Precision Design, absolute Confidence
Introduction
Built ruggedly with aluminum die cast housing and available in 3 power rating of 20 /
40 and 60W 100V line with half or full power tapping.
Suitable for classrooms, hyper markets, mosques, ballroom, factories, passenger
terminals, exhibition areas etc.
Technical Specification
Power rating
Line Voltage
Transformer Tapping (100V)
Primary Impedance (Ohm)
Sensitivity (1m / 1w)
Frequency Response
Dimension (mm)
Material
Weight with Bracket (kg)
Speaker Unit
Guide to Installation
Wall
Mount
Bracket
Speaker
Mount
Bracket
Recommended size for wall screw :
1) Screw
2) Wall Plug
3: Assemble speaker bracket to the rear of speaker
Speaker Mount Bracket
* Please determine the position of the
bracket prior
www.ampereselectronics.com
CL904
CL908
20W 100V
40W 100V
70 / 100V
20W / 10W
40W / 20W
500Ω / 1k Ω
250Ω / 500Ω
87 ± 3dB
88 ± 3dB
230 - 16 KHz
800 x 79 x 89
350 x 79 x 89
600 x 79 x 89
Aluminum
1.7kg
2.7kg
4 x 2"
8 x 2"
1 : Contents
Wall
Screw
55mm
Plug
Diameter
M4
6mm
Speaker
Adjustable
bracket
Physical Dimensions
CL912
60W 100V
60W / 30W
166Ω / 330Ω
89 ± 3dB
3.6kg
12 x 2"
Wall
Screw
Length
30mm
30mm
4 : Install the speaker to bracket on the wall, with the long
screw provided
1
Slot in the speaker assy to the wall mounted bracket.
2
Insert screw to the top pivot.
3
Insert screw to one of the 3 holes. Select the appropriate
hole according to the desired tilt angle.
Instruction Manual
CL900s Column Speaker
20 - 60W 100V Line Column Speaker
"A"
"B"
"C"
Rear View
Front View
CL904
"A"
"B"
"C"
350 mm
2 : Install wall mount bracket to wall
M4
Wall Mount Bracket
Wall
2
3
1
CL908
CL912
79 mm
89 mm
600 mm
800 mm
Wall
55mm
