  • Page 1 USER'S MANUAL POLAR SERIES ASH-18AIP PT, ASH-24AIP PT...
  • Page 2  ...
  • Page 3: Table Of Contents

    CONTENTS Operation and Maintenance Safety Precautions ■ ........1 Name of Parts ■ .........................4 Operation of Remote controller ■ ..............5 ■ Emergency Operation ........10 ■ ........11 Care and Cleaning ■ Troubleshooting ........13 ■ Operation Tips ................20    Installation Service ■...
  • Page 4: Safety Precautions

    Safety Precautions Please read the following notices before operation WARNING ★ ★ ★ If there's abnormal pheno- Do not operate the air cond- Do not cut off or damage the menon(like smell of burning), itioner with wet hands. power cord or signal control please cut off the power imm- wire.
  • Page 5 Safety Precautions Select the most appropriate ★ ★ ★ Always ensure effective For safety, be sure to turn off the circuit beaker before temperature. earthing. performing any maintenance or cleaning or when the product is not used for an extended period of time. Keep room about ℃...
  • Page 6 Safety Precautions To change the airflow direction, adjust the vertical Do not cut off or damage the power cords or ★ ★ and horizontal air flow direction by using the control cords. If they are damaged, please remote controller. contact the dealer or qualified service personnel Vertical Louver Horizontal Louver...
  • Page 7: Name Of Parts

    Name of Parts Indoor unit Air in ⑵ ⑹ ⑸ ⑷ Air out ⑶ The icons displayed: ⑴ :Cool :Dry Wireless Remote control ⑴ :Heat remote control Power : ⑵ Front panel Set temp. : Filter ⑶ ON/OFF : Guide louver Receive window ⑷...
  • Page 8: Operation Of Remote Controller

    Operation of Remote Controller ON/OFF Press it to start or stop operation. MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT). : Press it to decrease temperature AUTO OPER setting. HEALTH X-FAN HUMIDITY : Press it to increase temperature FILTER setting. TURBO HOUR ON/OFF...
  • Page 9: Mode Icon

    Operation of Remote Controller AUTO HEALTH X-FAN HUMIDITY FILTER TURBO HOUR ON/OFF MODE icon: Up & down swing icon: is displayed when pressing If MODE button is pressed, button. current operation mode icon up & down swing (AUTO), ( COOL), Press this button again to clear the (DRY), (FAN) or...
  • Page 10 Operation of Remote Controller Remote controller description ON/OFF : Press this button to turn on the unit .Press this button again to turn off the unit. MODE : Each time you press this button, a mode is selected in a sequence that goes from AUTO, , as the following: COOL,DRY, FAN, and HEAT COOL...
  • Page 11 Operation of Remote Controller HEALTH SAVE: Press HEALTH part of this button to turn on or off HEALTH function. Pressing SAVE part of this button, is displayed and the unit goes into SAVE operation mode. Press SAVE part of the button again to cancel SAVE function. During SAVE operation, the temperature and fan speed is not adjustable.
  • Page 12 Operation of Remote Controller SLEEP : Press this button to go into the SLEEP operation mode. Press it again to cancel this function. This function is available in COOL , HEAT (Only for models with heating function) or DRY mode to maintain the most comfortable temperature for you. LIGHT: Press LIGHT button to turn on the display's light and press this button again to turn off the display's light.
  • Page 13: Emergency Operation

    Emergency Operation Emergency Operation When the remote controller is lost r damaged, please use the manual switch on the main unit. In that case, the unit operates in AUTO mode and the temperature setting or fan speed can not be changed. The manual switch can be operated as below: Manual switch Open the panel.
  • Page 14: Care And Cleaning

    Care and Cleaning Caution Disconnect the power supply before cleaning and maintenance. ● Do not splash water on the units for cleaning, as electric shocks may occur. ● Wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleaner (not with ●...
  • Page 15 Care and Cleaning Check before Use ① Be sure that nothing obstructs the air outlet and inlet. ② Check if the batteries of remote controller are replaced. Check if the installation stand of the outdoor unit is damaged. ③ If damaged, consult the technicians. Maintenance after Use ①...
  • Page 16: Troubleshooting

    Troubleshooting CAUTION The air conditioner is not user serviceable. Incorrect repair may cause electric shock or fire, so please contact an authorized service center for professional repair. Following checks prior to contact may save your time and money. Phenomenon Troubleshooting The unit does not operate: The unit does not operate if it is turned on ●...
  • Page 17 Troubleshooting Phenomenon Troubleshooting ● Is the power cut off? The unit can not be started up: ● Is the power plug loose?( if applicable ) ● Is the circuit protection device tripped off? ● Is voltage higher or lower? (Tested by professionals) Breaking off ●...
  • Page 18 Troubleshooting Phenomenon Troubleshooting Indoor unit can not blow air: In HEAT mode, when the temperature of indoor ● heat exchanger is very low, air flow is stopped in order to prevent cold air. (Within 2minutes) In HEAT mode, when the outdoor temperature ●...
  • Page 19 Troubleshooting Malfunction Indication Table Display method of outdoor unit Display (3 kinds of display status for method Malfunction indicator; □OFF ■ON ☆blink) of indoor A/C Status Name Meaning of Malfunction unit During cooling operation: compressor stops while indoor High pressure Pressure of A/C system fan operates.
  • Page 20 Troubleshooting Malfunction Indication Table Display method of outdoor unit Display (3 kinds of display status for method Malfunction indicator; □OFF ■ON ☆blink) A/C Status of indoor Name Meaning of Malfunction unit During cooling operation: Outdoor discharge compressor stops while indoor Outdoor discharge temperature sensor fan operates.
  • Page 21 Troubleshooting Malfunction Indication Table Display method of outdoor unit Display (3 kinds of display status for method Malfunction indicator; □OFF ■ON ☆blink) of indoor A/C Status Name Meaning of Malfunction unit During cooling operation: High temperature compressor stops while indoor Temperature of module is protection of fan operates.
  • Page 22 Troubleshooting Malfunction Indication Table Display method of outdoor unit Display (3 kinds of display status for method Malfunction indicator; □OFF ■ON ☆blink) of indoor A/C Status Name Meaning of Malfunction unit During cooling operation: compressor stops while indoor Voltage of DC After the rectification of fan operates.
  • Page 23: Operation Tips

    Operation Tips Cooling Operation Principle: Air conditioners absorb heat in the room and transmit it to the outdoor unit, so that the room temperature is decreased. The cooling capacity will increase or decrease according to outdoor ambient temperature. Antifreezing Function: If the unit is operating in COOL mode and in low ambient temperature, frost may be formed on the heat exchanger.
  • Page 24: Operating Temperature Range

    Operation Tips Operating Temperature Range Indoor side DB/WB( Outdoor side DB/WB( Maximum cooling 32/23 48/- 21/15 Minimum cooling -15/- Maximum heating 27/--- 24/18 Minimum heating 20/--- -20/- The operating temperature range (outdoor temperature) for cooling only unit is-15℃ ~ 48℃; for heat pump unit is -20℃...
  • Page 25: Notices For Installation

    Notices for Installation Caution The unit must only be installed by authorized service center according to local or government regulations and in compliance with this manual . Before installation, please contact with local authorized maintenance center. If the unit is not installed by the authorized service center, the malfunction may not be solved due to discommodious contacts.
  • Page 26 Notices for Installation Installation Site of Indoor Unit The air inlet and outlet should be away from the obstructions. Ensure the air can be blown through the whole room. Select a site where the condensing water can be easily drained out, and where it is easily connected for outdoor unit.
  • Page 27 Notices for Installation Safety Requirements For Electric Appliances 1. The power supply should be used the rated voltage and AC exclusive circuit, the power cable diameter should be satisfied. 2. Don't drag the power cable emphatically. It should be reliably earthed, and it should be connected to the special earth device, the installation work should be operated by the professional.
  • Page 28: Installation Drawing

    Installation Drawing Installation Drawing Space to the ceiling Above Space to the wall Above Above Space to the wall Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ● installation of the appliance including the minimum permissible distances to adjacent structures Space to the obstruction Air inlet side...
  • Page 29: Installation Of Indoor Unit

    Installation of Indoor Unit Installation of Mounting Plate 1. Mounting plate should be installed horizontally. As the water tray's outlet for the indoor unit is two-way type, during installation, the indoor unit should slightly slant to water tray's outlet for smooth drainage of condenser water.
  • Page 30 Installation of Indoor Unit Connecting Indoor and Outdoor Electric Wires 1.Open the front panel. 2.Remove the wiring cover as shown in Fig 6. 3.Make the power connection cord pass through the hole at the back of indoor unit. 4.Reinstall the cord anchorage and wiring cover.
  • Page 31 Installation of Indoor Unit Installation of Indoor Unit External connection The piping can be output from right, right rear, left Gas side pipe electric wire ● Liquid side piping or left rear. When routing the piping and wiring from the left Tailing 2 or right side of indoor unit, cut off the tailings Gas side piping...
  • Page 32: Installation Of Outdoor Unit

    Installation of Outdoor Unit Electric Wiring Remove the handle on the right side plate of outdoor unit. Take off wire cord anchorage. Connect and fix power cord and power connect cord to the terminal board. Wiring should fit that of indoor unit. Handle Fix the power cord and power connect cord with wire clamps.
  • Page 33 Installation of Outdoor Unit Electric heating belt When outdoor ambient sensor malfunction happened, both of the electric heating belts stop working, otherwise, it will run at the following control :① When T outdoor ambient -5℃ and the compressor doesn't started, that the compressor electric heating belt starts to work; Otherwise if compressor started or compressor doesn't start but T outdoor ambient>-2℃...
  • Page 34: Check After Installation And Operation Test

    Check after Installation and Operation Test Check after Installation Items to be checked Possible malfunction Has the unit been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? It may cause condensation.
  • Page 35: Installation And Maintenance Of Healthy Filter(Optional)

    Installation and Maintenance of Healthy Filter(Optional) Installation of Healthy Filter Lift up the front panel from the two ends of it, as shown by the arrow direction, and (as shown in Fig.a) then remove the air filter. Fig. a Fig. b Attach the healthy filter onto the air filter, Air filter (as shown in Fig.b).
  • Page 36: Install Snow Guard(Optional)

    Install snow guard(Optional) Installation method of snow guard In consideration of snow during installation of outdoor units Note: It is required to equip snow guard and a higher foundation base to prevent snow from covering air inlet and outlet. Correct Incorrect The snow guard shall be wider than the...
  • Page 37 SERIES POLAR MODEL ASH‐09AIP PT ASH‐12AIP PT ASH‐18AIP PT ASH‐24AIP PT cooling 2,65 (0,45‐3,23) 3,53 (0,60‐3,96) 5,30 (1,05‐6,50) 6,45 (1,50‐7,00) Capacity heating 3,52 (0,45‐4,10) 4,10 (0,60‐5,13) 5,70 (1,00‐7,00) 7,00 (1,20‐7,80) Power supply 220‐240 220‐240 220‐240 220‐240 cooling 6,30 6,88 11,09 11,09 Power current heating 6,88 7,32 11,54 11,98 cooling 800 (200‐1350) 1100 (220‐1450) 1600 (360‐2500) 1985 (1500‐7000) Power input heating heating 950 (200‐1450)
