- Page 1 GF-3000 Ground Fog Machine...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 11.12.2023, ID: 358342 (V4)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 8 Features............................... 11 Installation..............................12 Connections and controls........................13 Operation..............................15 Technical specifications........................18 Troubleshooting............................20 Cleaning............................... 21 Protecting the environment......................24 GF-3000 Ground Fog Machine... - Page 4 GF-3000 Ground Fog Machine...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 7 General information Warning signs Type of danger Warning - slip hazard. Warning – harmful or irritating substances. Warning – danger zone. GF-3000 Ground Fog Machine...
-
Page 8: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended for generating artificial fog by evaporation of dry ice in hot water. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage. - Page 9 Safety instructions DANGER! Danger to life due to electric current! A short circuit could lead to a fire hazard and risk of death. Do not modify the mains cable or the plug! In case of isolation damage, disconnect immediately the power supply and arrange repair. If in doubt, seek advice from a qualified electrician. WARNING! Danger of frostbite when handling dry ice! Dry ice is frozen carbon dioxide (CO...
- Page 10 Safety instructions NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient conditions specified in the “Technical specifications” chapter of this user manual. Avoid operating it in environments with direct sun‐ light, heavy dirt and strong vibrations.
-
Page 11: Features
Features Features This fog machine is suitable for use in clubs, bars, discotheques and on stages Special features of the device: High efficiency heating element Large water tank Robust housing GF-3000 Ground Fog Machine... -
Page 12: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 13: Connections And Controls
Connections and controls Connections and controls ö & GF-3000 Ground Fog Machine... - Page 14 Connections and controls 1 Carrying handles 2 Lid clip 3 [READY] | Green indicator light. Indicates that the filled water is at the required operating temperature. 4 [HEATING] | Red indicator light. Lights when the device is heating up. 5 Mains cable for power supply 6 Connecting cable to the heating element 7 Fog nozzle 8 Heating element...
-
Page 15: Operation
Operation Operation Starting up the device WARNING! Danger of frostbite when handling dry ice! Dry ice is frozen carbon dioxide (CO ) at a temperature of -87.5°C. Direct skin con‐ tact causes severe frostbite. Never touch dry ice with bare hands. When handling dry ice, always wear suitable protective gloves and protective goggles. - Page 16 Operation NOTICE! Damage to the device due calcareous or dirty water. Too hard of water or dirty water can damage the device. Use only very soft water or, if in doubt, distilled water. Make sure that the device is disconnected from the mains. Open the lid clip (2) and open the lid.
- Page 17 Operation Wait until the green indicator light (3) comes on. The water has now reached the required temperature for fog generation. If the water cools down too much during oper‐ ation, the heating is switched back on and the red indicator light (4) comes on. Use the lever (8) to slowly lower the ice bin down to the middle position ([1]) so that the dry ice comes into contact with the hot water.
-
Page 18: Technical Specifications
Technical specifications Technical specifications Heater power 3000 W Warm-up time approx. 15 min Water container capacity 8.2 l Dry ice bin capacity 2.2 kg Fog blast, max. approx. 220 m³/min Power consumption 2400 W Supply voltage 203 V 50 Hz International Protection Rating IP20 Dimensions (W ×... - Page 19 Technical specifications Further information DMX control Timer remote control included Radio remote control included Battery operation With suspension bracket Blast direction Ground On/Off remote control included Light effect included GF-3000 Ground Fog Machine...
-
Page 20: Troubleshooting
2. Check the fluid level in the supply tank. 3. Check the fluid level in the dry ice bin. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. GF-3000 Ground Fog Machine... -
Page 21: Cleaning
Cleaning Cleaning Components Clean the externally accessible parts of the device regularly. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more dirt to accumulate on the device parts. Clean with a soft dry cloth. Stubborn stains may be removed with a slightly damp cloth. - Page 22 Cleaning Descaling WARNING! Possible cauterisation when using descaling agents! Descaling agents contain caustic substances that can damage eyes and skin on direct contact. Follow the instructions for use of the descaling agent and the warnings therein. Wear protective gloves when using descaling agent. Never ingest descaling agent.
- Page 23 Cleaning Fold down the lid and close the lid clip. Wait until the green indicator light (3) comes on. The water has now reached the required temperature. Disconnect the device from the mains (pull the mains plug). Open the lid clip (2) and open the lid. Fill one portion of the descaling agent (dosage according to manufacturer's instructions) into the container.
-
Page 24: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 25 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
- Page 26 Notes GF-3000 Ground Fog Machine...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
