Icom IC-92AD Service Manual page 35

RECEIVE ADJUSTMENT (continued)
1) Select an adjustment item using [2] / [8] keys.
2) Set the SSG as specifi ed (frequency, deviation and output level).
3) Push the [BAND] key to adjust (automatic) and store the adjustment value.
ADJUSTMENT
(FM) 1 • Displayed freq. : "(6)"
[145.1 MHz]
[435.1 MHz] 2 • Displayed freq. : "(7)"
(NFM) 3 • Displayed freq. : "(6)"
[145.1 MHz]
[435.1 MHz] 4 • Displayed freq. : "(7)"
[USA]
[SEA], [CHN], [EXP], [CAN]
ADJUSTMENT CONDITION
• Mode : " "
• Receiving
• Mode : " "
• Receiving
• Mode : " "
• Receiving
• Mode : " "
• Receiving
(1) (2) (3)
OPERATION
–
• Set the SSG as;
Frequency : "(6)"
Modulation : 1 kHz
Deviation : 1.75 kHz
Level : –28 dBµ
• Set the SSG as;
Frequency : "(7)"
(4) (5) (6)
5 - 19
ADJUSTMENT
VALUE
ITEM
Push the
[BAND] key.
[ ]
(Automatic
adjustment)
(7)
