316 SS MODELS: M154T, 154S/T, 204T, 204 S/T, 304 T
OPERATING INSTRUCTIONS, INSTALLATION & MAINTENANCE
860 Church Rd Elgin, IL 60123
330 Mill Bay South Suite 1511
IL - (847) 841-7867
Distributed by Pump Supply Inc
MANUAL INCLUDING SPARE PARTS LIST
Illinois Location:
(847) 841-7867
Minnesota Location:
(651) 758-7867
Afton, MN 55001
PumpSupplyInc.com
PumpSupplyInc.com
MN - (651) 758-7867
ISO 9001 Certified
MN - (651) 758-7867
Advertisement
Table of Contents
Related Manuals for Mody Pumps M154T
Summary of Contents for Mody Pumps M154T
- Page 1 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 316 SS MODELS: M154T, 154S/T, 204T, 204 S/T, 304 T OPERATING INSTRUCTIONS, INSTALLATION & MAINTENANCE MANUAL INCLUDING SPARE PARTS LIST Illinois Location: (847) 841-7867 860 Church Rd Elgin, IL 60123...
- Page 2 Never operate a pump with a plug-in type power cord without a ground fault circuit interrupter, adequate overload and short circuit protection. IMPORTANT !!! MODY Pumps Inc. is not responsible for losses, injury, or death resulting from a failure to observe these safety precautions, misuse or abuse of pumps or equipment.
-
Page 3: General Information
THE HP. THE PUMPS CAN ALSO BE SUPPLIED WITH A SUITABLE ADAPTER FOR DIRECT CONNECTION TO A 2.5” OR 3" FIRE HOSE INSTANTANEOUS COUPLING. THE MOTORS ARE RATED 5HP/3HP/2HP (MODEL M304T/M204T/M154T) SUITABLE FOR 230/460 VOLTS, 3 PHASE, 60 HZ POWER SUPPLY.(MOTORS ARE AVAILABLE FOR VARIOUS POWER SUPPLY CONFIGURATIONS -- PLEASE CHECK NAME PLATE ON THE PUMP VERY CAREFULLY TO CONFIRM THAT YOUR POWER SUPPLY MATCHES THE NAME PLATE DETAILS). -
Page 4: Installation
THE UNIT. THE AMPERAGE SHOULD BE LESS THAN OR EQUAL TO THE FULL LOAD AMPS AS INDICATED ON THE NAMEPLATE. H.R.C. FUSES ARE RECOMMENDED STRONGLY AS PER TABLE BELOW MAINS VOLTAGE AT SITE HRC FUSE RECOMMENDED M304T M204T M154T 230 VOLTS 3 PHASE 25 AMPS 16 AMPS 10 AMPS 460 VOLTS... -
Page 5: Trouble Guide
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 TROUBLE GUIDE CAUSE REMEDY 1.FUSES BLOWN. 1.REPLACE FUSES 2.CABLE DAMAGED 2.SHORTEN/REPLACE CABLE PUMP DOES NOT START 3 NO POWER. 4.BLOCKED IMPELLER. 4.CLEAN BOTTOM PARTS. 5.STATOR WINDING BURNT. 5.REPLACE STATOR. - Page 6 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 GENERAL OVERHAUL AND OIL CHECK. (ID NOS. ARE FOR MODEL M 304T/316SS) REFER DRAWINGS DWG/208/00 (SHEET 1 & 2) AT END OF MANUAL. • ALWAYS REPLACE O-RINGS WITH NEW ONES WHENEVER DISMANTLING AND RE- ASSEMBLING A PUMP.
-
Page 7: Oil Specifications
ORDERING OF SPARE PARTS. PLEASE NOTE THE MANUAL AND DRAWINGS REFER TO THE FOLLOWING MODELS OF PUMPS: A] M304T/316SS B] M204T/316SS C] M154T/316SS D] M204S/T/316SS E] M154S/T/316SS WHEN ORDERING SPARE PARTS PLEASE CLEARLY INDICATE THE PART NO. DEPENDING ON THE MODEL OF THE PUMP AND THE OUTLET SIZE AND TYPE. - Page 8 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 RECOMMENDED SPARES FOR TWO YEARS (ALL MODELS) • 1 DIFFUSER • 1 IMPELLER • 1 WEAR PLATE • 1 ‘O’ RING SET • 1 SET OF BEARINGS •...
- Page 9 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 IL - (847) 841-7867 PumpSupplyInc.com MN - (651) 758-7867...
- Page 10 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 IL - (847) 841-7867 PumpSupplyInc.com MN - (651) 758-7867...
- Page 11 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 IL - (847) 841-7867 PumpSupplyInc.com MN - (651) 758-7867...
- Page 12 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 MODY M304T/316SS VER 1.0 D.NO. PART NO. DESCRIPTION 065-014-79 CABLE 660-091-00 CABLE GRIP (order with grip) 085-022-24 CABLE CLAMP 525-022-24 PH.PAN HD.SCREW 662-001-66 CABLE SUPPORT 650-013-24 STUD 370-006-24 HEX NUT 660-091-00...
- Page 13 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 MODY M304T/316SS VER 1.0 D.NO. PART NO. DESCRIPTION 370-004-24 HEX NUT 650-002-24 STUD 600-033-24 CAP FOR CIRCLIP 515-009-24 SAND GUARD 525-025-24 PH.PAN HD SCREW 370-002-24 HEX NUT 085-005-24 OIL BAG CLAMP BIG 085-004-24...
-
Page 14: Limited Warranty
No rights extended under this warranty shall be assigned to any person, whether by operation or otherwise, without our prior written approval. Mody Pumps Inc. 2166 Zeus Court, Bakersfield, CA 93308 Tel.: (661) 392-7600 Fax: (661) 392-7601 IL - (847) 841-7867 PumpSupplyInc.com...
