Progres Agronic 4500 Manual

SUPPLIED MATERIAL
RJ11 and RJ45
Expansion plate
outputs
M3 nut and plastic
washer
External and internal cable
BOX FORMAT ASSEMBLY
1
Disconnect power from the
Agrónic 4500
Depending on the number of
4
expansions to be installed, a marked
hole must be made on the right side
of the main enclosure (starting from
the 2nd expansion of 56 outputs).
Agrónic 4500
Expansion up to 40, 56, 72, 88 or 104
outputs for box model
Spacer
cables 30 mm
Expansion box
2
Remove the four screws.
5
Place and secure the supplied plates using the screws and washers as
indicated in the following image.
17 mm
24 to
Expansion box
Screw
Relay plates
M3x6
M3x6 screws
Plastic washer
Nut M3
30 mm spacer
Green internal cable
External cable
RJ11 Cable
RJ45 Cable
Number of outputs
40 56 72 88
- 1 1 1
1 2 3 4
4 - - -
4 - - -
- - - 4
- - 4 -
- 2 2 2
- 1 1 1
1 2 3 4
1 2 3 4
3
Lift the keyboard.
M3 x 6 screw and
Plastic washer
1 expansion
st
Manual - Agrónic 4500 ·
104
1
5
-
-
-
4
2
1
5
5
1
