Summary of Contents for DAPOL O Gauge Austerity / J94 0-6-0
- Page 1 O Gauge Austerity / J94 0-6-0 Front Cover—Insert 0-6-0 Austerity/J94 Locomotive O Gauge Model Owner’s Manual Authentic Scale Model 1:43.5...
-
Page 2: Table Of Contents
O Gauge Austerity / J94 0-6-0 Contents A history of the Austerity / J94 ......3 Model specifications / quick start ...... 4 Unboxing / Operation ........5 Maintenance ............. 6 Installing DCC decoder (DCC Ready) ..... 8 Speaker installation ......... 9 DCC/DCC Sound factory fitted models .. -
Page 3: A History Of The Austerity / J94
O Gauge Austerity / J94 0-6-0 Thank you for purchasing this Dapol product. We hope it gives you many years of enjoyment A history of the Austerity / J94 On the 1st January 1943 the first of a new class of locomotive left the Hunslet Engine Company works in Leeds, the 'Austerity' 0-6-0ST. -
Page 4: Model Specifications / Quick Start
O Gauge Austerity / J94 0-6-0 Model Specification Firebox glow • Five pole skew wound motor with flywheel • vertically mounted in the firebox Slide in PCB accessed through the hinged • smokebox door DCC Ready with 21 pin DCC decoder socket. -
Page 5: Unboxing / Operation
O Gauge Austerity / J94 0-6-0 Unboxing 1) Carefully remove the model whilst attached to its acrylic plinth from the foam insert. 2) Remove the two screws securing the locomotive to the acrylic plinth. Ensure the locomotive is suitably cradled while removing screws to avoid damage. -
Page 6: Maintenance
(DC) and DCC layouts. DCC address is factory set to address #3. The sound decoder fitted is a MS440D Zimo or a Dapol imperium for DCC fitted versions. If operating a DCC fitted model on DC, please follow the DC operating procedure for your decoder. - Page 7 O Gauge Austerity / J94 0-6-0 • To lubricate the worm gear, you will need to remove the brake rodding. Remove the 6 keeper plate cover screws (shown below in yellow). • Unclip brake rodding from brake shaft as shown below. Care should be taken when lifting the keeper plate past the guard irons - this is a tight fit.
-
Page 8: Installing Dcc Decoder (Dcc Ready)
3 functions in order for the firebox flicker to operate. (This is controlled by the AUX 1 output of the decoder). The model is fitted with Dapol’s tool-less DCC and speaker fitting system. To install a decoder and/or optional speakers (2) follow these steps:... -
Page 9: Speaker Installation
O Gauge Austerity / J94 0-6-0 When the PCB is fully removed from the smokebox the decoder blanking plate can be removed in the usual way and replaced with the decoder of your choice Speaker Installation If using a sound decoder two 8-ohm ‘Sugar cube’... -
Page 10: Dcc/Dcc Sound Factory Fitted Models
O Gauge Austerity / J94 0-6-0 The speaker enclosures are removed by un-clipping (They are each held by 2 clips). Drop the sugarcube speaker into the enclosure with speaker contacts uppermost and orientated to match the location of the silver contact areas on the... -
Page 11: Dcc Sound Function Key Summary
O Gauge Austerity / J94 0-6-0 Function key summary (Manual sounds): F1 Sound fade in/out: Useful when loco is going ‘on or off scene’ or into / out of a tunnel. F2 Whistle 1 F3 Whistle 2 F4 Coal shovelling: The sound of the firebox door being opened is heard, followed by the fire- box flicker effect operating. - Page 12 O Gauge Austerity / J94 0-6-0 F12 Manual draincocks: Additional to the automatic draincocks, F12 enables the sound of steam ‘blast’ from the cylinder drains to be triggered. F13 Buffering up: Sound of buffers clashing. This can be ‘preselected’ whilst the loco is...
-
Page 13: Automatic Sounds / Cab Roof Removal
O Gauge Austerity / J94 0-6-0 F20: Passenger/freight train. This affects the sounds of the buffering up and the coupling/uncoupling sounds. With F20 ON, sounds appropriate to a passenger train are heard. With F20 OFF, sounds appropriate to a freight train are heard. -
Page 14: 'Realdrive
O Gauge Austerity / J94 0-6-0 ‘Realdrive’ A basic driving function is enabled by default. An advanced operation (‘Realdrive’) is possible which adds coasting and a working brake. This allows operation in a more prototypical manner. Brake applications will be needed to bring the model to a stop –... -
Page 15: Spare Parts
To operate a consist using ‘RealDrive’ and avoid difficulties, all locomotives consisted must have ‘RealDrive’ activated. Spare parts A range of spare parts is available for this model on launch. Please refer to the Dapol website for availability. -
Page 16: Manufacturer Warranty
If a replacement model is not available you may find a refund disappointing, or you may simply prefer to deal directly with Dapol. For these reasons, we offer a 12-month manufactur- er’s repair warranty on this product in addition to your statutory rights. - Page 17 O Gauge Austerity / J94 0-6-0 VERY IMPORTANT: Please ensure that your dealer has supplied a proper printed receipt with your purchase. Without this, our service agents are unable to offer warranty service. Repairs will be charged at the prevailing rate. Your statutory rights with the place of purchase are unaffected.
- Page 18 Requests for outright refund or replacement should be directed to the place of purchase. 3) In the event the model cannot be repaired, at Dapol’s sole option, you may be offered: a replacement model (subject...
- Page 19 9) Dapol and its agents shall be the sole arbiters as to the warranty status of the model and their decision is final. 10)Whilst every effort will be made to protect such, Dapol and its agents shall not be liable for damage or alteration to any ‘super...
- Page 20 O Gauge Austerity / J94 0-6-0 12) Dapol and its agents shall not be held liable for models lost in the post unless a proof of posting can be supplied. 13) All repairs will be repaired on a first in-first out basis, within a reasonable period after receipt by our agent.
-
Page 21: Notes
O Gauge Austerity / J94 0-6-0 NOTES: This page is left blank to write your own notes... - Page 22 O Gauge Austerity / J94 0-6-0 NOTES: This page is left blank to write your own notes...
-
Page 23: Contact Information
O Gauge Austerity / J94 0-6-0 Contact Information Dapol Customer Service Telephone: 01691 774455 E-Mail sales@dapol.co.uk Website www.dapol.co.uk Service Centre DCC Supplies Ltd Telephone: 01905 621999 Email: dapol@dccsupplies.com... - Page 24 O Gauge Austerity / J94 0-6-0 Back Cover—Insert Dapol Limited Unit 7 Gledrid Industrial Park, Chirk, Wrexham, LL14 5DG Telephone: 01691 774455 Website: www.dapol.co.uk Email: sales@dapol.co.uk...
