Introduction Safety notes Installing/mounting SITRANS SCM IQ Connecting Digitalization SITRANS CC220 and SITRANS Commissioning MS200 Service and maintenance Compact Operating Instructions Technical specifications Dimension drawings Product documentation and support 7MP2200-2CB05-2AA1 (SITRANS CC220) 7MP2210-2BB22-2AB1 (SITRANS MS200 general purpose non-Ex) 02/2025 A5E54380562A-AA...
Page 2
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
⑤ Product name Place of manufacture ② ⑥ Manufacturer ATEX/IECEx marking for intrinsic safety ③ ⑦ Article number ID link according to IEC 61406 ④ ⑧ Degree of protection Approvals SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...
This product includes third-party software. Siemens AG only provides a warranty for updates/ patches of the third-party software, if these have been distributed as part of a Siemens software update service contract or officially released by Siemens AG. Otherwise, updates/patches are undertaken at your own risk.
• National Electrical Code (NEC - NFPA 70) (USA) • Canadian Electrical Code (CEC Part I) (Canada) Further provisions for hazardous area applications are for example: • IEC 60079-14 (international) • EN 60079-14 (EU and UK) SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
• Only carry out modifications that are described in the instructions for the device. Failure to observe this requirement cancels the manufacturer's warranty and the product approvals. Do not operate the device after unauthorized modifications. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Note Operation under special ambient conditions We highly recommend that you contact your Siemens representative or our application department before you operate the device under special ambient conditions as can be encountered in nuclear power plants or when the device is used for research and development purposes.
• They are authorized, trained, or instructed in carrying out work on electrical circuits for hazardous systems. • They are trained or instructed in maintenance and use of appropriate safety equipment according to the pertinent safety regulations. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Safety notes 2.5 Basic safety notes SITRANS CC220 WARNING Use in hazardous area Risk of explosion. • Only use equipment that is approved for use in the intended hazardous area and labeled accordingly. • Do not use devices that have been operated outside the conditions specified for hazardous areas.
2.5.2 Data protection Siemens observes the data protection guidelines, especially the requirements regarding data minimization (privacy by design). This means the following for this product: The product does not process or save any personal information, but only technical functional data (For example time stamps).
Unsuitable battery pack Risk of explosion. SITRANS MS200 is delivered with an LTC (Lithium Thionyl Chloride) battery pack offered by Siemens. • Only use the MS200 Battery 7MP2210-2AB22-2AB8 (Page 59) (Siemens battery pack A5E52358723) SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 18
Loss of safety of device with type of protection "Intrinsic safety Ex i" If a non-Siemens battery has been inserted into the device, the safety of the device is no longer ensured for use in hazardous areas. There is a risk of explosion.
• Do not crush, puncture or open cells or disassemble. • Do not weld or solder to the battery’s body and electrical contacts. • Do not expose contents to water. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
• Observe the relevant DIN/VDE requirements or the applicable country-specific regulations. • Install the bluetooth antenna outside the cabinet. • To install the mounting clamps and brackets, Siemens recommends you use 0.6 Nm tightening torque. Before mounting the device You have all needed anchors and screws available.
Page 22
SITRANS CC220 (Page 63). 5. Bring the bluetooth antenna in a vertical position. Mounting example in a cabinet See technical details of the bluetooth antenna extension in chapter Technical specifications SITRANS CC220 (Page 63). SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Consider the permitted temperature range for operation that depends on the mounting position in accordance with the Technical specifications SITRANS CC220 (Page 63) chapter. Clearances Ensure that the following clearances measurements to another component or to a wall of a housing are complied with: •...
Secure the mounting clips Requirement • The DIN rail is installed at the installation site (35 mm standard profile). • Mounting bracket and mounting clamps • Two screws • T8 screwdriver SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 25
3. Place the brackets on the rear of the device. Align the bracket edge with the device edge. 4. Fasten the brackets with the sup‐ plied screws. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
1. Push the device down until it is released by the rail clamp. 2. Pull the bottom-half of the device away from the standard profile rail. 3. Lift the device up and off. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
1. Place the mounting brackets on the rear of the device. 2. Fasten the brackets with supplied screws. 3. Mark the bore holes, drill the required holes in the wall and fasten the device to the wall using two screws. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
1. Place the mounting brackets on the rear of the device. 2. Fasten the brackets with supplied screws. 3. Mark the bore holes, drill the required holes in the wall and fasten the device to the wall using two screws. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
4. Insert the top housing's two plastic clips into the clip holes on the heatsink. 5. Press the top housing to secure the clips. 6. Install power plug and screws for the COM interface. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Note Material compatibility Siemens can provide you with support concerning selection of parts wetted by process media. However, you are responsible for the selection of parts. Siemens accepts no liability for faults or failures resulting from incompatible materials. CAUTION Hot surfaces resulting from hot process media Risk of burns resulting from surface temperatures above 65 °C (149 °F).
In all cases, a strong, form-fitting mount for good vibrations transmission is required. Note For temporary mountings (testing purposes, for example), use a non flammable (UL94-V0) standard approved glue to mount SITRANS MS200. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Note Influences on data transmission The positioning of the sensors and the gateway, as well as the environmental conditions, influence the data transmission between SITRANS MS200 and SITRANS CC220. In case of an unfavorable constellation, transmission losses may occur. 3.2.3 Installing SITRANS MS200 on a pump or compressor Mount SITRANS MS200 near the liquid inlet directly on the pump.
• Make sure that no environmentally hazardous media are released. • Secure the remaining connections so that no damage can result if the process is started unintentionally. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
If there are voltage peaks on power supply lines, use a protective device in the form of a varistor (MOV) UMOV = U-rated x 1.2 (BLITZDUCTOR BVT AVD 24 (918 422) or compatible). Note The connection line must meet the requirements of IEC 60332-1-2 and IEC 60332-1-3, or alternatively, the requirements of IEC/TS 60695-11-21. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
• Never operate the device without functional grounding. • If a device is defective, remove it from operation without delay and label it accordingly. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
• A two-core cable, meeting the following requirements: – a copper (Cu) cable with cross-section of 0.75 to 2.5 mm – rated temperature 70 °C • A slotted screwdriver with a 3 mm blade SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 38
3. Insert the connecting terminal into the power supply slot. If done correctly, STAT LED and PWR LED blink green. 4. Connect SITRANS CC220 to your network, using Ethernet port X1 P1 - LAN. Figure 4-1 Ethernet connection X1 P1 - LAN 5.
Condition • You need the sensor and the grease included in the packaging. Take both out of the packaging • Wear anti-static gloves to avoid PCB contamination and static discharge. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 40
• Prevent grease or other contaminants from touching internal circuit boards, as this could reduce battery life. • Avoid direct skin contact with internal circuit boards. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 41
2. Connect the battery power connector to the PCBA (Printed Circuit Board Assembly). The LED located on the PCBA lights up for one second after the boot process is completed (up to 1 minute). SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 42
• Avoid getting grease on electrical components and the rest of the enclosure. Note • The grease is necessary to ensure the IP rating of the enclosure. • A lubricated O-ring ensures easy opening of the housing when replacing the battery. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 43
5. Mount the SITRANS MS200 onto the asset, using a wrench (min. 18 Nm/max. 20 Nm). The sensor is now active and can be connected wirelessly to the gateway via Bluetooth® low energy. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 44
Commissioning 5.2 Powering up SITRANS MS200 SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Monitor the Bluetooth LE connection quality and send generated events to the cloud for monitoring. Contact the Siemens technical support, if the issue persists after reviewing these potential causes. 6.1.2 Maintenance The device is maintenance-free.
5 years. WARNING Impermissible repair and maintenance of the device • Repair and maintenance must be carried out by Siemens authorized personnel only. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Service and maintenance 6.2 Maintenance and repair work for SITRANS CC220 CAUTION Hazardous voltage at open device Risk of electric shock when the enclosure is opened or enclosure parts are removed. • Before you open the enclosure or remove enclosure parts, de-energize the device.
6. Send the log files to the Technical support (Page 72). 7. Ensure you remove the "ConBox.Commands.json" file from the USB stick, before establishing a new connection of SITRANS CC220 to SITRANS SCM IQ (Onboarding). SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Service and maintenance 6.2 Maintenance and repair work for SITRANS CC220 6.2.3 Replacing the backup battery Prior to replacement WARNING Risk of explosion and release of harmful substances Improper handling of lithium batteries can result in an explosion of the batteries.
Page 50
Service and maintenance 6.2 Maintenance and repair work for SITRANS CC220 Before replacing the backup battery Ensure the following: • The device is disconnected from the power supply. • You have removed the bluetooth antenna. • You have the replacement battery (Page 59) available.
Service and maintenance 6.2 Maintenance and repair work for SITRANS CC220 Remove the motherboard. Pull the plug of the battery ca‐ ble from the motherboard. Remove the old battery. Stick the double-sided tape on the new battery and then glue it on the display port socket.
⇒ Both USER LEDs are blinking orange while the firmware update is ongoing (takes 5 to 10 minutes). We recommend you to remove the USB stick from SITRANS CC220. ⇒ If the firmware update passed the USER LEDs light green for 10 seconds.
• Seal integrity of the cover NOTICE Penetration of moisture into the device Damage to device. • Make sure when carrying out cleaning and maintenance work that no moisture penetrates the inside of the device. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
• If contact with the corrosive substances occurs, rinse the affected skin immediately with large amount of water to dilute substance. 6.3.2 Replacing the Siemens battery pack Condition • You have received the MS200 Battery 7MP2210-2AB22-2AB8 (Page 59) (Siemens battery pack) SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 55
For more information, refer to the ESD Guideline. 2. Disconnect the battery connector by gently pulling the cable. Pay attention to the plug orientation. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 56
If the enclosure is not closed correctly, the sensor is not water tight. Ensure that the gasket between the two lids is not visible from the outside after screwing them togheter, indicating that the gasket is mounted correctly. SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
6. Train new anomaly detection model based on new SITRANS MS200 data. Repositioning SITRANS MS200 on the same machine Note In this scenario, SITRANS CC220 and Insights Hub asset remain the same. 1. Stop anomaly detection models of the respective SITRANS MS200. 2. Reposition SITRANS MS200.
Page 58
1. Stop anomaly detection models of the respective SITRANS MS200. 2. Change assignment to Insights Hub asset of SITRANS MS200 in SITRANS SCM IQ by clicking on "Device configuration > > Configure sensor". SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
"Sensor data modelling" > click on your sensor > "See details". 7. Train new anomaly detection model only based on new data. Ordering of spare parts Condition • You have a Siemens Industry Mall account. Procedure 1. Open the PIA Life Cycle Portal (https://www.pia-portal.automation.siemens.com). 2. Select the desired language.
The watch list opens. 6. Click "Add to cart of Industry Mall". The Siemens Industry Mall opens and you can order your spare part. Cleaning the enclosure • Clean the outside of the enclosure with the inscriptions using a antistatic cloth moistened with water or a mild detergent.
Service and maintenance 6.7 Disposal Contact your Siemens representative to clarify if a product is repairable, and how to return it. They can also help with quick repair processing, a repair cost estimate, or a repair report/ cause of failure report.
Page 62
Service and maintenance 6.7 Disposal SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Antenna extension cord (optional) Type WLAN extension cord, SMA male, SMA female Maximum cable length 3 m Impedance Coaxial 50 Ohm Interfaces LAN interface 1 GB LAN port X1 P1 - LAN, RJ45 SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 64
Impact resistance, tested in accordance with IEC 60068-2-27 150 m/s , 11 ms • Operation 250 m/s , 6 ms • Storage/transport Direct current supply (DC) Power Supply DC 12 to 24 V Power consumption max. 15 W SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Technical specifications 7.2 Certificates and approvals SITRANS CC220 Wireless communication Bluetooth® (standard) Wireless protocol Bluetooth® low energy (BLE) 5.1 Frequency range 2 400 ... 2 480 MHz Max. transmit power +5.5 dBm Max. receive sensitivity -96.75 dBm (BLE-1M) Antenna rod antenna Distance to SITRANS MS200 up to 30 m...
Operation: -1000 ... 2000 m (pressure 795 ... 1080 hPa) Rating IP68 (2 m, 24 h) IP69 Temperature measurement Temperature range -30 ... +80 °C for general purpose device -30 ... +50 °C for hazardous areas Resolution 0.01 °C Repeatability ±0.15 °C Accuracy ±4 °C Data format 16 bits SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Certificates and approvals SITRANS MS200 SITRANS MS200 CE / RED USA, Canada, UCKA, South Africa, Hong Kong, Colombia, Ecuador, India, Peru, Nigeria, Serbia, Bahrain "Intrinsic safety" type of protection SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 68
Note Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Para maiores informações, consulte o site da ANATEL – www.anatel.gov.br SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
– "Download as html5, only PC": Open or save the manual in the HTML5 view on your PC You can also find manuals with the Mobile app at Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/sc/2067). Download the app to your mobile device and scan the device ID link. Product documentation by serial number Using the PIA Life Cycle Portal, you can access the serial number-specific product information including technical specifications, spare parts, calibration data, or factory certificates.
(http:// www.siemens.com/automation/csi/service). Service & support on the Internet In addition to our technical support, Siemens offers comprehensive online services at service & support (http://www.siemens.com/automation/serviceandsupport). Contact If you have further questions about the device, contact your local Siemens representative, by doing the following: 1.
Noise emission, 63 function earth, 36 Connecting, 36 Power supply Connecting, 35 Hazardous area DC power supply, 64 Laws and directives, 11 SITRANS MS200, 66 Qualified personnel, 14 Powering up SITRANS MS200, 41, 55 Hotline, (Refer to Support request) SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
Page 74
Support request, 72 Symbols, (Refer to warning symbols) Technical specifications SITRANS MS200, 66 Technical support, 72 partner, 72 personal contact, 72 Test certificates, 11 USB stick, 64 Wall mounting, 23, 27, 28 Warning symbols, 11 Warranty, 10 Weight, 63 SITRANS MS200, 66 SITRANS CC220 and SITRANS MS200 Compact Operating Instructions, 02/2025, A5E54380562A-AA...
