D o o r Ac t iv a ti o n D e v i c e s
CM-221M/CM-222M Touchless Exit Switch with
Remote LED Triggering
INSTALLATION INSTRUCTIONS
PARTS INCLUDED IN THE BOX
• (1) CM-221M/CM-222M Touchless Exit Switch with Manual Override pushbutton
• (1) Parts bag (Contents: (2) 6-32 X 1/2" oval head Phillips ss screws, (2) 6-32 X 1/2" snake eye s/s flat
head screws, (1) Key for tamper proof screws (snake eye), (1) Jumper for factory external LED control)
• (1) User/Installation Manual
• (1) Faceplate Gasket
1. GENERAL DESCRIPTION
The CM-221M/CM-222M Hands-Free Switch uses active
infra-red microburst sensor technology, designed for use in
ADA compliant automatic door control applications and access
control.
The CM-221M/CM-222M switches eliminate the spread of
germs by avoiding physical contact, and provide greater
convenience when moving through the premises. The switches
are available with stainless steel faceplates, in narrow (jamb) or
single gang.
All models are ROHS compliant with lead-free construction.
Built-in remote LED switching allows for integration with
third-party applications, such as guard and nurse station
annunciators. Adjustable time delay from 0.5 to 20 seconds
and an adjustable range from (2" to 8" / 5cm to 20cm).
2. SPECIFICATIONS
Voltage
Current
PIR Contact Rating
PIR Contacts
Temperature Range
Response Time
Pushbutton
Contact Rating
Pushbutton
Contacts
NOTE: Do NOT use AC Voltage for this unit.
Please see section 8 for power requirements
12 to 24 VDC +/- 10%
45 mA (peak)
1 Amp @ 30 VDC
Common/ N.O./ N.C.
14F to 122F (-10 to 50 °C)
10ms
1 Amp, 30 VDC
Common/N.O./N.C
Dimensions
LED Color
3. FEATURES
Built-in Red and Green LED indication. (CM-221M)
Factory default = Red (Standby), Green (Triggered)
Built-in Blue and Green LED indication. (CM-222M)
Factory default = Blue (Standby), Green (Triggered)
Red/Blue and Green LEDs can be controlled by sensor or
externally
Adjustable detecting distance: 2 to 8 Inches (5 cm to 20 cm)
Adjustable Time Delay: 0.5 seconds to 20 seconds
Toggle function selection available
IP65 rating
IR lens to provide stable and reliable operation
4. OPERATION AT A GLANCE
In a typical application, as you approach the CM-221M/CM-
222M, the LED will be red/blue. When you wave your hand
in front it will change the LED to green, and trigger its relay
to change state and unlock your door, or trigger the door
operator to open the door. The toggle feature can be used to
trigger the door to remain in the unlocked position, until you
wave your hand a second time to relock it.
Narrow:
1 3/4" W x 4 1/2" H x 1 1/4" D
(43 mm x 114 mm x 31 mm)
Single Gang:
2 3/4" W x 4 1/2" H x 1 1/4" D
(70 mm x 114 mm x 31 mm)
CM-221M: Red and Green
CM-222M: Blue and Green
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the CM-221M and is the answer not in the manual?

Questions and answers

Summary of Contents for CAMDEN CM-221M

  • Page 1 INSTALLATION INSTRUCTIONS PARTS INCLUDED IN THE BOX • (1) CM-221M/CM-222M Touchless Exit Switch with Manual Override pushbutton • (1) Parts bag (Contents: (2) 6-32 X 1/2" oval head Phillips ss screws, (2) 6-32 X 1/2" snake eye s/s flat head screws, (1) Key for tamper proof screws (snake eye), (1) Jumper for factory external LED control) •...
  • Page 2 Range of Detection and Output Duration Looking at the back of the CM-221M/CM-222M with the Mode pins located at the top, you will see two adjustment potentiometers. The one on the left can be turned clockwise to set the range of detection (2” to 8” / 5cm to 20cm), and the one on the right will set the duration of the output (0.5 to 20 seconds).
  • Page 3: Installation Instructions

    Jumper the PIR sensor blue (common) and red (power +) wires and then connect them to the (+) positive terminal of the DC power supply. Wire the PIR sensor black (-) wire to the negative (-) terminal of the DC power supply. CM-221M/CM-222M Touchless Switch with manual pushbutton wired to maglock Jumper must be OFF, the two...
  • Page 4 2. Connection to a Door Operator CX-PS13 Power Supply Button 12 or 24 VDC SPDT switch to CM-221M/CM-222M Touchless Switch wired to door operator. (Remote LED control) B- B+ DC- DC+ AC AC remotely control the green and red LEDs. CM-221M/CM-222M Touchless...
  • Page 5 INSTAL L AT ION INS T RUCT IONS 7. POWER The CM-221M/CM-222M is a VDC device only and will accept a range of VDC power from 12VDC to 24VDC (+/- 10%). Do not connect AC voltage to the CM-221M/CM-222M at any time.
  • Page 6: Parts Kit

    CM-221M/CM-222M TOUCHLESS EXIT SWITCH WITH REMOTE LED TRIGGERING I NS TA L L AT IO N I NST RUCT I ONS ORDERING INFORMATION FOR REPLACEMENT PARTS ITEM NUMBER PART NUMBER DESCRIPTION 60-31A083 TOUCHLESS SENSOR SWITCH WITH EXTERNAL LED CONTROL (RED AND GREEN)
