Operator's Manual
BIG FOOT
™
WE ARE HUNTERS
Hang-On Stands
MODELS RE551, RE558
BIG FOOT
XL
™
Model RE551
BIG FOOT
XXXL
™
Model RE558
Maximum Field Rating
300 lbs
Tree Diameter Range
8" to 20"
Wear Your Harness!
PRODUCT MEETS
INDUSTRY STANDARDS
RECOGNIZED BY
Get parts online at
© 2017 RETI
P/N: 18059
www.HuntRiversEdge.com
All Rights Reserved
REV5: 03/02/17
PARTICIPATING MEMBER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rivers Edge BIG FOOT XXXL
Summary of Contents for Rivers Edge BIG FOOT XXXL
- Page 1 Operator's Manual BIG FOOT ™ WE ARE HUNTERS Hang-On Stands MODELS RE551, RE558 BIG FOOT ™ Model RE551 BIG FOOT XXXL ™ Model RE558 Maximum Field Rating 300 lbs Tree Diameter Range 8" to 20" Wear Your Harness! PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY Get parts online at...
-
Page 2: Table Of Contents
Instructions should be kept in a safe place and reviewed at least annually. If for any reason you have a problem with your product, DO NOT return to the retailer, contact the Rivers Edge® customer service department at 800-450-EDGE (3343) for assistance. -
Page 3: Warnings
Operator's Manual BIG FOOT Hang-On Stands READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE551 / RE558 WARNING MAXIMUM OCCUPANCY - ONE (1) Pull up a bow, backpack, or firearm or other equipment only after being secure in the treestand and a firearm TOTAL WEIGHT LIMIT - 300 LB must be pulled up with it unloaded, chamber open, and TREE DIAMETER RANGE - 8"... -
Page 4: Inspection And Maintenance
Operator's Manual BIG FOOT Hang-On Stands WARNING INSPECTION AND MAINTENANCE Climbing aids (stick ladders, sectional ladders, steps, etc.) must extend above the platform to allow the user to step BEFORE EACH USE PERFORM THE FOLLOWING: down onto the platform. Never step up to your stand from a climbing aid. -
Page 5: Hardware Identification Chart
Operator's Manual BIG FOOT Hang-On Stands Bolts shown are for size reference. HARDWARE IDENTIFICATION CHART Extra hardware may be included in the parts bag. 5/16-18 Locknut 5/16 Steel Washer Qty 2 Qty 2 5/16-18 x 1-3/4" Bolt - Qty 2 TOOLS NEEDED 1/2"... -
Page 6: Warnings
Operator's Manual BIG FOOT Hang-On Stands READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE SETUP AND USE STOP WARNING WARNING Double check assembly steps to be certain you have Do Not twist strap when attaching. See setup and use correctly assembled this product. instructions for correct attachment. -
Page 7: Setup And Use Instructions
Operator's Manual BIG FOOT Hang-On Stands SETUP AND USE INSTRUCTIONS WARNING During installation and removal of a hang-on treestand, you must always and properly use the included Full Body Harness (Fall Arrest System) with climbing belt. Refer to the Full Body Never use a treestand on a dead, leaning, diseased or Harness and climbing belt instructions included with this loose barked tree, or a utility pole. - Page 8 Operator's Manual BIG FOOT Hang-On Stands TREE ATTACHMENT INSTRUCTIONS WARNING 1. At desired height, attach by following instructions - a,b,c,d,e,f. Platform must be folded up to remove stand! This allows NOTE: Stand should be attached to tree with platform folded in an upright position! slack in strap for removal.
- Page 9 Operator's Manual BIG FOOT Hang-On Stands THREADING THE FLOAT BUCKLE Always check the condition of your Big Foot strap before use. If strap becomes twisted or if you need to replace a worn or damaged strap, make sure to follow these instruction to ensure proper assembly. 1.
-
Page 10: Illustrated Parts Breakdown
Operator's Manual BIG FOOT Hang-On Stands ILLUSTRATED PARTS BREAKDOWN BIG FOOT ™ Model RE551 BIG FOOT XXXL ™ Model RE558 MESH HIDDEN FOR CLARITY MESH HIDDEN FOR CLARITY Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5... - Page 11 Operator's Manual BIG FOOT Hang-On Stands PARTS LIST RE551 RE558 KEY # DESCRIPTION PART # QTY. PART # QTY. FOOT PLATFORM 27096 26266 CABLE 48212 48212 SEAT POST 26406 26406 SEAT ASSEMBLY TEARTUFF 17446 17446 STRAP ASSEMBLY BIG FOOT 18063 18063 PLUG PLASTIC 1 INCH SQUARE 18551...
- Page 12 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-450-EDGE (3343) 1160 Eighth Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
