UK
MANUAL
DENVER F6™ NEW PANEL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DENVER F6 NEW PANEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for decoflame DENVER F6 NEW PANEL

Summary of Contents for decoflame DENVER F6 NEW PANEL

  • Page 1 MANUAL DENVER F6™ NEW PANEL...

  • Page 2: Table Of Contents

    IT IS IMPERATIVE THAT YOU READ THE ENTIRE INSTALLATION AND OPERATING INSTRUCTIONS AND ADHERE TO THE SAFETY MEASURES DESCRIBED IN THIS DOCUMENT. DECOFLAME CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGE CAUSED AS A RESULT OF NON-ADHERANCE TO THESE INSTRUCTIONS. KEEP THE MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.

  • Page 3: Packaging

    1. PACKAGING Upon receiving the Fireplace, please notice following: case the fireplace will need to be returned to Decoflame for service The fireplace can be packed in: or repair. In the situation where the original packaging is not avai- A cardboard box with polystyrene inside and placed on a pallet.

  • Page 4: Content Of The Box

    Electronical Filling Pump 3. GENERAL INFORMATION All Decoflame fireplaces are designed, manufactured and quality-tested in Denmark with the highest product safety and user- friendliness in mind. Denver F6 with CEVB Technology (Controlled Ethanol Vapour Burning Technology) can be operated via control panel.

  • Page 5: Installation

    5. INSTALLATION Please refer to the detailed installation instructions provided with the technical drawing for the Decoflame bio fireplace. These instructions include all necessary dimensions and a step-by-step installation guide. Installation of the Decoflame bio fireplace should only be carried out after all construction and finishing work in the room has been completed to prevent damage to the fireplace, casing, or glass.

  • Page 6: Preperation Of Wall

    The 2 wall must be in level. All cross-measures must be at an angle. BURNER The cavity wall downwards (to the floor) must max. be 1000mm in depth - minimum 400mm. Urheberrecht Decoflame ApS.

  • Page 7: Recess In Cavity Wall

    90º degree angle. Use a spatula, metal or straightening rail to achieve straight edges on the hole. For specific dimensions, please refer to the detailed technical drawing from Decoflame. If in doubt, please contact your Decoflame Retailer or Decoflame.
  • Page 8 BURNER CAN BE USED IN DIFFERENT CONSTRUCTIONS E.G: Open to front Open to front and back Open to front and 1 side (Left/right) Open to frint, back, 1 side Standalone Open to front and (Left/right) both sides Urheberrecht Decoflame ApS.

  • Page 9: Placement Under Tv Screen

    NB: Placing TV screens or valuable paintings above the fireplace is NOT recommended, as the upward-drifting warm air may cause damage. For those intending to incorporate a TV screen above the fireplace, the instructions below should be followed, or further advice can be sought from Decoflame. ↕ Min. 800mm Min.

  • Page 10: Burner Installation Process

    Once the bio fireplace is positioned as desired, switch on the power connection using the button that unlocks the fuel cap. > STEP 4: Carefully install the glass screen(s) by inserting the glass holders into the holes in the top plate. Avoid scratching the top plate. Urheberrecht Decoflame ApS.

  • Page 11: Operating Instructions

    NOTE: Do not touch the glowing filament when switched on as it is hot. convenience and safety. During cleaning - do not touch it as it is extremely fragile. ONLY ADULTS MAY OPERATE THE ELECTRONICS OF THE DECOFLAME DENVER F6™. > SWITCH ON Switch on the power connection to your Denver F6TM by pressing the button.

  • Page 12: Operating Control Panel

    > BIOETHANOL (FUEL) Decoflame bio fireplaces are designed and manufactured exclusively for use with high alcohol bioethanol (96.5% to max 97.5%). DO NOT use any other fuel, other materials, lower quality bioethanol, or bioethanol containing oils and odours as this will void your warranty.
  • Page 13 HOW TO SET THE TIMER The fireplace has two ways to set the built-in timer. > THROUGH THE FIREPLACE DISPLAY: While the fireplace is in operation, follow the instructions below. - Navigate to the timer screen by pressing the left button on the remote control. - Select the desired time interval by pressing the up and down buttons while on the timer screen.

  • Page 14: Button Function

    - Long press: Not used. When the Increase flame level button is pressed and then released, the flame level by one step. This action is only performed if the button has been pressed for a short time. Urheberrecht Decoflame ApS.

  • Page 15: Troubleshooting

    A fault in one or more sensors that may affect the Contact your retailer to resolve the issue. system's ability to monitor and control safety and Sensor Error operation. For further information, please refer to the FAQ at www.decoflame.com...

  • Page 16: App Control

    6.4 APP CONTROL Download and install the Decoflame app that corre- sponds to your smart device operating system. For more information go to: decoflame.com 7. REMOTE CONTROL Remote control: Bluetooth Low Energy (BLE) On/Off START/STOP the burner. Set a timer for when the the fireplace should stop.

  • Page 17: Maintenance

    Before cleaning the fireplace, ensure it has cooled down and is completely switched off. The glass components of the Decoflame fireplace are made of tempered heat-resistant glass. These glass parts, along with any metal parts exposed to the heat of the fire, may slightly change color or structure. This is considered normal wear and tear and does not indicate a product flaw or fault.

  • Page 18: Emptying The Fuel Tank

    Only the vapour of the bioethanol burns. The bioethanol boils from 78°C (172.4°F) and the flash point is 13°C (55.4°F). The bioethanol vapours are heavier than air, so it will always remain on top of the surface of the liquid bioethanol. All Decoflame fireplaces can be operated only with bioethanol of at least 96.5% but not more than 97.5%.

  • Page 19: Symbols

    Specific wearing parts other than those mentioned, which deteriorate under normal use, are not covered. These parts require regular maintenance and replacement for optimal function. Reference is also made to Decoflame's General Terms and Conditions of Sale and Delivery and applicable co-operation agreements.
  • Page 20 Follow the Fire Authorities and national and local requirements regarding bioethanol fireplaces. Subject to glass and product tolerances, typographical errors and technical errors. Decoflame ApS reserves the right to make changes without notice. We refer to Decoflame’s General Terms of Sale and Delivery.
