Current Tools 66 Cable Puller Operating, Maintenance, Safety And Parts Manual

Cable puller with mobile cart
Hide thumbs Also See for 66 Cable Puller:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating, Maintenance, Safety and Parts Manual
Model 66 Cable Puller with Mobile Cart
Operating, Maintenance, Safety
This manual is free of charge. All personnel who operate the Cable
Puller should have a copy of this manual and read and understand
its contents. To request a copy of this manual or replacement safety
decals, or for technical assistance, call or write to the address below.
CURRENT TOOLS • P. O. BOX 17026 GREENVILLE, SC 29606
800.230.5421 or 864.721-4230 • FAX 864.721-4232
and Parts Manual
Read and understand this material before
operating or servicing the Cable Puller. Failure
to understand how to safely operate and service
this unit may result in serious injury or death.
www.currenttools.com
1/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 66 Cable Puller and is the answer not in the manual?

Questions and answers

Related Manuals for Current Tools 66 Cable Puller

Summary of Contents for Current Tools 66 Cable Puller

  • Page 1 To request a copy of this manual or replacement safety decals, or for technical assistance, call or write to the address below. CURRENT TOOLS • P. O. BOX 17026 GREENVILLE, SC 29606 800.230.5421 or 864.721-4230 • FAX 864.721-4232...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safety Information .

  • Page 3: Safety Alerts

    SAFETY ALERTS Safety Alert Symbol THIS SAFETY SYMBOL is used to call your attention to instructions that concern your personal safety. It means: ATTENTION! BE AWARE! THIS IS AN IMPORTANT SAFETY INSTRUCTION! Read, understand and follow these safety instructions. Failure to follow these safety instructions may result in injury or death.

  • Page 4: Important Safety Information

    CAUTION WARNING ALWAYS disconnect cable puller before servicing. CAUTION WARNING ALWAYS plug the Model 66 Cable Puller into a grounded DANGER CAUTION receptacle with a 15 amp GFCI protected circuit. DO NOT CAUTION modify the plug provided with the Model 66 Cable Puller.

  • Page 5: Important Safety Information

    DANGER IMPORTANT SAFETY INFORMATION continued DANGER ⁄ WARNING ONLY use " or larger double-braided composite pulling rope with an average breaking strength of 26,000 lbs. WARNING NEVER allow the rope to slip on a rotating capstan for more DANGER CAUTION than a couple of seconds.

  • Page 6: Specifications

    SPECIFICATIONS model no. — 66 Cable Puller (mounted on Mobile Cart) ⁄ width — 24 " depth — 18" height — 49" fully extended length — 102" weight — 115 lbs. – (cable puller only) — 179 lbs. – (cable puller mounted on mobile cart) maximum pulling force —...

  • Page 7: Set-Up And Operating Instructions

    Remove the transport pins to release the cable puller (photo 3) and boom section (photo 4) from the mobile cart. Model 66 Cable Puller shown pinned for transport on mobile cart. Turn the boom section in the direction needed for the type pull (UP or DOWN). See common setups on page 11.
  • Page 8 SET-UP AND OPERATION INSTRUCTIONS continued Adjust Boom section to desired length Next, to position the extension arm to and re-pin. the desired angle for the pull, remove the pin that allows the extension arm to be adjusted to various positions and re-pin at desired angle.
  • Page 9 SET-UP AND OPERATION INSTRUCTIONS continued Next, move the cable puller into position Operator may stand on either side of the and attach the extension arm onto the cable puller. Place the foot switch on the conduit coupling. You should hear a side the operator will be standing.
  • Page 10 SET-UP AND OPERATION INSTRUCTIONS continued Depress the foot switch and check the Next, turn the High/Low speed rotation of the capstan with the pulling switch to the desired position, “H” rotation decal on the cable puller. or “L”. When the pull is completed, pull the ring on the back of the extension arm to separate the conduit coupling from the extension arm.

  • Page 11: Common Set-Ups

    COMMON SET-UPS UP PULL DOWN PULL Example of extension arm adjusted to shorter length...

  • Page 12: Maintenance

    Replace the capstan if it is grooved more than ⁄ " deep. Gear Box The Model 66 Cable Puller has a vent-free gear box and is factory lubricated for life with synthetic, semi-fluid gear lubricant with an operating range of +5˚F to +220˚F.

  • Page 13: Exploded View

    EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — 66 CABLE PULLER ATTACHES BEHIND ITEM 16...

  • Page 14: Exploded View

    EXPLODED VIEW — 66 CABLE PULLER EXPLODED VIEW — 66 MOBILE CART 72,73,74...

  • Page 15: Parts List

    PARTS LIST — 66 CABLE PULLER 6000 LB PULLER ITEM # PARTS DESCRIPTION PART# 1 ............. MOTOR ..........1 ......33-1 2 ............GEAR BOX ..........1 ......66-2 3 ............. ADAPTER SHAFT ........1 .......33-460 4 ............. CAPSTAN SHAFT ........1 .......66-599 5 ............

  • Page 16: Wiring Drawing

    PARTS LIST — 66 CABLE PULLER continued 6000 LB PULLER ITEM # PARTS DESCRIPTION PART# ⁄ 52 ............COUPLING-2- " ........1 ......66-52 53 ............COUPLING-3" ......... 1 ......66-53 ⁄ 54 ............COUPLING-3- " ........1 ......66-54 55 ............COUPLING-4" ......... 1 ......66-55 56 ..............GRIP ..........
