Summary of Contents for DAPOL GWR Streamlined Railcar
- Page 1 Introduction GWR Streamlined Railcar O Gauge Model Owner’s manual...
-
Page 2: Table Of Contents
Contents A history of the GWR Streamlined railcar ..1 Specification: ............2 Build lots ............. 2 Unboxing ............3 Accessory pack ........... 3 Operation: ............4 Running in / First use .......... 4 DCC address ............4 Factory decoder fitted........4 Maintenance ............ -
Page 3: A History Of The Gwr Streamlined Railcar
(without buffet). Numbers 8 to 16 were constructed in 1936. Cars 10,11 & 12 which were fitted with a toilet. This is the version that the Dapol model is based on Operating within the Western region, it was to be... -
Page 4: Specification
DCC and DC controlled lighting (DC via switches) • Interchangeable tail lamp (where appropriate) • Operating interior lighting • Operating Reading lamps Dapol are producing models from the following build lots (at the time of writing) Date built Lot number Loco Numbers 1936 1547 8 &... -
Page 5: Quick Start
Quick start Please read this section before you go any further! Quick start: We know you would like to have your model running as quickly as possible; please spare a moment to read this section first. • Models fitted with optional DCC or DCC sound will operate on DC or DCC* * When operating on DC, the sound fitted model will produce engine... -
Page 6: Operation
DCC address is factory set to address #3. The sound decoder fitted is a Zimo MX644C or a Dapol imperium for DCC fitted versions. If operating a DCC fitted model on DC, please follow the DC operating procedure for your decoder. -
Page 7: Maintenance
GWR Streamlined Railcar Maintenance The model uses components which require little maintenance. We suggest that the drive train and gear box are lubricated after every 100 hours running using a light synthetic lubricating oil such as Dapoil or Locolube™ Warning:... -
Page 8: Fitting Accessory Items
Remember to remove the lamp prior to repacking in foam tray. Installing a DCC decoder (DCC Ready) Dapol recommend a Dapol Imperium decoder. The decoder requires six functions to fully operate the lighting : • External lamps •... - Page 9 GWR Streamlined Railcar 1) Remove the 2 screws fastening the hatch on the base of the model. 2) The hatch can then be removed by pivoting upwards from the screw end. 3) Remove the DC ‘blanking plate’ which is fitted to the model and 4) Replace with the decoder of your choice.
-
Page 10: Dc Operation Of Lighting Features
GWR Streamlined Railcar DC operation of lighting features. A block of switches are located on the underside of the model. These will disable (turn off) various lighting features when in the OFF position: • SW1 – Express lighting • SW2 – Interior saloon lights •... -
Page 11: Dcc Sound Factory Fitted Models
GWR Streamlined Railcar Parts DCC Sound Factory Fitted models This model is pre-fitted with a Zimo sound decoder and speaker. Sounds are recorded as both manual and automatic sounds. Manual sounds are operated by the following keys on your DCC controller. - Page 12 GWR Streamlined Railcar On pressing F6 (F6 ON), the Guard-to- Communicat driver communication bell is heard. If ion bells pressed again (F6 OFF), the sound of the driver's response bell is heard. When F7 is pressed, a brake application sound will be heard.
- Page 13 GWR Streamlined Railcar used when the Railcar is arriving 'on- scene' or exiting a tunnel. Single On pressing F13, the sound of a high electric horn electric horn will be heard. Single On pressing F14, the sound of a low electric horn electric horn will be heard.
-
Page 14: Body Removal
GWR Streamlined Railcar Body removal Body removal is not required for DCC decoder or speaker installation. Caution: Dapol do not recommend disassembly, care should be taken to avoid damage to delicate assemblies and detail parts. 1. Remove the 4 retaining screws (located at each end of the railcar, behind the oil cooler matrix. -
Page 15: Spare Parts
GWR Streamlined Railcar Spare parts At the time of release there is a comprehensive list of spare parts, which will include at least the parts below: Please contact our spares and service agents DCC supplies Ltd. at dapolspares.dccsupplies.com Main PCB... -
Page 16: Manufacturer's Warranty
Dapol. For these reasons, we offer a 12-month manufacturer’s repair warranty on this product in addition to your statutory rights. - Page 17 VERY IMPORTANT: Please ensure that your dealer has supplied a proper printed receipt with your purchase. Without this, our service agents are unable to offer warranty service. Repairs will be charged at the prevailing rate. Your statutory rights with the place of purchase are unaffected. How to claim: •...
-
Page 18: Warranty: Terms And Conditions
Requests for outright refund or replacement should be directed to the place of purchase. 3. In the event the model cannot be repaired, at Dapol’s sole option, you may be offered: a new replacement model (subject to availability), a refund voucher (for exchange at the place of purchase) or the return of the model in an unrepaired condition. - Page 19 9. Dapol and its agents shall be the sole arbiters as to the warranty status of the model and their decision is final. 10. Whilst every effort will be made to protect such, Dapol and its agents shall not be liable for damage or alteration to any ‘super detailing’...
- Page 20 Dapol Limited. Unit 7 Gledrid Industrial Park, Chirk, Wrexham LL14 5DG Telephone: 01691 774455 Website: www.dapol.co.uk Email: sales@dapol.co.uk Spares: dapolspares.dccsupplies.com...
