Current Tools 615 Operating, Maintenance, Safety And Parts Manual

Cable reel roller with 615-113 motor

Advertisement

Quick Links

Model 615 Cable Reel Roller
with 615-113 Motor
Operating, Maintenance, Safety
and Parts Manual
04/22
Read and understand this material before operating
or servicing the Cable Reel Roller. Failure to
understand how to safely operate and service this
unit may result in serious injury or death.
This manual is free of charge. All personnel who operate the Cable Reel Roller
should have a copy of this manual and read and understand its contents. To
request a copy, call or write to the address below. All information, specifications
and product designs may change due to design improvements or updates and
are subject to change without notice. Current Tools does not assume any liability
for damages resulting from misuse or incorrect application of its products.
CURRENT TOOLS • P . O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864-721-4230 • FAX 864-721-4232
www.currenttools.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 615 and is the answer not in the manual?

Questions and answers

Summary of Contents for Current Tools 615

  • Page 1 All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Current Tools does not assume any liability for damages resulting from misuse or incorrect application of its products.
  • Page 2 615-255 Motor Assembly Exploded View and Parts List . . . . . . . . . . . . . . . .
  • Page 3 SPECIFICATIONS width — 122" 12' diameter maximum reel size — 96" width, 15 tons ⁄ length — 60 " motor specs — 120 volts, 11.5 amps height — 19" weight — 2,800 lbs. FEATURES • Speed control for variable • Rugged and durable •...
  • Page 4 615-255 MOTOR ASSEMBLY EXPLODED VIEW (WITH 615-113 MOTOR) 615 255 ASSEMBLED VIEW SHOWN OUTSIDE OF MOUNTING LOCATION ON 615 FRAME 615-255 MOTOR ASSEMBLY PARTS LIST (WITH 615-113 MOTOR) ITEM # PART # DESCRIPTION QTY. 615-113 4262 MOTOR WITH SPROCKET 615-252 ADJUSTING PLATE –...
  • Page 5 2. Install new adjusting plate into the opening such that the four motor mounting screw slots are accessible 3. Insert the new motor (Part #615-113) into the adjusting plate and fasten as shown. Connect the ground wire from the motor to the...
  • Page 6 615-255 MOTOR ASSEMBLY INSTALLATION (WITH 615-113 MOTOR) — CONTINUED 4. Hang the adjusting plate by the Jack Screw (#3). Loosely fit the four plate mounting screws (#8) into the corner slots in the adjusting plate as shown. Be sure to use the two thicker washers (#11) with the two lower mounting holes.
  • Page 7 • Lubricate drive chain every 20 hours of operation with 90W gear oil. • Before each use, inspect power and control cords for damage. • Inspect drive chain for wear every 40 hours of operation. WIRING SCHEMATIC 615-113 MOTOR (MILWAUKEE #4262)
  • Page 9 EXPLODED VIEW — MODEL 615 FRAME AND ROLLERS 615 255 615-255 MOTOR ASSEMBLY (MILWAUKEE #4262) ASSEMBLED VIEW (SEE EXPLODED VIEW AND PARTS LISTS ON PAGE 4) SHOWN OUTSIDE OF MOUNTING LOCATION ON 615 FRAME PARTS LIST — MODEL 615 FRAME AND ROLLERS...
  • Page 10 MAJOR COMPONENTS — MODEL 615 REEL ROLLER PARTS LIST — MODEL 615 FRAME AND ROLLERS ITEM # PART # DESCRIPTION QTY. 615-113 MOTOR ASSEMBLY 615-1B SPROCKET 615-4 PLUG, MALE TWIST LOCK 615-6A – KNOB SPEED CONTROL KNOB 615-6A SPEED CONTROL...
