  • Page 1 Automatic Electric Washing Machine User manual WD19J9*****/WD21J9***** WD19J9810KG_DC68-03474G-01-EN.indd 1 2016/6/17 19:05:05...
  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions To minimize the risk of fire in a tumble dryer, the following should b observed Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Installation...
  • Page 3 Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Specifications English 3 WD19J9810KG_DC68-03474G-01-EN.indd 3 2016/6/17 19:05:05...
  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.
  • Page 5: Important Safety Precautions

    These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist.
  • Page 6 Safety information 4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 5. The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.
  • Page 7 14. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
  • Page 8: To Minimize The Risk Of Fire In A Tumble Dryer, The Following Should B Observed

    Safety information To minimize the risk of fire in a tumble dryer, the following should b observed CAUTION Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected items can ignit spontaneously, especially when exposed to heat sources such as in a tumble dryer.
  • Page 9 Items such as foam rubber(latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in th tumble dryer. Fabric softeners, or similar products, should be used as specified by the fabric softene instructions.
  • Page 10: Critical Installation Warnings

    Safety information Critical installation warnings WARNING The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, therefore take care when lifting it.
  • Page 11: Installation Cautions

    Do not install this appliance in a location where gas may leak. • This may result in electric shock or fire. Do not use an electric transformer. • This may result in electric shock or fire. Do not use a damaged power plug, damaged power cord, or loose wall socket. • This may result in electric shock or fire.
  • Page 12 Safety information If the appliance generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact your nearest service centre. • Failure to do so may result in electric shock or fire. In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power plug.
  • Page 13: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact your nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 14 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 15 (*): Woollen bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers, sweat suits, and bicycle, motor cycle and car covers, etc. • Do not wash thick or hard mats even if the washing machine mark is on the care label. This may result in injury or damage to the washing machine, walls, floor, or clothing due to abnormal vibrations.
  • Page 16: Critical Cleaning Warnings

    Safety information • This may result in problems with the washing machine. Do not use natural hand-washing soap for the washing machine. • If it hardens and accumulates inside the washing machine, it may result in problems with the product, discolouration, rust, or bad odours. Place socks and brassieres in a washing net and wash them with the other laundry.
  • Page 17: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. 01 Detergent drawer 02 Door...
  • Page 18 • Hot water hose: Applicable models only. • The appearance of the machine and provided accessories may differ with the model. • If you lose an accessory and want to purchase a replacement, contact a local Samsung customer center or the retailer.
  • Page 19: Installation Requirements

    Drain • Improperly connected grounding Samsung recommends a standpipe in conductors may cause electric shock. height of 60-90 cm. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose.
  • Page 20: Water Temperature

    Installation Flooring Alcove installation For best performance, the washing Minimum clearance for stable operation: machine must be installed on a solid floor. Sides 25 mm Wood floors may need to be reinforced 25 mm to minimize vibration and/or unbalanced loads. Carpeting and soft tile surfaces are Rear 50 mm not a good resistance to vibrations and...
  • Page 21: Step-By-Step Installation

    Step-by-step installation STEP 1 Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) • Away from a heat source STEP 2 Remove the shipping bolts Unpack the product package and remove...
  • Page 22 Installation 3. Close all plastic bolt caps on the rear of the washing machine. WARNING Packaging materials can be dangerous to children. Dispose all packaging material (plastic bags, polystyrene, etc.) out of children’s reach. English WD19J9810KG_DC68-03474G-01-EN.indd 22 2016/6/17 19:05:08...
  • Page 23 STEP 3 Adjust the levelling feet 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet. 2. Level the washing machine by manually adjusting the levelling feet. The levelling feet can be loosened using the provided spanner.
  • Page 24 Installation STEP 4 Connect the water hose The provided hose adaptor may differ with the model. This step guides you through connecting the connector-type adaptor. If you are provided with the screw-type adaptor, go to 7. Connect the water hose to the water tap. 1.
  • Page 25 6. While holding down part (E), connect the water hose to the adaptor. Then, release part (E). The hose fits into the adaptor with a clicking sound. 7. If you are using a screw type of water tap, use the provided screw-type adaptor to connect to the water tap as shown.
  • Page 26 WARNING If there is a water leak, stop operating the washing machine and disconnect from the electrical supply. Then, contact a local Samsung service centre. Otherwise, this may cause electric shock. CAUTION Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-pressure hose.
  • Page 27 For models with an additional hot water inlet: 1. Connect the red end of the hot water hose to the hot water inlet on the back of the machine. 2. Connect the other end of the hot water hose to the hot water tap. CAUTION As the hot water temperature can only be controlled by hot water-related cycles,...
  • Page 28 Installation STEP 5 Connect the drain hose 1. Press the catches of the clamp (A) and insert the drain hose into the clamp. 2. Insert the drain hose into the extension hose (C) of the washing machine firmly by pressing the catches of the clamp. Then, release them to fix the drain hose (B).
  • Page 29 STEP 6 Position the drain hose CAUTION Improperly connecting the drain hose may cause drainage problems. This may result in degraded drying performance. Read all instructions below and follow them explicitly before connecting the drain hose. • Do not twist, fold, or bend the drain hose excessively.
  • Page 30: Before You Start

    Before you start Initial settings Run Calibration (recommended) Calibration ensures accurate weight detection by the washing machine. Make sure the drum is empty before running Calibration. 1. Power off, and then power on the washing machine. 2. Hold down Temp. and Delay End simultaneously for 3 seconds to enter Calibration mode.
  • Page 31: Laundry Guidelines

    Laundry guidelines STEP 1 Sort STEP 2 Empty pockets Sort the laundry according to these Empty all the pockets of your laundry criteria: items • Care Label: Sort the laundry into • Metal objects such as coins, pins, and cottons, mixed fibres, synthetics, silks, buckles on clothing may damage other wools, and rayon.
  • Page 32 Before you start STEP 4 Determine the load capacity STEP 5 Apply a proper detergent type Do not overload the washing machine. The type of detergent depends on the Overloading may cause the washing type of fabric (cotton, synthetic, delicate machine to not wash properly.
  • Page 33: Detergent Drawer Guidelines

    Detergent drawer guidelines The washing machine provides a three-compartment dispenser: the left compartment for the main wash, the front-right for fabric softeners, and the rear-right for the preliminary wash. Main-wash compartment: Apply main-wash detergent, water softener, soaking detergent, bleach, and/or stain removers.
  • Page 34 Before you start 3. Apply an appropriate amount of fabric softener to the front-right compartment if necessary. Do not exceed the max line (A) which is marked on the compartment. To use liquid detergent (applicable models only) To use a liquid detergent, first put the provided liquid detergent container in the main wash detergent compartment Then, apply an appropriate amount of...
  • Page 35: Operations

    Operations User interface 01 Cycle Selector Turn the dial to select a cycle. The display shows current cycle information and estimated time 02 Display remaining, or an information code if the washer needs to be checked. 03 Temp. Press to change the water temperature for the current cycle. Press to change the rinse count for the current cycle.
  • Page 36: Simple Steps To Start

    Operations Simple steps to start 1. Press POWER to turn on the washer. 2. Turn the Cycle Selector to select a cycle. 3. Change the cycle settings (Temp., Rinse, and Spin) as necessary. 4. Select desired options as necessary. 5. Press START/PAUSE. To change the cycle during operation 1.
  • Page 37 Cycle overview Max load (kg) Cycle Description 19 kg 21 kg For cottons, bed linens, table linens, underwear, towels, or shirts. The washing time and the rinse NORMAL count are automatically adjusted according to the load. • For colorfast fabrics and heavily soiled garments, this program heats the supplied water up to 95 °C to eliminate bacteria.
  • Page 38 Operations Max load (kg) Cycle Description 19 kg 21 kg Removes bad odors and bacteria from the SANITIZATION laundry. PILLOW CARE Restores the Down jacket to fluffy stat. Use this cycle to restore the water resistant OUTDOOR performance, and didn’t damage to the cloth with REFRESH Goretex material.
  • Page 39: Delay End

    AIR Wash cycle AIR Wash refreshes laundry through Samsung’s unique air-washing technology without the need for water. AIR Wash is not a drying cycle. Use this only for dried laundry. CAUTION Do not use any AIR Wash cycle for the following items: • Heat-sensitive cycles made from leather, mink, fur, or silk...
  • Page 40: Special Features

    Operations Special features AddWash When the AddWash indicator is on, you can stop operation of the machine and put additional laundry or softener into the drum. The Add Door opens by more than 130° for easy access. 1. Press START/PAUSE to stop operation. 2.
  • Page 41 CAUTION • Do not put excessive force on the Add Door. It may break. • Do not open the Add Door if suds have formed inside the drum that rise above the level of the Add Door. • Do not attempt to open the Add Door while the machine is operating without first pressing START/PAUSE.
  • Page 42: Settings

    Operations Settings Child Lock NOTE Child Lock is designed to prevent accidents • Child Lock stays active after the by children or the elderly and infirm machine powers off. To add laundry, Child Lock locks all buttons except for the you must deactivate Child Lock first POWER button.
  • Page 43: Maintenance

    Maintenance Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Drum Clean Perform this cycle regularly to clean the drum and to remove bacteria from it. Press POWER to turn on the washing machine. 1.
  • Page 44: Emergency Drain

    Maintenance Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off the washer, and then unplug it from the electrical outlet. 2. Gently press the top area of the filte cover to open.
  • Page 45 Cleaning Surface of the washing machine Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine. Add Door 1. Open the Add Door. 2. Use a wet cloth to clean the Add Door. - Do not use cleaning agents.
  • Page 46 Maintenance Mesh filter Clean the mesh filter of the water supply hose once or twice a year. 1. Turn off the washing machine, and unplug the power cord. 2. Close the water tap. 3. Loosen and disconnect the water supply hose from the back of the washing machine.
  • Page 47: Pump Filter

    Pump filter It is advisable to clean the pump filter 5 or 6 times a year to prevent its clogging. A clogged pump filter may reduce the bubble effect. 1. Turn off the washing machine, and unplug the power cord. 2.
  • Page 48: Detergent Drawer

    Maintenance Detergent drawer 1. While holding down the release lever (A) on the inner of the drawer, slide open the drawer. 2. Remove the release lever and the Liquid detergent guide from the drawer. 3. Clean the drawer components in flowing water using a soft brush.
  • Page 49: Recovery From Freezing

    Recovery from freezing The washing machine may freeze when it drops below 0 °C. 1. Turn off the washing machine, and unplug the power cord. 2. Pour warm water over the water tap to loosen the water supply hose. 3. Disconnect the water supply hose, and soak it in warm water. 4.
  • Page 50: Troubleshooting

    • Make sure the Auto Dispense function is enabled, with both the Water Hardness and Density settings properly specified. If a problem persists, contact a local Samsung service centre. English WD19J9810KG_DC68-03474G-01-EN.indd 50 2016/6/17 19:05:19...
  • Page 51: Information Codes

    Information codes If the washing machine fails to operate, you may see an information code on the screen. Check the table below and try the suggestions. Code Action Check the water level sensor. • Power off and power the machine on after 2-3 minutes, and then try again.
  • Page 52 • If the drain filter is clogged, clean the filter and restart the machine. Check the washing heater. • Power off the machine and contact a local Samsung service centre. Check the drying heater. • Power off and power the machine on after 2-3 minutes, and then try again.
  • Page 53 • Check if the power cord is plugged in properly. • If the information code continues to appear, call for service. For more information, see the user manual. If any of the information codes continues to appear, contact a local Samsung service centre. English 53 WD19J9810KG_DC68-03474G-01-EN.indd 53...
  • Page 54: Specifications

    Specifications Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items.
  • Page 55: Protecting The Environment

    Protecting the environment • This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.
  • Page 56: Specifications

    Memo Specifications “ * “ Asterisk(s) means variant model and can be varied (0-9) or (A-Z). The manufacturer’s name and/or his trademark Country of origin MADE IN CHINA The type number WD19J9810KG WD21J9810KP Kind of washing machine Automatic electric Washing machine Washing system Washing machine with drum system Rated voltage (volts)
  • Page 57 • The washing machine shall not be installed at a humid place. • The wringer must be switched off when not in use. • The washing machine must not be operated by children. • The appearance and specifications of the product are subject to change without prior notice for purposes of product enhancement.
  • Page 58 Memo WD19J9810KG_DC68-03474G-01-EN.indd 58 2016/6/17 19:05:22...
  • Page 59 Memo WD19J9810KG_DC68-03474G-01-EN.indd 59 2016/6/17 19:05:22...
  • Page 60 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.samsung.com/sa/support SAUDI ARABIA 8002474357 www.samsung.com/sa_en/support (English) DC68-03474G-01 WD19J9810KG_DC68-03474G-01-EN.indd 60 2016/6/17 19:05:22...
