Open up a sub-window
side-by-side of another
signal source.
When the sub source is
not detected:
Note
The black strip located on the top
and the bottom of the screen is for
measuring the correct aspect ratio when
in the PBP mode. If you expect to see full-
screen, adjust your device's resolutions
to pop-up attention resolution and you
will able to see 2 devices' source screen
project to this display without black
strips. It is important to note that the
analog signal is not supported on full
screen in PBP mode.
• PIP / PBP Input: There are different
video inputs to choose from as the
sub-display source: [HDMI 2.0],
[DisplayPort] and [USB C].
Please refer to the table below for com-
patibility of the main/sub-input source.
Inputs
MAIN
HDMI
SOURCE
DisplayPort
(xl)
USB C
• PIP Size: When PIP is activated,
there are three sub-window sizes to
choose from [Small], [Middle], and
[Large].
• PIP Position: When PIP is activated,
there are four sub-window positions
to choose from.
A B
(main)
A B
(main)
SUB SOURCE POSSIBILITY
(xl)
HDMI DisplayPort USB C
● ● ●
● ● ●
● ● ●
B
Small
A
Middle
Large
(main)
Top-Left
B
A
(main)
Bottom-Left
A
(main)
B
• Swap:
The main picture source and
the sub-picture source are
swapped on the display.
Swap A and B source in [PIP] mode:
A
(main)
Swap A and B source in [PBP] mode:
A
(main)
• Off:
Stop MultiView function.
Note
When you activate the SWAP function,
the video and its audio source will swap
at the same time.
13
Top-Right
A
Bottom-Right
A
B
↔
B
B
↔
(main)
A
(main)
B
(main)
(main)
B
A
B
(main)
A
