STEP 1

Before Installing

This product must be installed and
serviced by a licensed plumber, a
licensed gas fitter, or a professional
service technician. NTI is not liable for
any damages or defects resulting from
improper installation.
When applicable, the installation must
conform with Manufactured Home
Construction and Safety Standards,
Title 24 CFR, Part 3280
and/or CAN/CSA Z240 MH Series,
Mobile Homes.
Safety
DO NOT install in areas with
excessively high humidity or poor air
quality (dust, particulate matter, etc.)
1
Unpacking
When you unpack the boiler you will nd
the following items. Check for each of
the following items before installing the
appliance.
Nr. Quantity Description
1 1 Condensing Gas Boiler
2 1 Upper Bracket
3 2 Assembly Screws (Fischer Type SX )
4 1 Lower Bracket
5 1 Condensate Drain Pipe
6 1 CH Pressure Relief Valve
7 1 3" CPVC Pipe, 5" Long
8 2 + 2 2" Vent Screen + 3" Ve nt Screen
9 1 Tridicator
10 1 LP Gas Conversion Kit
1 Installation Manual (This Document)
1 Cascade Installation manual
1 Installation Quick Guide
1 1 1 User's Information Manual
1 LP Conversion Instructions
1 Warranty
1 Connectivity Quick Start Guide
12 1 Outdoor sensor Kit
13 1 3/4" Cap (Not Included with Combis, and not shown)
Table 1 - Included with the Boiler
2
CAUTION
Read both the Installation and
User's Information Manuals before
installing.
WARNING
Follow all local codes and/or the
most recent edition of the National
Fuel Gas Code (ANSI Z223.1/
NFPA 54) in the USA, or the Natural
Gas and Propane Installation Code
in Canada (CAN/CGA B149.1).
1
2
3
Figure 1 - Included with the Boiler
