to hanging type pendant ball. The speakers are driven by high efficiency Class D amplifier circuit and compatible with all IP equipment from Amperes.

  • Page 2: Parts Identification

    Parts Identification Speaker Unit iFS4020 iCS6020 iHS8020 iPS8020 Female weatherproof receptacle. Male Plug provided as a full set 1. SPEAKER UNIT The speaker unit has built in class D amplifier module. 2. CONNECTION CABLE This water-proof RJ45 receptacle is to be connected to PoE switch ( 48V ). The pin configuration is shown.

  • Page 3: General Schematic

    General Schematic The diagram below shows simple connections of iP PoE speakers in Amperes iPX environment for music and paging broadcast. For details and further integration with other equipment, please visit our website for more information with the link : www.ampereselectronics.com/product-guidelines. or scan the QR code.

  • Page 4: Device Setup

    IP Speakers are designed to work in Amperes iPX environment, working to receive BGM audio from iPX5200 music server / PMX LAN software and also to receive paging audio from iPD / iEP paging mic in accordance to PA requirement, such as muting on paging and priority broadcast.
  • Page 5 Device Setup BGM Setup Paging Setup Enable the speaker to connect to music streaming source, ie. iPX5200 or PMX Lan software. Set the unit to “auto connect”, which would enable the speaker to search for the audio source whenever it is turned on.

  • Page 6: Firmware Update

    Click on “Select Firmware” tab to update firmware which is available from time to time. Check the version number of the existing unit against the latest available version in the website : www.ampereselectronics.com/downloads-amperes 1. Open browser with the unit’s IP address 2.

  • Page 7: Technical Specification

    Technical Specification iP PoE Speakers PAGE 7...

  • Page 8: Warranty Conditions

    Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized dealers.
