Omni 2 – Zippie Salsa Hotseat
Retro Fitting Help Guide
CONFIDENTIAL: For internal use only.
CONFIDENTIAL: For internal use only.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Omni 2 Zippie Salsa Hotseat and is the answer not in the manual?

Questions and answers

Related Manuals for Sunrise Medical Omni 2 Zippie Salsa Hotseat

Summary of Contents for Sunrise Medical Omni 2 Zippie Salsa Hotseat

  • Page 1 Omni 2 – Zippie Salsa Hotseat Retro Fitting Help Guide CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 2 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Parts Required: Electronics • Omni 2 Kit – 20011242 (includes Input Section, Display Screen, 250cm connecting cable) Backpack, Mounting kit and R-Net bus cable • 20009168 (with fixed back) • 20009169 (with reclining back) Omni 2 Flex Mount –...
  • Page 3 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Parts Required: CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 4 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 1 • Remove Omni 1 or retro fit the Omni flex mount to the armrest. All parts included in the kit. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 5 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 2 • Remove any cable tidy and disconnect R-Net Bus Cable from the Omni 1 if removing. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 6 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 3 • Unscrew Omni 1 from the mounting bracket to remove. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 7 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 4 • Fix the Omni 2 adapter plate to the Omni 2 Display Module with 2 small bolts. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 8 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 5 • Fix the Omni 2 with adapter plate to the Omni mounting bracket with 2 bolts. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 9 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 6 • Take the 2 Omni 2 backpack mounting plate and fixings provided in the kit. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 10 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 7 • Remove the two securing bolts from the headrest mounting bracket using a 5mm Allen key. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 11 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 8 • Completely remove the two short headrest mounting bolts and replace with the longer bolts included in the kit. The thread on the bolts should stick out by about 10mm CONFIDENTIAL: For internal use only.
  • Page 12 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 9 • Screw the two silver metal extension blocks to the threads. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 13 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 10 • Fit by hand but use a spanner to tighten up. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 14 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 11 • Take the mounting plate and line up with the holes in the silver metal extensions. Correct mounting holes shown below. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 15 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 12 • Use a 5mm Allen key to secure the countersunk bolts in place to hold the mounting plate. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 16 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 13 • Ensure the bolts are secured as shown below. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 17 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 14 • Take the Omni 2 backpack and fixings provided. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 18 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 15 • Fix the Omni 2 backpack to the mounting plate using the fixings. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 19 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 16 • Use a spanner and Allen key to tighten up all 4 Omni 2 backpack bolts. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 20 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 17 • Fix all 4 bolts in the holes shown below and tighten. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 21 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 18 • Take the Omni 2 Input section and fix the Velcro to the rear of the module. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 22 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 19 • Attached the Omni 2 Input Section to the Velcro pad inside the backpack. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 23 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 20 • Connect the charging socket lead to the port on the right side of the Input Section. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 24 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 21 • Connect the 90 degree bus cable into the port on the left side of the Input Section. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 25 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 22 • Make sure the bus cable is connected correctly. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 26 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 23 • If NOT replacing an existing Omni 1 then fit the Omni Flex-Mount to the chair using the fixing bolts and nuts. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 27 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 24 • Fit the Omni Flex mount bracket to the armrest mounting bracket. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 28 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 25 • Take the Omni 2 Display module and turn over so you can see the two gold sockets. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 29 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 26 • Secure the Omni 2 adapter plate to the Omni 2 Display Module. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 30 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 27 • Secure the Omni 2 to the flex mount. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 31 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 28 • Fit the Omni 2 and Flex mount to the mounting bracket and secure with the hand wheel screw. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 32 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 29 • Plug the Display cable into the DISP port on the Input Section. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 33 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 30 • Plug the connecting cable from the Input section and into the Display module. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 34 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 31 • Connect the Omni 2 Input section into the R-Net Bus. system. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 35 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 32 • Use the Velcro loops inside the backpack to tidy the display connecting cable. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 36 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 33 • Ensure you fix the display connector in place along the armrest. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 37 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 34 • Follow the Omni 2 Programming guide to program the chair through Web IQ. Turn the system on once programmed and wait for the system to calibrate, then cycle the power.
  • Page 38 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 34…..cont • Follow the Omni 2 Programming guide to program the chair through Web IQ. Turn the system on once programmed and wait for the system to calibrate, then cycle the power.
  • Page 39 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 35 If the chair has a reclining backrest. • Remove the main backpack mounting plate using a 4mm Allen key. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 40 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 36 If the chair has a reclining backrest. • Take the two extension spacers supplied in the kit. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 41 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 37 If the chair has a reclining backrest. • Fit the extension pieces into the existing spacers. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 42 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 37……cont If the chair has a reclining backrest. • Fit the extension pieces into the existing spacers and tighten with a 10mm spanner CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 43 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 38 If the chair has a reclining backrest. • Re-fit the backpack mounting plate CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
  • Page 44 OMNI 2 – ZIPPIE SALSA HOTSEAT RETRO FITTING HELP GUIDE Step 38……cont If the chair has a reclining backrest. • Re-fit the backpack mounting plate. You can now mount the backpack in the same way as before. CONFIDENTIAL: For internal use only. CONFIDENTIAL: For internal use only.
