Zhiyun CINEPEER CX50 COB Light User Manual

Zhiyun CINEPEER CX50 COB Light User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
The following features are available in
this PDF document.
Quick Keyword Search
Enter the keyword in the search box
and hit the search button
Quick Jump between
Chapters
Click the title of a specific chapter on
the Contents to jump to it
*Reading software such as Adobe Reader is
needed to support the functions above.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CINEPEER CX50 COB Light and is the answer not in the manual?

Questions and answers

Related Manuals for Zhiyun CINEPEER CX50 COB Light

Summary of Contents for Zhiyun CINEPEER CX50 COB Light

  • Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
  • Page 2 ZHIYUN CINEPEER CX50 COB Light User Guide...

  • Page 3: Table Of Contents

    Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■ZHIYUN■CINEPEER■CX50■COB■Light■ ■ (hereinafter■referred■to■as■“the■light” ) Get■to■Know■ZHIYUN■CINEPEER■CX50■ ··········· 4 Battery■and■Charging ■ Battery■and■Charging■·················· 5 Installing■and■Removing■Reflector■ ■ Installing■the■Reflector■ ················· 7 Removing■the■Reflector■ ················· 7 Installing■and■Removing■dome■diffuser■(hereinafter■ ■ referred■to■as■"dome■diffuser"） Installing■dome■diffuser■················· 8 Removing■dome■diffuser■ ················ 8 Installing■the■Tripod ■...
  • Page 4 Firmware■Upgrade ■ Contents Product■Specifications ■ Disclaimer■and■Warnings ■ Reading■Tips■ ····················· 18 Safe■Operation■Instructions■ ··············· 18 Warranty■Card ■ Warranty■Period■ ···················· 19 Warranty■Exclusions■ ·················· 19 Warranty■Claim■Procedure■················ 19 Contact■Card ■...

  • Page 5: Brief Introduction

    WARNING This product is not waterproof. Prevent contact with any kind of liquid with the ZHIYUN CINEPEER CX50. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it...
  • Page 6 Brief■Introduction Battery safety precautions: ① It is strictly prohibited to use batteries that are not provided by ZHIYUN. If you need to replace the battery, please contact ZHIYUN or designated agents. ZHIYUN will not be responsible for any battery accidents or equipment malfunctions caused by using batteries that are not officially provided by ZHIYUN.

  • Page 7: Product■List

    Product List Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. Fill Light x1 Reflector x1...

  • Page 8: Get■To■Know■Zhiyun■Cinepeer■Cx50■Cob■Light

    Get■to■Know■ZHIYUN■CINEPEER■CX50■COB■Light■(hereinafter■referred■to■as■ “the■light” ) Get to Know ZHIYUN CINEPEER CX50 Power Button Built-in Battery Adjust Knob Cooling Vent Display Screen Fan Guard Mode Knob Accessory Mount Chip USB-C Port Cooling Vent 1/4''Screw Hole DC Power Supply Port...

  • Page 9: Battery■And■Charging

    Battery■and■Charging Battery and Charging This product features a built-in battery. Before first use, please fully charge the light to activate the battery. To ensure smooth operation of the product, please use the following methods for charging: ① Power via USB adapter: Use the provided USB Type-C charging cable to connect the USB adapter (not provided) and the USB-C power supply port of the light.
  • Page 10 Battery■and■Charging ② Power via DC power adapter: Connect the DC power adapter to the DC power supply port and an AC socket to power ZHIYUN CINEPEER CX50. AC Power （100-240V） It is recommended to use a 24V/2.7A DC power adapter to charge the light.

  • Page 11: Installing And Removing Reflector

    Installing the Reflector Align the reflector mount with the ZHIYUN CINEPEER CX50 accessory mount. Install the reflector to the ZHIYUN CINEPEER CX50 and rotate the reflector as shown in the image until you hear a click sound. The reflector is then installed.

  • Page 12: Installing And Removing Dome Diffuser

    Installing and Removing dome diffuser (hereinafter referred to as "dome diffuser"） Installing dome diffuser Install the reflector to ZHIYUN CINEPEER CX50. Expand the dome diffuser as shown in the image, and align the opening of the dome diffuser with the reflector.

  • Page 13: Installing The Tripod

    Installing the Tripod Installing the Tripod Align the 1/4" screw of the tripod with the 1/4" threaded hole at the bottom of the ZHIYUN CINEPEER CX50. Drive the screw firmly to finish the installation. Tripod is not provided.

  • Page 14: Using With A Light Stand

    Using■with■a■Light■Stand Using with a Light Stand Align the 1/4'' screw hole at the bottom of the light with the 1/4'' screw at the top of the light stand, then mount the light body onto the stand. ② ① Light stand is not provided in the product package.

  • Page 15: How■To■Use■Zhiyun■Cinepeer■Cx50

    How■to■Use■ZHIYUN■CINEPEER■CX50 DO NOT stare at the chips when the device is operating. The IP rating of the outer case is IP20. Buttons and Knobs Long press the power button+turn the Adjust knob/ Mode knob: Power on (powered by grip battery)

  • Page 16: Operation Instruction

    How to Use ZHIYUN CINEPEER CX50 Operation Instruction 1. CCT Mode Settings Single press Mode knob to switch to CCT mode. Single press or turn the Adjust knob to adjust brightness. Turn the Mode knob to adjust color temperature. Dimming range: 0-100% Color temperature adjustment range: 2700K-6500K.
  • Page 17 How to Use ZHIYUN CINEPEER CX50 3. Menu Settings Single press Mode knob to switch to Menu. Turn the Mode knob to switch to language/Bluetooth reset options. Turn the Adjust knob to adjust the chosen option. Finally, press the Adjust knob once to confirm.
  • Page 18 Firmware■Upgrade You can use “Zhiyun Led Tools” or “ZY Vega” to perform the ZHIYUN CINEPEER CX50 firmware upgrade. Method 1: 1. Visit the official website of ZHIYUN (www.zhiyun-tech.com), go to the CX50 product page, click "Download", find the Zhiyun Led Tools and the firmware and download.
  • Page 19 Firmware■Upgrade Method 2: The firmware of the CX50 can be upgraded using the "ZY Vega" app. For more detailed instructions, please visit the ZHIYUN official website at www.zhiyun-tech.com and watch the related video tutorials for the CX50. ① When using Method 1 for the upgrade, please wait until the screen displays that the upgrade is finished, then you can plug out the USB Type-C cable.

  • Page 20: Product■Specifications

    Product■Specifications Product Model： PLX108 Input Power Battery Capacity 4500mAh/66.6Wh 0-100% Dimming Range Color Temperature 2700K-6500K Range CRI ≈ 95 CRI/TLCI TLCI ≈ 96 Illuminance (maximum power, 1520(lux) Lab Data1 without reflector) Illuminance (maximum power, 6580(lux) Lab Data2 with reflector) Runtime (max power) 60min Lab Data3 2H 20min...
  • Page 21 Product■Specifications Lab Data 1: The data is collected in the following conditions: No reflectors, 25℃ temperature, indoor illuminance lower than 0.1lux, test distance 1m, and the color temperature is set at 4300K with 100% brightness. The illuminance is 1520lux. The actual illuminance varies under different conditions. Lab Data 2: The data is collected in the following conditions: Installed reflector, 25℃...

  • Page 22: Disclaimer■And■Warnings

    Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice.

  • Page 23: Warranty■Card

    1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
  • Page 24 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...

  • Page 25: Contact Card

    Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube WeChat Instagram...
  • Page 26 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.

  • Page 27: Fcc Statement

    Contact Card FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
