- Page 1 MANUAL ESPOO FLOOR...
-
Page 3: Content Of The Box
DO NOT use a hammer or other hard objects. the fireplace will need to be returned to Decoflame for service or repair. In the situation where the original packaging is not available anymore, Deco- DO NOT use saws or other similar objects. -
Page 4: Table Of Contents
B1: Floor telescope B2: Tripod with legs Pump Manual 3. SAFETY Naturally, safety is imperative dealing with open fire. All decoflame ® fireplaces are designed, manu- factured and quality-tested in Denmark with highest product safety and user-friendliness in mind. Our fireplaces feature a unique and design-protected decoflame ®... - Page 5 A full tank will last between 6-10 hours, depending on flame intensity and air flow. The Espoo Floor model is primarily intended for indoors use. It can be positioned, however, on a balcony or terrace as well (it should not be kept exposed to the elements, though). Make sure that the fireplace stands on a solid floor with a distance of at least one meter (40 in) from curtains, sunshades and similar textiles or other inflammable objects.
- Page 6 4. POSITIONING & INSTALLATION 1. Espoo fireplace INSTALLATION (using tripod) 2. Tripod flange 3. 4,8 screws (3pcs) 4. M10 bolt (1pcs) Installation of base & Espoo fireplace 5. Wooden leg (3pcs) (best done by two people) 1. Insert the wooden legs in the tripod flange, and make sure that you have pushed them all the way 2.
- Page 7 5. OPERATING INSTRUCTIONS Espoo Floor is designed and manufactured exclusively for use with liquid bioethanol of the highest purity (96.5 - 97.5%) without additives. DO NOT use other fuel, material or bioethanol of inferior quality, as the warranty will be void.
- Page 8 6. MAINTENANCE REFILLING Under no circumstances refill the burner while it is in operation or still hot from previous use. For safety reasons, this fireplace is equipped with a temperature sensor that prevents the pump from filling when the fireplace is hot.
- Page 9 PUMP The Espoo Ceiling contains a pump to fill the tank. The pump is battery powered. It is important to check when the battery is discharged. The battery must be replaced with a new one. Depending on the type and brand of the battery, it lasts for approx. 20-30 refills.
- Page 10 7. DISPOSAL AND RECYCLING The fireplace is made of powder-coated steel and brushed steel. If you wish to dispose of the fireplace, the regional rules and regulations must be observed. Most parts from the Decoflame fireplace can be reused. 8. BIOETHANOL Buy bioethanol from a dealer or online and make sure the alcohol percentage is min.
-
Page 11: Pcs
Warning – flammable material Keep suitable extinguishing Adhere to instructions about fuel and fire blanket. agent ready. The package will include: Pcs. Content Espoo Floor: Ignition button Espoo logo plate M10 bolt B1: Floor telescope B2: Tripod with legs Pump Manual... - Page 12 Follow the Fire Authorities and national and local requirements regarding bioethanol fireplaces. Subject to typographical errors and technical errors. Decoflame ApS reserves the right to make changes without notice. We refer to Decoflame’s General Terms of Sale and Delivery. V11223...
