ASSEMBLY AND CONNECTION MANUAL
AGRÓNIC 2500
VERSION 3
Sections in the manual:
‒ Dimensions
‒ Technical specifications
‒ Connection locations
‒ Connections
‒ Installing the options
‒ Recommendations
The sections on Programming, Manual Actions and
Query are detailed in the User Manual.
The input and output parameters and coding sections
are detailed in the Installer's Manual.
The Communications Parameters section is detailed in
the Communications Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGRONIC 2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Progres AGRONIC 2500

Summary of Contents for Progres AGRONIC 2500

  • Page 1 ASSEMBLY AND CONNECTION MANUAL AGRÓNIC 2500 VERSION 3 Sections in the manual: ‒ Dimensions ‒ Technical specifications ‒ Connection locations ‒ Connections ‒ Installing the options ‒ Recommendations The sections on Programming, Manual Actions and Query are detailed in the User Manual. The input and output parameters and coding sections are detailed in the Installer’s Manual.
  • Page 2 Welcome to the Agrónic 2500 manual. We are pleased to count on your experience and skills to install the Agrónic 2500. This document will guide you in the process of installing the Agrónic on the farm or electrical panel. It provides details on the dimensions of the controller and wiring of the different connection options.

  • Page 3: Table Of Contents

    Index Dimensions ......................4 Technical specifications ..................5 Connection locations ..................6 3.1. Box format ....................6 3.2. Built-in format ................... 7 Connections ......................8 4.1. Connecting the power supply ..............8 4.2. Connecting the ground connection ............8 4.3. Connecting digital inputs ................9 4.4.

  • Page 4: Dimensions

    DIMENSIONS Where to install the Agrónic In the built-in format, a hole must be drilled in the front Install the Agrónic at the correct height and position of the cabinet or desk according to the measurements for good handling. Avoid direct sunlight, humidity, indicated in the previous drawing and held in place by dust and vibrations as much as possible.

  • Page 5: Technical Specifications

    2 TECHNICAL SPECIFICATIONS General power supply Voltage 12 Vdc +15% -10% Power consumption Less than 12.5 W (0.3 W in standby) Fuse Input Thermal (PTC) 1.1 Amp. at 25°C, auto-resettable Output power source Voltage From 12 to 24 Vdc or Vac (maximum 30 V) Fuse Input “R+”...

  • Page 6: Connection Locations

    3 CONNECTION LOCATIONS 3.1. BOX FORMAT In the box format, remove the bottom cover to access The connectors and antennas from the rest of the the connectors. options are located on the right side. To insert cables, the holes required must be punched It is recommended to connect the wires to the terminal out (do this with the connection cover in place and using the terminal connectors that come with the unit.

  • Page 7: Built-In Format

    Connection locations | Built-in format 3.2. BUILT-IN FORMAT To connect the built-in model, access the back park expansion option and 4 analog inputs. On the sides, located inside the desk or cabinet. The connections for there may be the USB port connector, the 2 analog the power supply, inputs and outputs on the 9-, 18- or input and the 5 digital input options.

  • Page 8: Connections

    4 CONNECTIONS The unit must be installed pursuant to the current regulations that apply to electrical installations. The unit will not be adequately protected if it is not used as specified in this manual. The Agrónic must be installed away from interference sources such as frequency drives, pumps and power cables. Sensor and communication cables should never pass next to cables with alternating current and should preferably be shielded.

  • Page 9: Connecting Digital Inputs

    Connections | Connecting digital inputs 4.3. CONNECTING DIGITAL INPUTS Digital inputs Both the digital inputs and the relay outputs are • DM Definitive malfunction powered externally at 12 Vdc or 24 Vac. • CS Conditional stop The digital inputs are galvanically isolated by optocou- •...

  • Page 10: Connecting The Outputs

    Connections | Connecting the outputs 4.4. CONNECTING THE OUTPUTS 4.4.1 Relay output connection All the outputs are operable at either 12 or 24 volt in al- The outputs are isolated from the internal circuitry by ternating or continuous current (do not supply voltage relays and protected by a varistor in each one.
  • Page 11 Connections | Connecting the outputs 12 Vdc outputs (12 Vdc installation) Assembly and connection manual | Agrónic 2500...

  • Page 12: Connection Of Latch Outputs

    Connections | Connecting the outputs 4.4.2 Connection of latch outputs In installations where very low power consumption The installer can configure the unit to use latch is needed, latch valves are usually used. The latch solenoid valves in the two or three-wire format and a solenoid valve, also called from impulses, functions 12 or 22-volt trip voltage.
  • Page 13 Connections | Connecting the outputs 3-Wire latch connections This solenoid valve model has two commons; the one The CM start and the CP stop commons must also be for starting (normally red) will be brought to the diode connected on the unit and from the diode box. If the box, to one of the terminals marked Start ;...

  • Page 14: Latch Relay Connection

    Connections | Connecting the outputs 4.4.3 Latch relay connection When there are electrical units in the installation Like latch valves, there are two types: 2-wire and 3-wire. (injectors, mixers, pumps, etc.) that must be activated Depending on how Agrónic is configured, it must make by Agrónic, a ‘latch relay’...

  • Page 15: Options

    5 OPTIONS 5.1. DIESEL PUMP CONTROL OPTION In installations where there is a motor pump, the mentary relay is intercalated between each to prevent Agrónic can manage the start and stop maneuvers. To damage to the internal relays. manage it, it uses four outputs (preheating, contact, The contact output is connected through the relay to start and stop) and a digital input (oil pressure gage).

  • Page 16: Dual Voltage Option

    Options | Dual Voltage Option If the pump is stopped when the fuel supply is cut off For greater safety, it is convenient to have a dual by a solenoid valve, it is installed at the same injector stopping system that uses an electromagnet for input for the stop to be as quick as possible.
  • Page 17 Options | Dual Voltage Option Diesel pump with generator set without control unit Diesel pump with generator set with control unit Assembly and connection manual | Agrónic 2500...

  • Page 18: Option 2 Analog Inputs

    Options | Option 2 analog inputs 5.3. OPTION 2 ANALOG INPUTS Only for the Plus version. This option allows up to two The wiring in this option has one switch per sensor to analog sensors to be connected in order to measure select the measurement using current or voltage.
  • Page 19 Options | Option 2 analog inputs Examples • Independent power supply output: Connect the common from the sensor to terminal 4 and t he sensor signal to terminal 1 or 2. • Sensor powered by the Agrónic: Connect the common from the sensor to terminal 4, the sensor signal to terminal 1 or 2 and the power supply positive to terminal 3.

  • Page 20: Sdi-12 Expansion Option And 4 Analog Inputs

    Options | SDI-12 expansion option and 4 analog inputs 5.4. SDI-12 EXPANSION OPTION AND 4 ANALOG INPUTS Only with the PLUS version. This option allows you to tors on the right side of the unit. connect up to 4 4-20 mA sensors, on terminals A2-1 to IMPORTANT The sensor cables and the SDI-12 must be A2-4 and several multi-sensors that communicate with shielded and routed separately from AC cables.

  • Page 21: Expansion Option Five Digital Inputs

    Options | Expansion option five digital inputs 5.5. EXPANSION OPTION FIVE DIGITAL INPUTS In models with relay outputs, the option to add 5 The common CD digital sensor is located next to digital sensors can be installed. These are located in inputs 1 to 6.

  • Page 22: Recommendations

    6 RECOMMENDATIONS • In installations that have a pressure transducer, it Controller location must be galvanically isolated from the pressure • Install the controller at the correct height and pipe, since interference can propagate through position for good handling. it. The transducer can be secured to the wall by •...

  • Page 23: Technical Support

    7 TECHNICAL SUPPORT Apart from this manual, the Agrónic 2500 has other manuals, instruction videos, tips and fre- quently asked questions on the Progrés website, Technical Support section. Assembly and Communications connection manual manual r2465 r1850 Intended for those who physically install Intended for installers who configure the Agrónic on the farm or in the electri- communications with the cloud for...
  • Page 24 Pivot manual Solar irrigation manual r2485 r2006 For the installer and end user who uses Intended for the installer and user who the unit for pivot control. uses hybrid solar irrigation systems (panels + generator set). See manual See manual Installing the options Installation Option GPRS Installation Option USB (r1933)
  • Page 25 SPACE RESERVED FOR THE USER Use this space to record information such as the parameters entered into the controller, drawings, program information, determining factors, alarms, etc. Assembly and connection manual | Agrónic 2500...
  • Page 26 Assembly and connection manual | Agrónic 2500...
  • Page 27 Assembly and connection manual | Agrónic 2500...
  • Page 28 Compensation for direct and indirect damage caused by the use of the unit is excluded from the guarantee. Sistemes Electrònics Progrés, S.A. Polígon Industrial, C/ de la Coma, 2 | 25243 El Palau d’Anglesola | Lleida | Spain Tel. 973 32 04 29 | info@progres.es | www.progres.es R-2365...
