Model 11 High Speed Cable Puller
Operating, Maintenance, Safety
This manual is free of charge. All personnel who operate the Cable Puller should have a copy of this manual and
read and understand its contents. To request a copy of this manual or replacement safety decals, or for technical
assistance, call or write to the address below. All information, specifications and product designs may change
due to design improvements or updates and are subject to change without notice. Current Tools does not
assume any liability for damages resulting from misuse or incorrect application of its products.
CURRENT TOOLS • P . O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864.721.4230 • FAX 864.721.4232
and Parts Manual
Read and understand this material before
operating or servicing the Cable Puller. Failure
to understand how to safely operate and service
this unit may result in serious injury or death.
www.currenttools.com
6/2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the 11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Current Tools 11

Summary of Contents for Current Tools 11

  • Page 1 All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Current Tools does not assume any liability for damages resulting from misuse or incorrect application of its products.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safety Information .

  • Page 3: Safety Alerts

    SAFETY ALERTS Safety Alert Symbol THIS SAFETY SYMBOL is used to call your attention to instructions that concern your personal safety. It means: ATTENTION! BE AWARE! THIS IS AN IMPORTANT SAFETY INSTRUCTION! Read, understand and follow these safety instructions. Failure to follow these safety instructions may result in injury or death.

  • Page 4: Important Safety Information

    RETAIN SAFETY INFORMATION This manual should be read and understood by all personnel who operate or service this Cable Puller. Failure to understand how to safely operate and service this equipment could result in injury or death. This equipment should only be operated and serviced by qualified personnel. IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION DANGER...
  • Page 5 DANGER IMPORTANT SAFETY INFORMATION continued WARNING ALWAYS inspect pins to be sure they are fully inserted through DANGER holes and their detent balls are working. DO NOT substitute any other object for factory supplied pins. CAUTION DANGER WARNING When making a vertical cable pull, keep the area underneath the cable pull clear of all personnel.

  • Page 6: Specifications

    SPECIFICATIONS Model no. — 11 Width — 10" Height — 14.5" Fully extended length — 55" Retracted length — 37.25" Weight — 16 lbs. – puller only (no drill) Maximum pulling force — 1,000 lbs. Conduit size range — 1/2"– 4"...
  • Page 7 FEATURES — CONTINUED Multi-position Coupling Head Adjustable Length Inner Boom Tube Handle Assembly Maintenance Free Gearbox Drill Bracket Capstan Cap and Knob Wing Screws Drill Attachment Strap NOTE: See exploded view and parts list on pages 18 & 19 for detailed breakdown.
  • Page 8 DANGER SET-UP AND OPERATING INSTRUCTIONS ATTACHING CORDLESS DRILL TO PULLER Drill attachment strap must be properly WARNING used during operation. Failure to observe this warning could result in injury. 1. Loosen the wing screws and drill attachment strap on the adjustable drill bracket.

  • Page 9: Set-Up And Operating Instructions

    SET-UP AND OPERATING INSTRUCTIONS — CONTINUED 3. Slide the adjustable drill bracket towards the cordless drill until the bracket is snug against the drill. Tighten the bracket wing screws. Wing Screws 4. Wrap the drill attachment strap around the drill and secure by inserting the strap through the buckle and pull to tighten.
  • Page 10 SET-UP AND OPERATING INSTRUCTIONS — CONTINUED Drill Attached to Puller and Ready for Pull...
  • Page 11 CONTINUED COUPLING HEAD INSTALLATION AND OPERATION NOTE: The coupling head on the Model 11 Puller has numerous adjustment positions to allow for the proper angle of engagement to the conduit. To obtain the proper angle, pull the spring loaded retainer pin on the coupling head and adjust the angle of the engagement slot as required.
  • Page 12 SET-UP AND OPERATING INSTRUCTIONS — CONTINUED 1. The coupling head is secured to the adjustable boom tube with a bolt and should not be removed. 2. To set up the inner boom tube for the type of pull (up, down or side), remove the boom tube detent pin and remove the inner boom tube.
  • Page 13 SET-UP AND OPERATING INSTRUCTIONS — CONTINUED PULLING CABLE NOTE: The following instructions should be referred to when using polyester measuring/pulling tape (mule tape) or conduit measuring tape that is approved for cable pulling. These are referred to below as “pulling line’’. 1.
  • Page 14 SET-UP AND OPERATING INSTRUCTIONS — CONTINUED 2. If necessary, adjust the boom length and the position of the coupling head to ensure that the coupling head engagement slot is fully seated on the lip of the conduit. 3. If pulling cable, set the cordless drill direction to FORWARD or CLOCKWISE and the speed to low.
  • Page 15 PULLING CABLE — continued NOTE: The following instructions should be referred to when using approved pulling rope on the Model #11 puller. 1. If necessary, adjust the boom length and the position of the coupling head to ensure that the coupling head engagement slot is fully seated on the lip of the conduit.
  • Page 16 SET-UP AND OPERATING INSTRUCTIONS — CONTINUED OPTIONAL: Mounting a stabilizing leg 1. Cut a piece of 1/2" Rigid conduit to your desired length. One end of the conduit must be threaded. 2. Screw the piece of 1/2" Rigid conduit into the adapter coupling, ensuring full thread engagement.

  • Page 17: Common Set-Ups

    COMMON SET-UPS UP PULL DOWN PULL SIDE PULL...

  • Page 18: Exploded View

    EXPLODED VIEW — MODEL 11 CABLE PULLER...

  • Page 19: Parts List

    PARTS LIST — MODEL 11 CABLE PULLER ITEM PART NUMBER DESCRIPTION QTY. 11-001 GEARBOX 11-005 CAPSTAN 11-006 CAPSTAN END PLATE 11-008 RELEASE KNOB (3/8" × 1.5") 11-003 DRIVE SHAFT 11-007 DOWEL PIN (1/4" OD × 1/2") 11-134 KEY STOCK - 3/16" X 3/16" × 1/2"...
