- Page 1 Owners Guide Sentinel 0-4-0 Steam Shunter O Gauge Model Owner’s manual P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019...
- Page 2 Sentinel 0-4-0 Steam Shunter P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019...
-
Page 3: Table Of Contents
Owners Guide Table of Contents Section A: All versions and quick start...... 4 Running in / First use........... 4 Couplings ............. 5 Removing the body ..........5 Fitting a DCC decoder .......... 6 Programming your decoder ......... 6 Fitting a speaker........... -
Page 4: Section A: All Versions And Quick Start
Sentinel 0-4-0 Steam Shunter Thank you for purchasing this Dapol Model Section A: All versions and quick start. This section is applicable to all versions including those with factory fitted DCC. Quick start: We know you would like to have your model running as quickly as possible;... -
Page 5: Couplings
Owners Guide 2. Couplings: Prototypical 3-link couplings are fitted as standard and are designed to use the coupling hook of the rolling stock to be attached. 3. Removing the body: (For DCC fitting instructions, please read paragraph 4, page 6). Info: It is not necessary to remove the body to install a DCC Decoder. -
Page 6: Fitting A Dcc Decoder
Sentinel 0-4-0 Steam Shunter 4. Fitting a DCC decoder: The model requires a 21-pin decoder with a minimum of 2 functions. (4 or 6 function decoders may also be used). Regardless of the type, fitting remains the same. After fitting a sound decoder, please read paragraph 6, fitting a speaker. -
Page 7: Maintenance
Owners Guide c. Solder the speaker leads to the PCB, if + & - are not marked on your speaker it is not important which polarity is used. d. The design allows a 23mm diameter speaker (DCC Supplies part:110100) to fit into the base of the boiler, other sizes will require alternative fitting methods. -
Page 8: Spare Parts
Sentinel 0-4-0 Steam Shunter 8. Spare parts: Refer to Section D, pages 11 to 14 for exploded views and parts list. 9. Warranty: Details are in Section E. Page 15. Section B Factory Fitted DCC 1. DCC Address: The model is factory set to address 3. -
Page 9: Table Of Manual Sounds
Owners Guide Manual sounds Comments Simulate the effect of going into the Sound fade distance. On entering the scenic section, this in/fade out can be used to fade the sound back in. Whistle 1 Whistle 2 Coal The coal shovelling will continue until F4 is shovelling turned off. -
Page 10: Table Of Automatic Sounds
Sentinel 0-4-0 Steam Shunter Automatic functions Comments Draincocks when Operates as speed increases from 0 AND the starting off. locomotive has been static over 25 seconds Heard when the speed of the locomotive drops below the threshold AND the locomotive is Brake squeal decelerating. -
Page 11: Section D: Parts View
Sentinel 0-4-0 Steam Shunter Section D: Parts view 11 | P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019... - Page 12 Owners Guide 12 | P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019...
- Page 13 Sentinel 0-4-0 Steam Shunter 13 | P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019...
- Page 14 Owners Guide Due to variances between liveries and original equipment not all spares are available for every livery. Please quote the part number of the model to ensure you receive correctly decorated parts. Part Part Description Number Bunker deck 114626 Chimney and rain flap 114627 Body shell assembly...
-
Page 15: Section E: Manufacturer's Warranty
Dapol. For these reasons, we offer a 12- month manufacturer’s repair warranty on this product in addition to your statutory rights. -
Page 16: How To Claim
Owners Guide purchase. Without this, our service agents are (Cont.) unable to offer warranty service. Repairs will be charged at the prevailing rate. Your statutory rights with the place of purchase are unaffected. How to claim: • Locate the proof of purchase (copies acceptable) •... -
Page 17: Terms And Conditions
Requests for outright refund or replacement should be directed to the place of purchase. 3. In the event the model cannot be repaired, at Dapol’s sole option, you may be offered: a new replacement model (subject to availability), a refund voucher (for exchange at the place of purchase) or the return of the locomotive in an unrepaired condition. - Page 18 9. Dapol and its agents shall be the sole arbiters as to the warranty status of the model and their decision is final. 10. Whilst every effort will be made to protect such, Dapol and its agents shall not be liable for damage or alteration to any ‘super detailing’...
- Page 19 19 | P a g e Sentinel 0-4-0 Owners Guide. V 1.0 15-06-2019...
- Page 20 Dapol Limited. Unit 7 Gledrid Industrial Park, Chirk, Wrexham LL14 5DG Telephone: 01691 774455 Website: www.dapol.co.uk Email: sales@dapol.co.uk...
