Operator's Manual

RELAX 2-MAN — LS

Ladder Stand

MODEL RE673

Maximum Height

16' 10" to shooting rail

Maximum Field Rating

500 lbs; no more than

300 lbs per person.

Tree Diameter Range

12" to 30"

Wear Your

Harness!

P/N: 45323

C/N: 45321

REV3: 04/02/24

Table of Contents

Need help?

Do you have a question about the RELAX 2-MAN-LS and is the answer not in the manual?

Questions and answers

Summary of Contents for Rivers Edge RELAX 2-MAN-LS

Page 1 Operator's Manual RELAX 2-MAN — LS WE ARE HUNTERS Ladder Stand MODEL RE673 Maximum Height 16’ 10” to shooting rail Maximum Field Rating 500 lbs; no more than 300 lbs per person. Tree Diameter Range 12” to 30” Wear Your Harness! PRODUCT MEETS INDUSTRY STANDARDS...
Page 2: Table Of Contents
INTRODUCTION Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free pleasure. Instructions should be kept in a safe place and reviewed at least annually.
Page 3: Warnings
Operator's Manual RELAX 2-MAN— LS Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE673 WARNING MAXIMUM USE HEIGHT - 16’10” TO SHOOTING RAIL Never use, install, or remove a treestand on a dead, leaning, diseased or loose barked tree, or a utility pole. MAXIMUM OCCUPANCY - TWO (2) PEOPLE Always avoid electrical power lines.
Page 4: Inspection And Maintenance
Operator's Manual RELAX 2-MAN— LS Ladder Stand WARNING INSPECTION AND MAINTENANCE Check the ground under the stand to make sure it is firm and level. Sloping ground or uneven surface (one side on BEFORE EACH USE PERFORM THE FOLLOWING: a rock) can cause your ladder to tilt or shift off the tree as you climb.
Page 5: Hardware List
Operator's Manual RELAX 2-MAN— LS Ladder Stand TOOLS REQUIRED (NOT INCLUDED) 7/16 IN WRENCHES HARDWARE LIST Item Part No. Image Description PLASTIC 23572 YELLOW WASHER BOLT M6 X 26813 20 MM 28839 KNOB M6 WING BOLT 45731 1/4 X 1-1/2 IN WING NUT 48042B 1/4 IN...
Page 6 Operator's Manual RELAX 2-MAN— LS Ladder Stand HARDWARE LIST (CONTINUED) Item Part No. Image Description 48153B BOLT 1/4 X 2 IN BOLT 1/4 48240B X 1-1/2 IN BOLT 1/4 X 48250B 1-3/4 IN 48261B WASHER 1/4 IN BOLT 1/4 X 48270B 2-1/2 IN BOLT 1/4...
Page 7: Assembly Instructions
Operator's Manual RELAX 2-MAN— LS Ladder Stand ASSEMBLY INSTRUCTIONS IMPORTANT ASSEMBLY TIP: All assembly must be done in this order at ground Do not tighten any nut and bolt combinations completely level before uprighting. until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the Do not remove labels/warnings from product, they are lock- nut on the bolt while helping alignment of all parts!
Page 8 Operator's Manual RELAX 2-MAN— LS Ladder Stand Attach the previously assembled seat side rails (8) and tree blade (21) from Step 1 to the previously assembled vertical supports (12 and 13) and seat support (11) from Step 2 by attaching the seat side rails (8) to the vertical supports (12 and 13) using four 1/4 X 1-3/4 IN bolts (30) and nuts (36).
Page 9 Operator's Manual RELAX 2-MAN— LS Ladder Stand Begin attaching the seat (17) to the assembled frame by attaching the center seat rail to the tree blade (21) using a 1/4 X 1-1/2 IN bolt (29) and nut (36). Then attach the lower end of the center seat rail to the u bracket (18) using a 1/4 X 1-1/2 IN bolt (29) and nut (36) Next attach the sides of the seat (17) to the vertical...
Page 10 Operator's Manual RELAX 2-MAN— LS Ladder Stand Attach the shooting rail assembly to the seat (17) using two 1/4 X 2-1/4 IN bolts (33), six yellow washers (1) and two nuts (36). SEE DETAIL 7A. Attach the two shooting rail adjustment knobs (3) to the adjustment plates on right and left vertical supports (12 and 13) using two M6 x 20 MM bolts (2).
Page 11 Operator's Manual RELAX 2-MAN— LS Ladder Stand Attach the ladder ratchets (6) to the middle ladder section (20) using two 1/4 X 1-1/2 IN bolts (29) and nuts (36). 10. Ladder sections are assembled on the ground in the following order: bottom ladder section (4), middle ladder section (20) and the top ladder section (10) with the treestand top assembly.
Page 12 Operator's Manual RELAX 2-MAN— LS Ladder Stand 11. Before uprighting the stand to the tree, you must attach the two long straps (40) to the assembled treestand. Begin by feeding one end of each strap through the strap guide (23) and strap guide guard (22) under the treeblade and at the top of the ladder on both sides.
Page 13: Warnings
Operator's Manual RELAX 2-MAN— LS Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE SETUP AND USE STOP WARNING WARNING Double check assembly steps to be certain you have Always maintain three (3) points of contact when correctly assembled this product. climbing a ladder treestand.
Page 14: Setup And Use Instructions
Operator's Manual RELAX 2-MAN— LS Ladder Stand SET UP AND USE INSTRUCTIONS WATCH THE SET-UP AND USE VIDEO ONLINE AT WWW.HUNTRIVERSEDGE.COM TO ASSIST WITH THE SET-UP OF YOUR TREESTAND WARNING During installation and removal of ladder treestands, Never use, install, or remove a treestand on a dead, you must always and properly use the included Full Body leaning, diseased or loose barked tree, or a utility pole.
Page 15 Operator's Manual RELAX 2-MAN— LS Ladder Stand Begin by removing the long straps (40) from the ground level FIGURE 3 ratchets (6) and let them hang down on either side of the tree. SEE FIGURE 3. 10. Hook the large carabiner (42) to one of the long straps (40) that are hanging down near the tree.
Page 16 Operator's Manual RELAX 2-MAN— LS Ladder Stand 11. If the tree has branches between the ground and the top of the FIGURE 5 stand, before hooking the two long straps (40) together behind the tree with the carabiner (42), you must first get both straps on the same side of all of the branches.
Page 17 Operator's Manual RELAX 2-MAN— LS Ladder Stand 12. Hook the two long straps (40) together behind the tree with the FIGURE 7 large carabiner (42). SEE FIGURE 5. Be sure to lock the carabiner with the screw locking mechanism. SEE FIGURES 6 A-C. 13.
Page 18 Operator's Manual RELAX 2-MAN— LS Ladder Stand 14. Once the straps (40) and carabiner (42) are all the way up the back FIGURE 9-A FIGURE 9-B of the tree, unhook the tether rope (38) from the two long straps (40) and set aside. The tether rope can later be used as a haul line to pull your gear up into the stand.
Page 19 Operator's Manual RELAX 2-MAN— LS Ladder Stand INSTALLING THE RATCHET STRAP (39) FIGURE 12-A FIGURE 12-B 19. Be certain ladder bottom is firmly seated on dry, level ground. With two people securely holding the base of the ladder, use the three point contact climbing method to slowly climb the ladder and carefully keep a constant hand grip on the ladder at all times.
Page 20: Finished Ladder
Operator's Manual RELAX 2-MAN— LS Ladder Stand FINISHED LADDER ASSEMBLED RATCHET STRAP PLATFORM SECTION TOP LADDER SECTION STABILIZER BAR RATCHET STRAP MIDDLE LADDER SECTION STABILIZER BAR RATCHETS BOTTOM LADDER SECTION Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
Page 21: Llustrated Parts Breakdown
Operator's Manual RELAX 2-MAN— LS Ladder Stand ILLUSTRATED PARTS BREAKDOWN 22,23 mesh hidden for clarity Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
Page 22: Parts List
Operator's Manual RELAX 2-MAN— LS Ladder Stand PARTS LIST ITEM # PART # DESCRIPTION QTY. ITEM # PART # DESCRIPTION QTY. 23572 PLASTIC YELLOW WASHER 48261B WASHER 1/4 IN 26813 BOLT M6 X 20 MM 48270B BOLT 1/4 X 2-1/2 IN 28839 KNOB M6 48271B...
Page 23: Notes
Operator's Manual RELAX 2-MAN— LS Ladder Stand NOTES Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
Page 24 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-345-6007 1730 Industrial Avenue, PO Box 666 Fax: 715-822-2124 Cumberland, WI 54829 www.HuntRiversEdge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvement, product images may not be exact. Warning labels in some product...
