Page 1: Table Of Contents
Table of Contents Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette AM/FM stereo with CD AM/FM stereo cassette with CD Rear seat controls Climate Controls Manual heating and air conditioning Electronic automatic temperature control Rear window defroster Lights Headlamps...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Transmission operation Trailer towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance Reporting safety defects (U.S.
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 5: Safety And Environment Protection
Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 6: Special Notices
This information may be stored during regular operation or in a crash or near crash event. This stored information may be read out and used by: • Ford Motor Company. • service and repair facilities. • law enforcement or government agencies.
Page 7 F150 SuperCrew, F150 5.4L Supercharged “Lightning” and Harley-Davidson F-150 Owners: Snowplowing Your vehicle is not recommended for snowplowing. Ford makes no representation as to the suitability of your vehicle for snowplowing, in particular regarding the potential for exceeding vehicle weight limits, airbag (SRS) deployment sensitivity, vehicle crash integrity, or powertrain durability.
Page 8 Introduction Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 9 Introduction MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster Optional instrument cluster Harley—Davidson instrument cluster DOOR THEFT AJAR 60 70 80 RPMX1000 SELECT/RESET km/h SERVICE ENGINE SOON P RN BRAKE CRUISE PREMIUM UNLEADED FUEL ONLY 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 13 Instrument Cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 14 Instrument Cluster Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately. Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system...
Page 15 Instrument Cluster Low fuel: Illuminates when the fuel level in the fuel tank is at, or near empty (refer to Fuel gauge in this FUEL chapter). Low washer fluid: Illuminates when the windshield washer fluid is low. Speed control: Illuminates when CRUISE the speed control is activated.
Page 16: Gauges
Instrument Cluster Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on. Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and the driver’s door is opened.
Page 17 Instrument Cluster Harley—Davidson instrument cluster gauges DOOR THEFT AJAR 60 70 80 RPMX1000 FUEL SELECT/RESET km/h SERVICE ENGINE SOON P RN BRAKE CRUISE PREMIUM UNLEADED FUEL ONLY Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature.
Page 18 Instrument Cluster Trip odometer: Registers the kilometers (miles) of individual journeys. Press the control once to P RN switch from the odometer to the trip odometer. To reset the trip, press the control again until the trip reading is 0.0 miles. Tachometer (if equipped): Indicates the engine speed in revolutions per minute.
Page 19 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information..
Page 20: Entertainment Systems
Entertainment Systems Entertainment Systems AM/FM STEREO CASSETTE 14 15 16 17 VOL - PUSH ON BASS TREB FADE TAPE SEEK SIDE 1 - 2 SCAN TUNE 1. Balance: Press to shift sound to the left/right speakers. 2. Fade: Press to shift sound to the rear/front speakers.
Page 21 Entertainment Systems 4. Tape AMS: In tape mode, press TAPE and hold to activate Automatic Music Search (allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 22 Entertainment Systems 13. AM/FM: Press to choose a frequency band in radio mode. 14. Bass: Press decrease/increase the bass output. 15. Treble: Press decrease/increase the treble output. 16. EJ (Eject): Press to eject a tape. 17. Cassette door: Insert a cassette into the cassette door. AM/FM STEREO / SINGLE CD RADIO 14 15 16 17 18 VOL - PUSH ON...
Page 23 Entertainment Systems 1. Balance: Press to shift sound to the left/right speakers. 2. Fade: Press to shift sound to the front/rear speakers. 3. SCN (Scan): Press to hear a brief sampling of all listenable stations or CD tracks. Press again to stop.
Page 24 Entertainment Systems CD: Press and hold until desired selection is reached. 11. Tune / Discs: In radio mode, press to move up or down the frequency band in individual increments. 12. Seek: Press and release SEEK for previous/next strong station, selection or track. 13.
Page 25 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 26 Entertainment Systems Treble: Press TREB and then press SEL to increase/decrease the BASS amount of treble output. TREB 2. Select: Press and release SEEK for previous/next strong station, selection or track. 3. Balance: Press BAL then press SEL to shift the sound from to the left/right speakers.
Page 27 Entertainment Systems 6. AUTO: Allows you to set strong radio stations without losing your original manually set preset stations. Select a frequency and press AUTO. Once the six strongest stations are filled, the station stored in memory 1 will begin to play. To deactivate autoset and return to your audio system’s manually set memory stations, press the control again.
Page 28 Entertainment Systems 15. Mute: Press to mute the playing media. 16. Seek: Press to listen to the SEEK previous or next listenable radio station or CD track. 17. CD: Press to enter CD mode if in another mode. Press CD to begin CD play if a CD is already loaded into the system.
Page 29 Entertainment Systems 2. Rewind: Press for a slow rewind, press and hold for a fast rewind. Fast forward: Press for a slow advance, press and hold for a fast advance. 3. Comp (Compression): In CD mode, press to adjust the soft and loud passages together for a more consistent listening level.
Page 30 Entertainment Systems 9. Menu: Press MENU and SEL to access clock mode, RDS on/off, Traffic, Program type, Show type and Compression modes. Traffic: Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data).
Page 31 Entertainment Systems AUTOSET will flash on the display. When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.
Page 32 Entertainment Systems PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD 1. Power/volume: Press to turn ON/OFF; turn clockwise/counterclockwise to increase/decrease volume. 2. Scan: Press SCAN to move up SCAN the radio frequency band. SCAN automatically finds a station, plays it for five seconds, then moves to the next station. Press again to stop. Tape/CD: Press SCAN to sample tape/CD selections for eight seconds.
Page 33 Entertainment Systems 4. Cassette door: Insert the cassette with the opening to the right. 5. Eject: Press to eject the cassette/CD. The radio will resume playing. 6. Tape: Press to stop tape during rewind/fast forward. CD: Press to start CD play. With the dual media audio, press CD to toggle between single CD and CD changer play.
Page 34 Entertainment Systems 10. Balance: Press BAL; then press to shift sound to the left/right speakers. Fade: Press FADE; then press to shift sound to the rear/front speakers. 11. Memory preset buttons: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.
Page 35: Rear Audio Controls (If Equipped)
Entertainment Systems 18. Select (SEL): Use with Bass, Treble, Balance, Fade and Clock controls. 19. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output. 20. Tune: Works in radio mode only. SEEK Press TUNE to change...
Page 36: Radio Frequencies
Entertainment Systems 1. Mode: Push to toggle between AM, FM1, FM2, tape, CD or CD changer mode (if equipped). 2. Memory: Push successively to allow rear seat passengers to scroll through memory presets. Push in CD changer mode (if equipped) to advance to the next disc.
Page 37: Cd/Cd Player Care
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 38: Climate Controls
Climate Controls Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 39: Manual Heating And Air Conditioning
Climate Controls 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 40: Electronic Automatic Temperature Control
Climate Controls • Do not put objects under the front seats that will interfere with the airflow to the back seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. To aid in side window defogging/demisting in cold weather: 1.
Page 41 Climate Controls Temperature conversion: Press the MAX A/C and DEF at the same time (for one second) to switch between Fahrenheit and Celsius. The English/Metric (E/M) control on the trip computer and message center (if equipped) will not change temperature display. 1.
Page 42 Climate Controls 8. Vent: Distributes outside air through the instrument panel vents and the floor vents. 9. Max A/C: Distributes recirculated air through the instrument panel vents to cool the vehicle. 10. Manual override controls: Press any of these controls to leave automatic mode and to manually determine where airflow is directed.
Page 43: Rear Window Defroster
Climate Controls To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C 3. Modulate the temperature control to maintain comfort. 4. Set the fan speed to HI 5. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
Page 44: Lights
Lights Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp control (if equipped) The autolamp system sets the headlamps to turn on and off automatically.
Page 45 Lights Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position and • the headlamp control is in the OFF, parking lamp or autolamp position. Always remember to turn on your headlamps at dusk or during inclement weather.
Page 46: Panel Dimmer Control
Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps. Move the control to the full down position, past detent, to turn off the interior lamps.
Page 47: Interior Lamps
Lights INTERIOR LAMPS Map lamps To turn on the map lamps, press the control next to each lamp. If equipped with a moon roof, press the control next to the map lamp to illuminate the lamp. AUTO ROOF Rear dome lamp (if equipped) The dome lamp lights when the control is in the DOOR (left) position, any door is open, the...
Page 48 Lights Courtesy/reading lamps The dome lamp lights when the control is in the DOOR (left) position, any door is open, the instrument panel switch is pushed past the detent and when any of the remote entry controls are pressed while the ignition is off. The reading lamps can be turned on by pressing the rocker controls next to each lamp.
Page 49 Lights Function Number of Trade number bulbs Headlamps 9007 Front park/turn lamps 3157K Foglamps 9145 Backup lamp 3156K Rear stop/turn/sidemarker/tail 3457K lamp High-mount brakelamp Cargo lamp License plate lamp Signal mirror lamp (if equipped) 906/921 Running board lamp (if equipped) All replacement bulbs are clear in color except where noted.
Page 50 Lights 4. Remove bulb retainer ring by turning it counterclockwise, then slide the ring off the plastic base. 5. Carefully pull bulb assembly out of headlamp assembly and replace. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass.
Page 51 Lights 3. Remove bulb socket from the parking lamp assembly by turning it counterclockwise. 4. Pull bulb straight out of socket and press in the new bulb. Install the new bulb(s) in reverse order. Replacing tail/brake/turn signal/backup lamp bulbs 1. Make sure the headlamp control is in the OFF position.
Page 52 Lights Replacing high-mount brake and cargo lamp bulbs Make sure the headlamp control is in the OFF position. 1. Remove the two screws and move the lamp assembly away from the vehicle to expose the bulb sockets. 2. Remove the bulb socket by rotating counterclockwise and pulling it out of the lamp assembly.
Page 53 Lights Replacing running board lamp bulbs (if equipped) The running board bulbs are located behind the running board. 1. Reach behind the center bracket of the running board to locate the bulb. 2. Twist the bulb socket counterclockwise and carefully pull to remove it from the lamp assembly.
Page 54: Driver Controls
Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 55: Tilt Steering Wheel (If Equipped)
Driver Controls TILT STEERING WHEEL (IF EQUIPPED) To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control.
Page 56 Driver Controls Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: 1. Place Velcro hook onto side of aftermarket transmitter opposite of actuator control. 2. Place the transmitter into storage compartment, control down.
Page 57 Driver Controls If the outside temperature falls below 3°C (38°F), the display will alternate from “ICE” to the outside temperature at a two second rate for one minute. Compass The compass display is contained in the overhead console. The vehicle heading is displayed as one of N, NE, E, SE, S, SW, W and NW.
Page 58: Auxiliary Power Point
Driver Controls Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines: • Press and hold the SELECT control until CAL appears in the display (approximately eight seconds) and release. • Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 59: Center Console (If Equipped)
Driver Controls Auxiliary power point (SuperCrew only) An additional auxiliary power point is located on the right side rear trim panel next to the rear seat. CENTER CONSOLE (IF EQUIPPED) The center console offers several useful storage features. These include: •...
Page 60: Power Windows
Driver Controls A driver’s first responsibility is the safe operation of the vehicle. The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.
Page 61: Mirrors
Driver Controls Power rear slider window (if equipped) • Press and hold the open arrow side of control to open window. • Press and hold the closed arrow side of control to close window. MIRRORS Automatic dimming rear view mirrors (if equipped) Your vehicle is equipped with an inside rear view mirror with an auto-dimming function.
Page 62: Power Adjustable Foot Pedals (If Equipped)
Driver Controls Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog. The mirrors are activated when the vehicle is running and the glass is below freezing. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 63: Speed Control
Driver Controls Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 48 km/h (30 mph) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 48 km/h (30 mph).
Page 64 Driver Controls Resuming a set speed Press the RES/RSM (resume) control and release it. This will automatically return the vehicle to the previously set speed. The ACCEL RES/RSM control will not work if the vehicle speed is not faster than COAST 48 km/h (30 mph).
Page 65: One-Touch Moon Roof (If Equipped)
Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. ACCEL COAST Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal or the clutch pedal (if equipped). This will not erase your vehicle’s previously set speed.
Page 66 Driver Controls • To tilt into the vent position (when the glass panel is closed), press and hold the front portion of the moon roof control. To close from the vent position, press and hold the rear portion of the control until the glass panel stops moving.
Page 67 Driver Controls also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal. 1. Press and hold the two outside buttons releasing only when the red light begins to flash after 20 seconds.
Page 68 Driver Controls 7. Press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate step eight. 8. Return to the vehicle and firmly press, hold for two seconds and release the HomeLink button.
Page 69 Driver Controls Reprogramming a single HomeLink button To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1. Press and hold the desired HomeLink button. Do NOT release the button. 2. The red indicator light will begin to flash after 20 seconds. Without releasing the HomeLink button, follow step 2 in the “Programming”...
Page 70 Driver Controls To record a message: 1. Press and release the REC button one time to start recording. PLAY (An audible tone will sound, confirming the onset of recording). 2. Press and release the REC button a second time to end recording.
Page 71: Positive Retention Floor Mat (If Equipped)
Driver Controls If the DEL button is inadvertently pressed or the time allotted (five seconds) has passed, the indicator light will flash amber and an “error” tone will sound. POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in.
Page 72: Tailgate Removal
Driver Controls TAILGATE REMOVAL Your tailgate is removable to allow more room for loading. 1. Lower the tailgate. 2. Use a screwdriver to pry the spring clip (on each connector) past the head of the support screw. Disconnect cable. 3. Disconnect the other cable. 4.
Page 73: Tonneau Cover (If Equipped)
Driver Controls To stow the bed extender, follow steps one through four in reverse order. The bed extender may be used to secure a load of up to 46 kg (100 lbs.) on the tailgate. The bed extender should always be kept in the stowed position with the tailgate closed when not in use.
Page 74 Driver Controls 2. Pull the rear corner assist loops of the cover, outward, then upward to release the tension. Lift up on the rear edge of the cover to remove it from the rear rail. 3. Pull one side of the cover outward and upward away from the side rail working from the rear to the front.
Page 75 Driver Controls Flareside only: • Remove two cross bars from pickup box by pushing towards either side to release tension. • Lower tailgate, depress the levers on each side of the rear rail and remove rear rail from pickup box. Styleside only: •...
Page 76 Driver Controls HARD TONNEAU COVER (IF EQUIPPED) The tonneau cover has been designed to maximize fuel economy. • To avoid damage to the cover, do not operate the vehicle unless the cover is fully secured. To open the cover: • Unlock the cover (with the key) and lift the cover up for access to the pickup box.
Page 77: Locks And Security
Locks and Security Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency.
Page 78 Locks and Security Childproof door locks (if equipped) When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 79: Remote Entry System (If Equipped)
Locks and Security To open the tonneau cover from the inside, pull the “T” shaped handle and push up on the tonneau cover panel. The handle is composed of a material that will glow for hours in darkness following brief exposure to ambient light.
Page 80 Locks and Security Your vehicle is equipped with a remote entry system which allows you to: • unlock the vehicle doors without a key. • lock all the vehicle doors without a key. • activate the personal alarm. If there is any potential remote keyless entry problem with your vehicle, ensure ALL remote entry transmitters are taken to the dealership, to aid in troubleshooting.
Page 81 Locks and Security The UNLOCK feature will work again after: • a door has become ajar, • the ignition is turned to the ON position, or • using the UNLOCK control on your remote entry transmitter or unlocking via the keyless entry keypad. Power door lock disable feature —...
Page 82 Locks and Security 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery.
Page 83 Locks and Security To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Put the key in the ignition. 3. Turn the key from the 2 (LOCK) position to 3 (OFF). 4. Cycle, eight times, rapidly (within 10 seconds) between the 3 (OFF) position and 4 (ON).
Page 84 Locks and Security The inside lights will not turn off if: • they have been turned on with the dimmer control, or • any door is open. The battery saver will shut off the interior lamps 30 minutes after the last door is closed, even if the dimmer control is on.
Page 85: Keyless Entry System (If Equipped)
Locks and Security KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: • lock or unlock the doors without using a key. • activate or deactivate the autolock feature. The keypad can be operated with the factory set 5–digit entry code; this code is located on the owner’s wallet card in the glove box, is marked on the computer module, and is available from your authorized dealer.
Page 86 Locks and Security The anti-scan feature will turn off after: • one minute of keypad inactivity. • pressing the control on the remote entry transmitter. • the ignition is turned to the ON position. Unlocking and locking the doors using keyless entry To unlock the driver’s door, enter the factory set 5-digit code or your personal code.
Page 87 Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 88 Locks and Security THEFT • The indicator will illuminate for three seconds and then go out. THEFT • If the indicator stays on for an extended period of time or flashes rapidly, have the system serviced by your dealer. Replacement keys If your keys are lost or stolen and you don’t have an extra coded key, you will need to have your vehicle towed to a dealership.
Page 89 Locks and Security 3. Turn the ignition to the 3 (OFF) position. 4. Remove the previously programmed coded key from the ignition. 5. Within ten seconds of removing the previously programmed coded key, insert the other previously programmed coded key into the ignition. 6.
Page 90: Seating And Safety Restraints
Seating and Safety Restraints Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 91 Seating and Safety Restraints Full bench seat (if equipped) • Lift the release bar to move the seat forward or backward. Ensure that the seat is relatched into place. • Pull up on the lever located at the bottom of the seatback to quickly fold the seatback forward.
Page 92 Seating and Safety Restraints Captain’s chair (if equipped) • Lift the track release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. • Pull the release lever handle located on the side of the seat up to move the seat back forward or backward.
Page 93 Seating and Safety Restraints Press to raise or lower the front portion of the seat cushion. • Type A • Type B Press to raise or lower the rear portion of the seat cushion. • Type A • Type B 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus)
Page 94: Rear Seats
Seating and Safety Restraints Press the control to move the seat forward, backward, up or down. • Type A • Type B Heated seats (if equipped) To operate the heated seats: • Push control located on the side of the seat to activate. •...
Page 95 Seating and Safety Restraints Returning the seat to seating position Always be sure that the seat is in a latched position, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. 1.
Page 96 Seating and Safety Restraints 3. Pull seatback toward front seat and down into load floor position. 4. Make sure seat is pushed all the way down and locks into position. Returning the seat to seating position Always be sure that the seat is in a latched position, whether the seat is occupied or empty.
Page 97 Seating and Safety Restraints 2. Lift seatback up until it locks into vertical position. 3. Return the head restraint to its original position. If the head restraint is inserted backwards, it may lock and not be removable by using the release button.
Page 98: Safety Restraints
Seating and Safety Restraints SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 99 Seating and Safety Restraints Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Combination lap and shoulder belts 1.
Page 100 Seating and Safety Restraints • Front seats • Rear seats (if equipped) The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in...
Page 101 Seating and Safety Restraints When to use the automatic locking mode • Anytime a child safety seat is installed in a passenger front or outboard rear seating position with Regular Cab or SuperCab. SuperCrew models include the center seating position of the second row.
Page 102 Seating and Safety Restraints 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 103 Seating and Safety Restraints CrewCab base bench seats and all Regular Cab seating positions, the safety belts are equipped with a retractor pretensioner. The driver and front outboard passenger safety belt pretensioners are designed to activate only during certain frontal or near-frontal collisions with sufficient longitudinal deceleration.
Page 104 Seating and Safety Restraints • 4–door SuperCab (Bench seats only) To lower the shoulder belt height, push the button and slide the height adjuster down. To raise the height of the shoulder belt, slide the height adjuster up. Pull down on the height adjuster to make sure it is locked in place.
Page 105 Seating and Safety Restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 106 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 107 Seating and Safety Restraints If... Then... The driver’s safety belt is The BeltMinder feature will not buckled before the ignition activate. switch is turned to the ON position... The following are reasons most often given for not wearing safety belts: (All statistics based on U.S.
Page 108 Seating and Safety Restraints Reasons given... Consider... “The people I’m with don’t Set the example, teen deaths occur 4 wear belts” times more often in vehicles with TWO or MORE people. Children and younger brothers/sisters imitate behavior they see. “I have an air bag” Air bags offer greater protection when used with safety belts.
Page 109 Seating and Safety Restraints • All vehicle doors are closed. • The driver’s safety belt is unbuckled. • The parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure). To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 110 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 111: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 112 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to an occupant in the center front seating position.
Page 113 Seating and Safety Restraints Children must always be properly restrained. Failure to follow these instructions may increase the risk of injury in a collision. An infant in a rear-facing seat faces a high risk of serious or fatal injuries from a deploying passenger air bag. Rear facing infant seats should NEVER be placed in the front seats, unless the passenger air bag is turned off.
Page 114 Seating and Safety Restraints internal injuries, particularly to occupants who are not properly restrained or are otherwise out of position at the time of air bag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the air bag module as possible while maintaining vehicle control.
Page 115 Seating and Safety Restraints A difficulty with the system is indicated by one or more of the following: • The readiness lights will either flash or stay lit. • The readiness lights will not illuminate immediately after ignition is turned on. •...
Page 116 If the OFF light fails to illuminate when the passenger airbag ON/OFF switch is in the OFF position and the ignition switch is in ON, have the passenger airbag ON/OFF switch serviced at your Ford or Lincoln-Mercury dealer immediately. In order to avoid inadvertent activation of the switch, always remove the ignition key from the passenger air bag ON/OFF switch.
Page 117 If the OFF light is illuminated when the passenger air bag ON/OFF switch is in the ON position and the ignition switch is ON, have the passenger air bag ON/OFF switch serviced at your Ford or Lincoln-Mercury dealer immediately. The passenger side air bag should always be ON (the air bag OFF light...
Page 118 Seating and Safety Restraints Always transport children who are 12 and younger in the rear seat. Always use safety belts and child restraints properly. If a child in a rear facing infant seat must be transported in front, the passenger air bag must be turned OFF. This is because the back of the infant seat is too close to the inflating air bag and the risk of a fatal injury to the infant when the air bag inflates is substantial.
Page 119: Safety Restraints For Children
Seating and Safety Restraints • the child has a medical condition which, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can constantly monitor the child’s condition. 3. Medical condition. A passenger has a medical condition which, according to his or her physician: •...
Page 120 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. 2003 F150 (f12)
Page 121 Seating and Safety Restraints Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably. Booster seats also make the shoulder belt fit better and more comfortably for growing children.
Page 122 Seating and Safety Restraints • Those with a high back. If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. Both can be used in any vehicle in a seating position equipped with lap/shoulder belts if your child is over 40 lbs.
Page 123: Safety Seats For Children
Seating and Safety Restraints SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 124 Cab and SuperCab) (passenger side front and rear seating positions-SuperCrew) (if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 125 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 126 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 127 Seating and Safety Restraints Installing child safety seats in the front row lap belt seating positions 1. Lengthen the lap belt. To lengthen the belt, hold the tongue so that its bottom is perpendicular to the direction of webbing while sliding the tongue up the webbing.
Page 128 Seating and Safety Restraints 8. Before placing the child in the seat, forcibly move the seat forward and side-to-side to make sure the seat is securely held in place. 9. Check to make sure the child seat is properly secured before each use.
Page 129 Seating and Safety Restraints • F150 SuperCab • F150 SuperCrew • F150 SuperCrew with quad buckets Tether strap attachment 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat. 3.
Page 130 Seating and Safety Restraints • Front seat (Regular Cab and SuperCab only) • Rear seats ( with quad buckets only) 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 131 Seating and Safety Restraints • Rear seats (SuperCrew only) If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the...
Page 132 Seating and Safety Restraints Many tether straps cannot be tightened if the tether strap is hooked to the loop directly behind the child seat. To provide a tight tether strap: 1. Route the tether strap through the loop directly behind the child seat.
Page 133 Seating and Safety Restraints Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments for child seat anchors (if equipped) Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use seat belts to attach the child seat.
Page 134 Seating and Safety Restraints • F150 SuperCrew with Quad Buckets The anchors on both sides of the center of the SuperCrew rear seat are provided only for child seats at the outboard seats. These anchors are further apart than the pairs of lower anchors for child seat installation at other seats.
Page 135 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.
Page 136: Driving
Driving Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. For vehicle equipped with a manual transmission, you must depress the ignition release lever to release the...
Page 137 Driving Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 138 Driving • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: 1. Make sure the parking brake is set. 2. Push the clutch pedal to the floor. 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus)
Page 139 Driving • Turn the key to 4 (ON) without turning the key to 5 (START). 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 140 Driving Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate. Starting the engine 1. Turn the key to 4 (ON) without turning the key to 5 (START).
Page 141: Brakes
Driving To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Guarding against exhaust fumes Carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 142 Driving Even when the ABS is disabled, normal braking is still effective. (If your BRAKE warning lamp BRAKE illuminates with the parking brake released, have your brake system serviced immediately.) Parking brake To set the parking brake (1), press the parking brake pedal down until the pedal stops.
Page 143: Traction-Lok Axle (If Equipped)
Driving If the power steering system breaks down (or if the engine is turned off), you can steer the vehicle manually, but it takes more effort. If the steering wanders or pulls, check for: • an improperly inflated tire • uneven tire wear •...
Page 144: Automatic Transmission Operation (If Equipped)
Driving Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles. Extra precautions, such as slower speeds and increased stopping distance, should be taken when driving a heavily loaded vehicle. AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.
Page 145 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician. Understanding the gearshift positions of the 4–speed automatic transmission P (Park) This position locks the transmission and prevents the rear wheels from turning.
Page 146 Driving (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. Overdrive can be deactivated by pressing the transmission control OVERDRIVE switch on the end of the gearshift lever. This transmission control indicator light (TCIL) will illuminate on the OVERDRIVE end of the gearshift.
Page 147 Driving 1 (First) • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds. Forced downshifts • Allowed in (Overdrive) or Drive. •...
Page 148: Manual Transmission Operation (If Equipped)
Driving MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch The manual transmission has a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. To start the vehicle: 1. Make sure the parking brake is fully set. 2.
Page 149 Driving 4.2L V6 engine Upshifts when accelerating (recommended for best fuel economy) Shift from: Transfer case position (if equipped) 2H or 4H 1 - 2 24 km/h (15 mph) 14 km/h (9 mph) 2 - 3 40 km/h (25 mph) 19 km/h (12 mph) 3 - 4 60 km/h (37 mph)
Page 150 Driving Upshifts when cruising (recommended for best fuel economy) Shift from: Transfer case position (if equipped) 2H or 4H 1 - 2 16 km/h (10 mph) 6 km/h (4 mph) 2 - 3 34 km/h (21 mph) 16 km/h (10 mph) 3 - 4 51 km/h (32 mph) 21 km/h (13 mph)
Page 151 Driving All applications Maximum downshift speeds Shift from: Transfer case position (if equipped) 2H or 4H 89 km/h (55 mph) 34 km/h (21 mph) (Overdrive) - 4 - 3 72 km/h (45 mph) 27 km/h (17 mph) 3 - 2 56 km/h (35 mph) 21 km/h (13 mph) 2 - 1...
Page 152: Four-Wheel Drive (4Wd) Operation (If Equipped)
Driving FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. Four–wheel drive (4WD) supplies power to all four wheels. 4WD should not be operated on dry pavement; driveline damage may occur. If equipped with the Electronic Shift 4WD System, and 4WD Low is selected while the vehicle is moving, the 4WD system will not engage.
Page 153 Driving 4L (4WD Low)– Uses extra gearing to provide maximum power to all four wheels at reduced speeds. Intended only for off-road applications such as deep sand, steep grades or pulling heavy objects. 4L (4WD Low) will not engage while the vehicle is moving; this is normal and should be no reason for concern.
Page 154 Driving Using the electronic shift 4WD system (if equipped) 2H (2WD High) - Power to the rear wheels only; used for street and highway driving. Provides optimal smoothness and fuel economy at high speeds. 4H (4WD High) - Used for extra traction such as in snow or icy roads or in off-road situations.
Page 155 Driving • If shifting into 4L (4WD Low), wait for the LOW RANGE light in the instrument cluster to turn on indicating the shift is complete. • If shifting out of 4L (4WD Low), wait for the LOW RANGE light in the instrument cluster turn off indicating the shift is complete.
Page 156 Driving pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface. • It may be safer to stay on the apron or shoulder of the road and slow down gradually before returning to the pavement. You may lose control if you do not slow down or if you turn the steering wheel too sharply or abruptly.
Page 157 Driving Do not spin the wheels at over 56 km/h (35 mph). The tires may fail and injure a passenger or bystander. Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency.
Page 158 Driving 4WD Systems 4WD (when you select a 4WD mode) uses all four wheels to power the vehicle. This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. Power is supplied to all four wheels through a transfer case.
Page 159 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 160 Driving slopes or hills. A danger lies in losing traction, slipping sideways and possibly rolling over. Whenever driving on a hill, determine beforehand the route you will use. Do not drive over the crest of a hill without seeing what conditions are on the other side. Do not drive in reverse over a hill without the aid of an observer.
Page 161 If you nevertheless decide to equip your 4WD for off-road use with tires larger than what Ford Motor Company recommends, you should not use these tires for highway driving. If you use any tire/wheel combination not recommended by Ford Motor...
Page 162 Failure to follow tire pressure recommendations can adversely affect the way your vehicle handles. Do not exceed the Ford Motor Company recommended pressure even if it is less than the maximum pressure allowed for the tire.
Page 163: Driving Through Water
Driving Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover). Failure to maintain your vehicle properly may void the warranty, increase your repair cost, reduce vehicle performance and operational capabilities and adversely affect driver and passenger safety.
Page 164 Driving • GCW (Gross Combined Weight): The combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer. • GCWR (Gross Combined Weight Rating): Maximum allowable combined weight of towing vehicle (including occupants and cargo) and the loaded trailer. •...
Page 165: Trailer Towing
Driving Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in this chapter. Loaded vehicles may handle differently than unloaded vehicles. Extra precautions, such as slower speeds and increased stopping distance, should be taken when driving a heavily loaded vehicle.
Page 166 Driving Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury. Engine Rear axle ratio Maximum Maximum GCWR-kg trailer...
Page 167 Driving Engine Rear axle ratio Maximum Maximum GCWR-kg (lbs.) trailer weight-kg (lbs.) Regular Cab 4x2 w/manual transmission 4.2L 3.08 2944 (6500) 907 (2000) 4.2L 3.55 3538 (7800) 1588 (3500) 4.6L 3.08 2944 (6500) 907 (2000) 4.6L 3.31 3265 (7200) 1315 (2900) 4.6L 3.55 3538 (7800)
Page 168 Driving Engine Rear axle Maximum Maximum ratio/tire size - GCWR-kg (lbs.) trailer cm (inches) weight-kg (lbs.) 5.4L 3.31/40.6 (16) 5443 (12000) 3175 (7000) 5.4L 3.55/40.6 (16) 5897 (13000) 3628 (8000)/ 3447 (7600) 5.4L 3.55/43.2 (17) 5670 (12500) 3401 (7500)/ 3221 (7100) 5.4L 3.73/40.6 (16) 6124 (13500)
Page 169 Driving Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. See your dealer or a reliable trailer dealer if you require assistance. Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle.
Page 170 Driving Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 171: Recreational Towing (All Wheels On The Ground)
Driving • Allow more distance for stopping with a trailer attached. • The trailer tongue weight should be 10–15% of the loaded trailer weight. • After you have traveled 80 km (50 miles), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. •...
Page 172 If a distance of 80 km (50 miles) or a speed of 56 km (35 mph) must be exceeded, the drive shaft will have to be removed before the vehicle is towed. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation. Improper removal/installation of the driveshaft can cause transmission fluid loss, damage to the driveshaft and internal transmission components.
Page 173 Driving • The weight of the snowplow and supporting components distributed to the front axle must not exceed the Front Axle Accessory Reserve Capacity. • The total weight of the snowplow and aftermarket equipment must not exceed the TARC. • The weight of the installed snowplow and aftermarket equipment must not load the vehicle beyond the GAWR (front/rear) and GVWR listed on the Safety Compliance Certification Label.
Page 174 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Additional equipment such as snowplow equipment may effect the performance of the air bag sensors increasing the risk of injury.
Page 175 Driving • If the vehicle is stuck, shift the transmission in a steady motion between forward and reverse gears. Do not rock the vehicle for more than a few minutes. The transmission and tires may be damaged or the engine can overheat. Do not rock the vehicle if the engine is not at operating temperature.
Page 176: Roadside Emergencies
Roadside Emergencies Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 177: Roadside Coverage Beyond Basic Warranty
Roadside Emergencies Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.
Page 178: Fuses And Relays
Roadside Emergencies This switch is located in the front passenger’s footwell, by the kick panel access cover. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
Page 179 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 180 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Audio Powertrain Control Module (PCM), Cluster Cigar lighter, Data link connector Power mirror switch, Mirror turn signal relays Speed control module, Reverse lamp, Climate mode switch, Daytime Running Lamps (DRL) relay, Digital Transmission Range...
Page 181 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description — Not used Radio, Remote entry module, GEM, In-vehicle entertainment system (SuperCrew only) — Not used — Not used Front washer pump relay, Wiper run/park relay, Wiper HI/LO relay, Windshield wiper motor —...
Page 182 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Trailer tow battery Charge relay, Turn/Hazard flasher, 4x4 solenoids, 4x4 relays, Overhead console, 4–Wheel Anti-lock Brake System (4WABS) module, EC mirror, Heated seats Function selector switch assembly Heated mirrors Right-hand low beam headlamp Foglamp relay and foglamp indicator, Main light switch...
Page 183 Roadside Emergencies Always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and specifications chapter. The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box...
Page 184 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 15A* Power door locks, Central Security Module (CSM), Lock relays (not used on SuperCrew) 15A* Daytime Running Lamps (DRL), Fog lamps 20A* Fuel pump 20A* Alternator field 20A* Rear auxiliary power point (SuperCrew only) 15A* A/C clutch...
Page 185 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 50/20A** Four-wheel Anti-lock Brake System (4WABS) module/Rear-wheel Anti-lock Brake System (RABS) module, Ignition switch 50A** Central junction box 30A** 4x4 shift motor & clutch 40A** Climate control front blower 20A** Intercooler pump (supercharged engine only)
Page 186: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Fog lamp relay — Front washer pump relay — Intercooler pump relay (supercharged engine only) — Front wiper HI/LO relay — Fuel pump relay — Trailer tow battery charge relay —...
Page 187 Roadside Emergencies Spare tire information Your vehicle is equipped with a spare tire that may be used as a spare or a regular tire. The spare tire wheel may not match the road wheel, and is not equipped with wheel trim. The wheel trim from the wheel/tire may be used on the spare if the wheels match.
Page 188 Roadside Emergencies 2. Attach the spare tire lock key (A) to the jack handle (B). 3. Fully insert the jack handle through the bumper hole and into the guide tube. The key and lock will engage with a slight push and counterclockwise turn.
Page 189 Roadside Emergencies 1. Park on a level surface, activate hazard flashers and set the parking brake. 2. Place gearshift lever in P (Park) (automatic transmission) or in the reverse gear (manual transmission)and turn engine OFF. 3. Block the diagonally opposite wheel.
Page 190 Roadside Emergencies When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park) or in the reverse gear (manual transmission).
Page 191 Roadside Emergencies • Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 192 (seven lug nut wheel): M12 x 1.75 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. Stowing the flat/spare tire Note: Failure to follow spare tire stowage instructions may result in failure of cable or loss of spare tire.
Page 193: Jump Starting
Roadside Emergencies the tire is raised to the maximum tightness. Tighten to the best of your ability, to the point where the ratchet/slip occurs, if possible. The spare tire carrier will not allow you to overtighten. If the spare tire carrier ratchets or slips with little effort, take the vehicle to your dealer for assistance at your earliest convenience.
Page 194 Roadside Emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. Connecting the jumper cables 1.
Page 195 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 196 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 197 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 198: Wrecker Towing
Ford recommends your vehicle be towed with a wheel lift or flatbed. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 199: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 200 If you still have a complaint involving a warranty dispute, you may wish to contact the Dispute Settlement Board (U.S.). In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 201: Ford Extended Service Plan
5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 202 Customer Assistance The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
Page 203 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 204 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 205: Getting Assistance Outside The U.s. And Canada
If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 206: Ordering Additional Owner's Literature
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer...
Page 207: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (or 366–0123 in the Washington D.C.
Page 208: Cleaning
Cleaning Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 209: Paint Chips
Cleaning PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color. • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips.
Page 210 Cleaning • 4.2L V6 engine • 4.6L V8 and 5.4L V8 engine 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 211: Plastic (Non-Painted) Exterior Parts
Cleaning • 5.4L Supercharged V8 engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer.
Page 212: Instrument Panel And Cluster Lens
Cleaning INSTRUMENT PANEL AND CLUSTER LENS Clean the instrument panel with a damp cloth, then dry with a dry cloth. • Avoid cleaners or polish that increase the gloss of the upper portion of the instrument panel. The dull finish in this area helps protect the driver from undesirable windshield reflection.
Page 213: Leather Seats (If Equipped, Except For The King Ranch Supercrew)
Cleaning LEATHER SEATS (IF EQUIPPED, EXCEPT FOR THE KING RANCH SUPERCREW) Your leather seating surfaces have a clear, protective coating over the leather. For King Ranch F-150 SuperCrew leather seats, refer to separate section in this chapter. • To clean, use a soft cloth with Motorcraft Deluxe Leather and Vinyl Cleaner (ZC-11–A).
Page 214 Cleaning SCRATCHES In order to lessen the appearance of certain scratches and other wear marks, apply conditioner on the affected area following the same instructions as in the Conditioning section. CONDITIONING Bottles of King Ranch Leather Conditioner are available at the King Ranch Saddle Shop.
Page 215: Ford, Lincoln And Mercury Car Care Products
Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 216: Maintenance And Specifications
Maintenance and Specifications Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 217: Opening The Hood
Maintenance and Specifications Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral).
Page 218: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Clutch fluid reservoir (manual transmission) 5. Brake fluid reservoir 6. Power distribution box 7. Engine coolant reservoir 8.
Page 219 Maintenance and Specifications 4.6L V8/5.4L V8 engines 1. Power steering fluid reservoir 2. Clutch fluid reservoir (manual transmission) 3. Engine oil dipstick 4. Brake fluid reservoir 5. Power distribution box 6. Air filter assembly 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.
Page 220 Maintenance and Specifications 5.4L Supercharged V8 engine 1. Engine oil dipstick 2. Power steering fluid reservoir 3. Brake fluid reservoir 4. Power distribution box 5. Engine coolant reservoir 6. Air filter assembly 7. Intercooler coolant reservoir 8. Windshield washer fluid reservoir 9.
Page 221: Windshield Washer Fluid
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 222 Maintenance and Specifications • 4.2L engine 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 223 Maintenance and Specifications • 4.6L/5.4L engine 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 224 Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 225: Battery
Change your engine oil according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 226 Maintenance and Specifications Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 227: Engine Coolant
Maintenance and Specifications • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected.
Page 228 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. COLD FILL RANGE • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 229 If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (VC-7–B in Oregon), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 230 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 231 Maintenance and Specifications Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36° C [–34° F]): • It may be necessary to increase the coolant concentration above 50%.
Page 232 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The and the symbol will illuminate. • The “Service Engine Soon” indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 233: What You Should Know About Automotive Fuels
Maintenance and Specifications 5. Restart the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank.
Page 234 Maintenance and Specifications • Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. •...
Page 235 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 236 Maintenance and Specifications Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Octane recommendations Your vehicle is designed to use “Regular” unleaded gasoline with pump (R+M)/2 octane rating of 87. We do not recommend the use of (R+M)/2 METHOD gasolines labeled as “Regular”...
Page 237: Essentials Of Good Fuel Economy
Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 238 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 239 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 240: Emission Control System
Maintenance and Specifications • Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide. Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed.
Page 241 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 242 Maintenance and Specifications On board diagnostics (OBD-II) Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD-II). This OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 243: Checking And Adding Power Steering Fluid
Maintenance and Specifications engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules.
Page 244: Brake Fluid Reservoir
If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specification ESA-M6C25–A. Refer to Lubricant Specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 245: Transmission Fluid
Maintenance and Specifications 1. Clean the reservoir cap before removal to prevent dirt and water from entering the reservoir. 2. Remove cap and rubber diaphragm from reservoir. 3. Add fluid until the level reaches the step in the reservoir. 4. Reinstall rubber diaphragm and cap onto reservoir.
Page 246 Maintenance and Specifications 4. Latch the gearshift lever in P (Park) and leave the engine running. 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick.
Page 247 Maintenance and Specifications The transmission fluid should be in this range if at ambient temperature (10°C-35°C [50°F-95°F]). COLD DO NOT ADD High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
Page 248 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter. 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 249: Driveline Universal Joint And Slip Yoke
Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 250: Air Filter(S)
Maintenance and Specifications AIR FILTER MAINTENANCE Refer to the scheduled maintenance guide for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft Part Numbers. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 251: Information About Uniform Tire Quality Grading
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 252 Maintenance and Specifications The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 253 Maintenance and Specifications Tire rotation Because your vehicle’s tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the scheduled maintenance guide. If you notice that the tires wear unevenly, have them checked. The following procedure applies to vehicles equipped with single rear wheels, if your vehicle is equipped with dual rear wheels it is recommended that only the front wheels be rotated (side to side).
Page 254: Snow Tires And Chains
Make sure that all replacement tires are of the same size, type, speed rating, load-carrying capacity and tread design (e.g., “All Terrain”, “Touring”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires.
Page 255: Motorcraft Part Numbers
Maintenance and Specifications tires and chains. If you need to use chains, it is recommended that steel wheels (of the same size and specifications) be used, as chains may chip aluminum wheels. Follow these guidelines when using snow tires and chains: •...
Page 256: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft High Fill to line or step and clutch Performance (for clutch) on fluid DOT 3 Motor reservoir Vehicle Brake Fluid Engine Motorcraft 4.2L V6 engine 19.0L (20.1 quarts)
Page 257 Maintenance and Specifications Fluid Ford Part Application Capacity Name Power Motorcraft Fill to between MIN steering MERCON ATF and MAX lines on fluid reservoir Transfer Motorcraft 4x4 vehicles 1.9L (2.0 quarts) case fluid MERCON ATF Transmission Motorcraft 5-speed manual 3.5L (3.75 quarts)
Page 258 Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118–A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles. Service refill capacity is determined by filling the axle to the bottom of the filler hole with the vehicle on a level surface.
Page 259: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford part Ford part Ford Item name or number specification equivalent Motorcraft SAE XY-75W90-TQL WSP-M2C201-A 75W-90 Front axle Premium 4x4 (4X4) Front Axle Lubricant Motorcraft SAE XY-75W140–QL WSL-M2C192-A 75W-140 High Rear axle Performance Synthetic Rear...
Page 260 Motorcraft ZC-32–A WSB-M8B16–A2 Premium Windshield Windshield washer fluid Washer Concentrate Add 118 ml (4 oz) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118-A for complete refill of 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 261: Engine Data
Maintenance and Specifications Traction-Lok axles. Add 236 ml (8 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118-A for complete refill of 10.25 and 10.5 inch Traction-Lok axles. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 262: Vehicle Dimensions
Maintenance and Specifications VEHICLE DIMENSIONS Styleside Body Style Dimension Regular Regular Cab Super Cab Super Cab Cab 4x2 5256 mm 5264 mm 5728 mm 5735 mm (206.9 in) (207.2 in) (225.5 in) (225.8 in) (1) Overall (SWB) (SWB) (SWB) (SWB) length 5729 mm 5736 mm...
Page 263 Maintenance and Specifications Flareside Body Style Dimension Regular Regular Super Cab Super Cab Cab 4x2 Cab 4x4 (1) Overall 5255 mm 5263 mm 5728 mm 5735 mm length (206.9 in) (207.2 in) (225.5 in) (225.8 in) (2) Overall 2014 mm 2030 mm 2014 mm 2030 mm...
Page 264 Maintenance and Specifications 2003 F150 (f12) Owners Guide (post-2002-fmt) USA English (fus) https://www.MyCarManual.com...
Page 265 Maintenance and Specifications F-150 SuperCrew Body Style Dimension SuperCrew 4x2 mm SuperCrew 4x4mm (in) (in) 5738 5745 (1) Overall length (225.9) (226.2) 2009 2029 (2) Overall width (79.1) (79.9) 1878 1953 (3) Overall height (73.9) (76.9) 3518 3525 (4) Wheel base (138.5) (138.8) 1661...
Page 266: Identifying Your Vehicle
Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 267 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 268 In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
Page 269 Accessories Cargo trays (interior) Cellular phone holder Daytime running lights (DRL) Dash trim (wood grain) Engine block heaters Manual sliding rear window Power sliding rear window Remote start system Tire step Travel equipment Cargo cage (SuperCrew only) Bed mount bike carrier Bed tent Fog lights Hitch mount bike carrier...
Page 270 Accessories Protection and appearance equipment Bed mat/bedliner tailgate covers Bed mats Bedliners Bull bar (chrome & black) Cap (hard, color keyed — Leer supplier branded) Carpet floor mats Commercial Cap (Leer supplier branded) Cargo cover Cargo liner Chrome grill insert Diamond plate, bed rail caps Diamond plate, front box protector Diamond plate, splash guards...
Page 271 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. 2003 F150 (f12)
Page 272 Index Index Accessory delay ......60 Battery ........225 acid, treating emergencies ..225 Air bag supplemental restraint system ........111 jumping a disabled battery ..193 and child safety seats ....112 maintenance-free ....225 description ......111 replacement, specifications ...255 disposal ........115 servicing ........225 driver air bag ......113 Bed extender ......72 indicator light ......114 operation .........113...
Page 273 ....259, 261 jump-starting ......193 Cruise control Emergency Flashers ....177 (see Speed control) ....63 Emission control system ..240 Customer Assistance ....176 Ford accessories for your Engine ........261–262 vehicle ........215 cleaning ........209 Ford Extended Service coolant ........227 Plan ..........201 fail-safe coolant ......231 Getting assistance outside idle speed control ....225...
Page 274 Index refill capacities ......256 quality ........236 service points ....218–220 running out of fuel ....237 starting after a collision ..177 safety information relating to automotive fuels ....233 Engine block heater ....140 Fuel pump shut-off switch ..177 Engine oil ........221 checking and adding ....221 Fuses ........178–179 dipstick ........221 filter, specifications ..224, 255...
Page 275 Index Heating fog lamps ........44 heating and air headlamps .........44 conditioning system ...38–40 headlamps, flash to pass ..45 instrument panel, dimming ..46 HomeLink universal interior lamps .....47–48 transceiver (see replacing bulbs ....48–53 Garage door opener) ..66, 68–69 Lane change indicator Hood ..........217 (see Turn signal) ......46 Lights, warning and indicator ..12...
Page 276 Index extension assembly ....110 for adults ......99–102 for children .....119–120 Parking brake ......142 lap belt ........104 Parts (see Motorcraft parts) ..255 safety belt maintenance ..110 Pedals (see Power warning light and adjustable foot pedals) ....62 chime .......105–106 Power adjustable foot pedals ..62 Safety seats for children ..123 Power distribution box Seat belts (see...
Page 277 Index Tires ......186, 251–252 manual operation ....148 changing ......186–188 Trunk ...........78 checking the pressure ....252 Turn signal ........46 replacing ........254 rotating ........253 snow tires and chains ....254 tire grades .......252 Vehicle dimensions ...262, 265 treadwear ........251 Vehicle Identification Number Tonneau cover .......73, 76 (VIN) ..........267 Towing ........165 Vehicle loading ......163...
Page 278 https://www.MyCarManual.com...
Page 279 https://www.MyCarManual.com...
Page 280 https://www.MyCarManual.com...

Ford F150 2003 Owner's Manual

Quick Links

Table of Contents

Need help?

Questions and answers

Related Manuals for Ford F150 2003

Summary of Contents for Ford F150 2003

Table of Contents
