Model 615 Cable Reel Roller
with VFD
Operating, Maintenance, Safety
and Parts Manual
08/24
Read and understand this material before operating
or servicing the Cable Reel Roller. Failure to
understand how to safely operate and service this
unit may result in serious injury or death.
This manual is free of charge. All personnel who operate the Cable Reel Roller
should have a copy of this manual and read and understand its contents. To
request a copy, call or write to the address below. All information, specifications
and product designs may change due to design improvements or updates and
are subject to change without notice. Current Tools does not assume any liability
for damages resulting from misuse or incorrect application of its products.
CURRENT TOOLS • P . O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864-721-4230 • FAX 864-721-4232
www.currenttools.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Current Tools 615
Summary of Contents for Current Tools 615
- Page 1 All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Current Tools does not assume any liability for damages resulting from misuse or incorrect application of its products.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Specifications &... -
Page 3: Specifications & Features
SPECIFICATIONS width — 122" 8' diameter maximum reel size — 96" width, 15 tons ⁄ length — 60 " power height — 19" requirement — 115 volts, 20 amps weight — 2,800 lbs. FEATURES • Speed control for variable • Rugged and durable •... -
Page 4: Remote Control Pedestal
REMOTE CONTROL PEDESTAL POWER / STATUS INDICATOR ROLLER SPEED CONTROL FORWARD / REVERSE SWITCH FOOT SWITCH MAINTENANCE • DO NOT store the cable reel roller in wet or damp locations. • Grease the pillow block bearings every 20 hours of operation with a good quality multi-purpose (MP) grease. -
Page 6: Exploded View - Frame And Rollers
EXPLODED VIEW — MODEL 615 FRAME AND ROLLERS ITEM REMOTE CONTROL PEDESTAL STORAGE TRAY... -
Page 7: Parts List - Frame And Rollers
PARTS LIST — MODEL 615 FRAME AND ROLLERS ITEM PART NUMBER DESCRIPTION QTY. 33-53 SCREW-HEX HEAD CAP GR5 ZINC (3/8-16 X3/4) 33BAT-005 NUT- HEX NYLON INSERT THIN (#10-24) 450-14I WASHER-FLAT ZINC 1/4"(USS) 506-3 WASHER-FLAT 3/8 (USS) ZINC 615-024 SCREW - SHOULDER SOCKET (1/4" X 5/16") -
Page 8: Exploded View - Motor/Gearbox Mount
EXPLODED VIEW — 615-640 MOTOR REPLACEMENT KIT TOP TWO ONLY TOP TWO ONLY BOTTOM TWO ONLY BOTTOM TWO ONLY MOUNTED VIEW MOUNTED VIEW PARTS LIST — 615-640 MOTOR REPLACEMENT KIT ITEM PART NUMBER DESCRIPTION QTY. ITEM 615-644 MOTOR/GEARBOX ASSEMBLY - VFD... -
Page 9: Exploded View And Parts List - Motor Assembly
EXPLODED VIEW — 615-644 MOTOR ASSEMBLY KEY INCLUDED KEY INCLUDED WITH MOTOR WITH GEARBOX BOLTS INCLUDED WITH GEARBOX PARTS LIST — 615-644 MOTOR ASSEMBLY ITEM PART NUMBE ESCRIPTION QTY. 615-642 GEARBO 615-641 MOTO 615-643 SPROCKET - D40B14 615-016 .281" X 1.5OD FENDER WASHER... -
Page 10: Exploded View And Parts List - Remote Pedestal (Front)
CONTROL PEDESTAL HOUSING 9518SR-12 NUT-HEX NYLON INSERT (1/4-20) 615-013 SCREW-FLAT SOCKET (1/4-20 X 1") 615-012 CORD GRIP 615-011 FOOT CONTROL 77-033A SCREW-HEX HEAD (#10-32 x 1/2) 615-612 BENT CONTROL PEDESTAL COVER 615-613 VFD ASSEMBLY 615-020 FUSE — 25A (INTERNAL — NOT SHOWN) -
Page 11: Exploded View And Parts List - Remote Pedestal (Back)
PART NUMBER DESCRIPTION QTY. 33BAT-005 NUT- HEX NYLON INSERT THIN (#10-24) 450-14J WASHER-FLAT SAE #10 453-16A NUT-HEX ZINC (#8-32) 615-010 CORD GRIP 615-019 CORD CLAMP 615-029 SCREW - HEX HEAD CAP ZINC (#10-24 X 5/8") 615-622 COVER - ELECTRICAL 747-39 WASHER, LOCK - #8 EXT.
