- Page 1 MODELS: G 502 T, G 504 T OPERATING INSTRUCTIONS, INSTALLATION & MAINTENANCE MANUAL INCLUDING SPARE PARTS LIST Mody Pumps Inc. 2166 Zeus Court Bakersfield, CA 93308 Tel.: (661) 392-7600 FAX.: (661) 392-7601 EMAIL: sales@modypump.com http://www.modypump.com ISO 9001 Certified...
- Page 2 Never operate a pump with a plug-in type power cord without a ground fault circuit interrupter, adequate overload and short circuit protection. IMPORTANT !!! MODY Pumps Inc. is not responsible for losses, injury, or death resulting from a failure to observe these safety precautions, misuse or abuse of pumps or equipment.
- Page 3 INTRODUCTION “mody” MOTOR DRIVEN PORTABLE SUBMERSIBLE PUMPS HAVE BEEN DEVELOPED DUE TO A LONG FELT NEED OF HAVING A TRULY MAINTENANCE FREE PUMPSET FOR VARIOUS APPLICATIONS. THE PUMP IS A LIGHTWEIGHT, COMPACT UNIT ENABLING IT TO BE USED IN MOST SEA-CRAFT DIFFICULT LAND...
-
Page 4: Overall Dimensions And Weight
OVERALL DIMENSIONS AND WEIGHT. G 502T & G 504T OVERALL HEIGHT 23”(APPROX.) MAX. DIAMETER 10.75” MAX. WEIGHT(EXCL. CABLE) 110 lbs. MAINTENANCE SERVICES REQUIRED. THE FOLLOWING CHECKS TO BE DONE AT INTERVALS INDICATED BELOW: 1. CONDITION OF SEALS TO BE CHECKED AT EVERY 2500 HRS. OF OPERATION BY ASCERTAINING THE CONDITION OF OIL IN THE SEAL CHAMBER. - Page 5 MAINS VOLTAGE AT SITE HRC FUSE RECOMMENDED 220 VOLTS / 3 PHASE 20 AMPERES 380 VOLTS / 3 PHASE 16 AMPERES 460 VOLTS / 3 PHASE 15 AMPERES FAULT FINDING IN THE UNIT. TROUBLE GUIDE CAUSE REMEDY 1.FUSES BLOWN. 1.REPLACE FUSES 2.CABLE DAMAGED 2.SHORTEN/REPLACE CABLE PUMP DOES NOT START.
- Page 6 THE SEAL CHAMBER THE HEART OF THE MODY PUMP. DUAL MECHANICAL, TUNGSTEN CARBIDE V/S TUNGSTEN CARBIDE SEAL FACES(LOWER SEAL) AND TUNGSTEN CARBIDE V/S TUNGSTEN CARBIDE (UPPER SEAL),SECONDARY SEALS OF HNBR RUBBER AND METAL PARTS IN STAINLESS STEEL, RUNNING IN AN OIL BATH, ENCLOSED IN A PRESSURE COMPENSATING RUBBER OIL BAG -CREATES THE ULTIMATE SEAL SOLUTION.
-
Page 7: Electrical Information
ELECTRICAL INFORMATION MOTORS ARE DESIGNED TO OPERATE ON SINGLE VOLTAGE AND FREQUENCY. MAX. DEVIATION IN VOLTAGE ALLOWED IS + - 6 % AND FREQUENCY +- 3% .CHECK NAME PLATE FOR OPERATING VOLTAGE AND FREQUENCY. DISMANTLING AND OVERHAULING GENERAL OVERHAUL AND OIL CHECK.(REF. DRGS. # DW/130/00 SHEETS 1 & 2 1. - Page 8 9. CHECK BOTH UPPER AND LOWER BEARINGS(9 & 68) FOR ANY RADIAL OR AXIAL PLAY OR ANY ABNORMAL NOISE WHILE SPINNING THE SAME. CHECK FOR ANY LEAKAGE OF GREASE THROUGH THE SHIELD OF THE BEARING. IF BEARING SEEMS WORN OUT OR ANY GREASE LEAKAGE IS OBSERVED, REPLACE BEARING.(DO NOT USE ANY STANDARD BEARING PROCURED FROM THE MARKET.
-
Page 9: Oil Specifications
10. TURN OIL BAG INSIDE OUT AND FIT OIL BAG "VEE" SECTION INTO GROOVE IN SEAL HOUSING(28).USING SMALL OIL BAG CLAMPS AND SCREWS & NUTS CLAMP THE OIL BAG TO THE SEAL HOLDER. TURN OIL BAG TO CLAMP THE LARGER SIDE "VEE" SECTION TO THE GROOVE IN THE LOWER BEARING BRACKET IN THE SAME WAY. - Page 10 R: RECOMMENDED SPARES FOR TWO YEARS OPERATION SR.NO DESCRIPTION PART NO. RECOMMENDED QTY. MECHANICAL SEAL 535-022-00 1 NO. MECHANICAL SEAL 535-022-00 1 NO. "O" RING SET 375-003-66 2 SETS. CABLE GROMMET 260-013-66 2 NOS. CABLE LEAD GROMMET 260-014-66 2 NOS. UPPER BEARING 020-005-07 1 NO.
-
Page 14: Limited Warranty
OR FITNESS FOR A PARTICULAR PURPOSE. No rights extended under this warranty shall be assigned to any person, whether by operation or otherwise, without our prior written approval. Mody Pumps Inc. 2166 Zeus Court, Bakersfield, CA 93308 Tel.: (661) 392-7600 Fax: (661) 392-7601...
