Model 66 Cable Puller with
4 Wheel Mobile Carriage
Operating, Maintenance, Safety
and Parts Manual
This manual is free of charge. All personnel who operate the Cable
Puller should have a copy of this manual and read and understand
its contents. To request a copy of this manual or replacement safety
decals, or for technical assistance, call or write to the address below.
CURRENT TOOLS • P. O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864.721-4230 • FAX 864.721-4232
Read and understand this material before
operating or servicing the Cable Puller. Failure
to understand how to safely operate and service
this unit may result in serious injury or death.
www.currenttools.com
2/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 66 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Current Tools 66

Summary of Contents for Current Tools 66

  • Page 1 To request a copy of this manual or replacement safety decals, or for technical assistance, call or write to the address below. CURRENT TOOLS • P. O. BOX 17026 GREENVILLE, SC 29606 800.230.5421 or 864.721-4230 • FAX 864.721-4232...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safety Information .

  • Page 3: Safety Alerts

    SAFETY ALERTS Safety Alert Symbol THIS SAFETY SYMBOL is used to call your attention to instructions that concern your personal safety. It means: ATTENTION! BE AWARE! THIS IS AN IMPORTANT SAFETY INSTRUCTION! Read, understand and follow these safety instructions. Failure to follow these safety instructions may result in injury or death.

  • Page 4: Important Safety Information

    CAUTION WARNING ALWAYS disconnect cable puller before servicing. CAUTION WARNING ALWAYS plug the Model 66 Cable Puller into a grounded DANGER CAUTION receptacle with a 15 amp GFCI protected circuit. DO NOT CAUTION modify the plug provided with the Model 66 Cable Puller.

  • Page 5: Important Safety Information

    DANGER IMPORTANT SAFETY INFORMATION continued DANGER ⁄ WARNING ONLY use " or larger double-braided composite pulling rope, or a pulling rope with a average breaking strength of 26,000 lbs. WARNING NEVER allow the rope to slip on a rotating capstan for more DANGER CAUTION than a couple of seconds.

  • Page 6: Specifications

    SPECIFICATIONS model no. — 66 Cable Puller mounted on 4 Wheel Carriage width — 25" depth — 42" height — 46" fully extended length — 93" weight — 190 lbs. – Cable puller mounted on 4 wheel carriage maximum pulling force — 6,000 lbs.

  • Page 7: Set-Up And Operating Instructions

    SET-UP AND OPERATING INSTRUCTIONS Adjustable boom Model 66 Cable Puller shown pinned for transport on 4 wheel mobile carriage. Extension From the transport position, Remove the puller mount locking remove the extension arm locking retainer pin. retainer pin. With the swivel casters brakes disengaged,...
  • Page 8 SET-UP AND OPERATING INSTRUCTIONS continued Next, to position the adjustable boom to the desired length for the pull, remove the locking retainer pin that goes through the adjustable boom and re-pin at the desired length, making sure to Raise the boom to a comfortable secure the pin with attached clip.
  • Page 9 SET-UP AND OPERATING INSTRUCTIONS continued The standard couplings for the model # 66 puller are stored on the puller frame. Choose the correct size coupling for the conduit you are pulling in and insert into the coupling adapter by pushing the receiver plate of the coupling into the coupling adapter until the spring loaded pawl "snaps"...
  • Page 10 NOTE: The Model 66 puller can be Puller disassembled from, 66 puller shown in mount...

  • Page 11: Common Set-Ups

    COMMON SET-UPS UP PULL DOWN PULL DANGER DANGER WARNING NEVER allow the rope to slip on a WARNING DO NOT allow the rope to overlap on DANGER rotating capstan for more than a couple of seconds. the capstan. If this condition begins to occur, DANGER The rope will wear in that spot and the rope could immediately release the tailing force on the rope.

  • Page 12: Maintenance

    Replace the capstan if it is grooved more than ⁄ " deep. Gear Box The Model 66 Cable Puller has a vent-free gear box and is factory lubricated for life with synthetic, semi-fluid gear lubricant with an operating range of +5˚F to +220˚F.

  • Page 13: Exploded View

    EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — 4 WHEEL CARRIAGE BOOM TRANSPORT HOLE PARTS LIST — 4 WHEEL CARRIAGE ITEM # PART # DESCRIPTION QTY. 452-27 WASHER–LOCK MEDIUM 3/8 ZINC 452-28 NUT–HEX ZINC (3/8-16) 506-3 WASHER–FLAT 3/8 (USS) ZINC 524-11 3/8-16 ×...
  • Page 14 EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — GEAR ASSEMBLY EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — DRIVE ASSEMBLY...

  • Page 15: Exploded View

    EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — BOOM ASSEMBLY...
  • Page 16 PARTS LIST — 66 CABLE PULLER ITEM # PART # DESCRIPTION QTY. 2-1301-4 NUT–HEX NYLON INSERT (5/16"-18) 2-1501-4 NUT–HEX NYLON INSERT (3/8-16) 280-8B RING–RETAINING H.D. EXT (1.5) 33-1 MOTOR 33-12 PIN–ROLL, 3/16 × 1-7/8 33-19 RING–RETAINING 3/8 EXTERNAL 33-24 PIN 5/8" CLEVIS...

  • Page 17: Wiring Drawing

    PARTS LIST — 66 CABLE PULLER ( CONTINUED) 66-663 MOTOR SPACER ITEM # PART # DESCRIPTION QTY. 66-684 PIN–66 PULLER 66-685 HI/LO WELDMENT 66-695 BRACKET FAB–SWITCH 66-742 HI/LO SWITCH 66-76 WASHER–FLAT 7/16" (SAE) 66-971 LOWER TUBE WELDMENT 77-017A WASHER–FLAT SAE ZINC (1/2) 77-035A ROLL PIN 1/8 ×...
