Operator's Manual
Hang-On Stands
BIG FOOT™ TRAVELER
BIG FOOT™ XL LOUNGER
Model RE513
Model RE552
INCLUDES MODEL #'s:
Wear Your
Harness!
GAS/OIL
RE513, Big Foot™ Traveler
PRODUCT MEETS
RATIO
INDUSTRY STANDARDS
50:1
RECOGNIZED BY
RE552, Big Foot™ XL Lounger
PARTICIPATING MEMBER
P/N: 18051
REV5: 03/15/16
Get parts online at
© 2016 RETI
www.HuntRiversEdge.com
All Rights Reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rivers Edge BIG FOOT XL LOUNGER RE552
Summary of Contents for Rivers Edge BIG FOOT XL LOUNGER RE552
- Page 1 Operator's Manual Hang-On Stands BIG FOOT™ TRAVELER BIG FOOT™ XL LOUNGER Model RE513 Model RE552 INCLUDES MODEL #'s: Wear Your Harness! GAS/OIL RE513, Big Foot™ Traveler PRODUCT MEETS RATIO INDUSTRY STANDARDS 50:1 RECOGNIZED BY RE552, Big Foot™ XL Lounger PARTICIPATING MEMBER P/N: 18051 REV5: 03/15/16 Get parts online at...
-
Page 2: Table Of Contents
Instructions should be kept in a safe place and reviewed at least annually. If for any reason you have a problem with your product, DO NOT return to the retailer, contact the Rivers Edge® customer service department at 800-450-EDGE (3343) for assistance. -
Page 3: Warnings
Operator's Manual Hang-On Stands MODEL RE513 / RE552 WARNING MAXIMUM OCCUPANCY - ONE (1) Pull up a bow, backpack, or firearm or other equipment only after being secure in the treestand and a firearm TOTAL WEIGHT LIMIT - 300 LB must be pulled up with it unloaded, chamber open, and TREE DIAMETER RANGE - 8"... -
Page 4: Inspection And Maintenance
Operator's Manual Hang-On Stands INSPECTION AND MAINTENANCE SCHEDULE WARNING BEFORE EACH USE PERFORM THE FOLLOWING: Climbing aids (stick ladders, sectional ladders, steps, etc.) must extend above the platform to allow the user to step • Inspect all webbing, rope, cord, and strap assemblies for down onto the platform. -
Page 5: Assembly Instructions (Re513)
Operator's Manual Hang-On Stands ASSEMBLY INSTRUCTIONS (RE513) Tools needed – two 7/16" wrenches, two 1/2" wrenches nylon washers IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combi- nations completely until all parts are assembled together! Finger 1/4-20 x 2-1/4" bolts tighten plus one turn of a wrench only! This will temporarily hold the seat frame lock nut on the bolt while helping alignment of all parts! After all parts... -
Page 6: Assembly Instructions (Re552)
Operator's Manual Hang-On Stands ASSEMBLY INSTRUCTIONS (RE552) Tools needed – two 7/16" wrenches, two 1/2" wrenches IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combina- tions completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the lock nut on the bolt while helping alignment of all parts! After all parts are assembled together, all nut and bolt combinations must be completely tightened. -
Page 7: Warnings
Operator's Manual Hang-On Stands WARNING WARNING Double check assembly steps to be certain you have All users are responsible for ensuring strap is attached correctly assembled this product. to treestand properly and securely. Failure to do so may result in serious injury or death. Read and understand Practice installing, adjusting and using your treestand at all instructions for proper installation procedure and ground level prior to using it at elevated positions. -
Page 8: Setup And Use Instructions
Operator's Manual Hang-On Stands SETUP AND USE INSTRUCTIONS TREE (RE513 & RE552) During installation and removal of a hang-on treestand, you must always and properly use the included Full Body Harness (Fall Arrest System) with climbing belt. Refer to the Full Body Harness and climbing belt instructions included with this product for proper use. -
Page 9: Threading The Float Buckle
Operator's Manual Hang-On Stands THREADING THE FLOAT BUCKLE WARNING Always check the condition of your Big Foot strap before use. If strap becomes twisted or if you need to replace a worn or damaged strap, All users are responsible for ensuring strap is attached make sure to follow these instruction to ensure proper assembly. -
Page 10: Parts Explosion/Parts List (Re513)
Operator's Manual Hang-On Stands HANG-ON PARTS LIST (RE513) HANG-ON PARTS EXPLOSION (RE513) KEY # PART # DESCRIPTION QTY. 8655B BOLT 5/16-18 X 1-3/4" HH BLK ZN 48210 CABLE 26" BLACK VINYL W/ BLACK ENDS 48152 BOLT 5/16-18 X 1-1/2" HH BLK ZN 48250B BOLT 1/4-20 X 1-3/4"... -
Page 11: Parts Explosion/Parts List (Re552)
Operator's Manual Hang-On Stands HANG-ON PARTS LIST (RE552) HANG-ON PARTS EXPLOSION (RE552) KEY # PART # DESCRIPTION QTY. 1423B BOLT 5/16-18 X 2 HHCS GR5 BLK ZN 48153B BOLT 1/4-20 X 2 HHCS GR5 BLK ZN 48212 CABLE- 28" BROWN VINYL 48152 BOLT 5/16-18 X 1-1/2 HHCS GR5 BLK ZN... - Page 12 Rivers Edge® Treestands, Inc. 1160 Eighth Avenue, PO Box 755 Cumberland, WI 54829 800-450-EDGE (3343) | Fax 715-822-2124 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images...
