Washing Machine
User manual
WD1*T******/WD9*T******/WD8*T******/WD7*T******
U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 1
2022/4/16 11:05:15

Advertisement

Table of Contents
loading

Related Manuals for Samsung WD7 T Series

Summary of Contents for Samsung WD7 T Series

  • Page 1 Washing Machine User manual WD1*T******/WD9*T******/WD8*T******/WD7*T****** U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 1 2022/4/16 11:05:15...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Instructions about the WEEE Installation What’s included Installation requirements Step-by-step installation Before you start Initial setup...
  • Page 3 Maintenance Drum clean+ Emergency drain Cleaning Defrosting your washing machine Care against an extended time of disuse Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Spare parts guarantee Specification sheet Contact information QUESTIONS OR COMMENTS? English 3 U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 3 2022/4/16 11:05:15...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 Safety information 10. The lint trap has to be cleaned frequently, if applicable. 11. Lint must not to be allowed to accumulate around the tumble dryer. (not applicable for appliances intended to be vented to the exterior of the building) 12.

  • Page 7: Critical Installation Warnings

    23. This appliance is intended to be used in household only and it is not intended to be used such as: ‒ staff kitchen areas in shops, offices and other working environments; ‒ farm houses; ‒ by clients in hotels, motels and other residential type environments; ‒...

  • Page 8: Installation Cautions

    Following the repair by a non-authorized service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.

  • Page 9: Critical Usage Warnings

    Critical usage warnings WARNING If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest service centre. • Do not touch the power plug with wet hands. • Failure to do so may result in electric shock. If the appliance generates a strange noise, a burning smell, or smoke, unplug the power cord immediately and contact your nearest service centre.

  • Page 10: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power cord and contact your nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 11 Using the appliance for business purposes qualifies as an appliance misuse. In this case, the appliance will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 12 Safety information Also, do not allow children to play around the washing machine or touch the door glass. • This may result in burns. Do not insert your hand into the detergent drawer. • This may result in injury as your hand may be caught by the detergent input device. Remove the liquid detergent guide (applicable models only) when using powdered detergent.

  • Page 13: Critical Cleaning Warnings

    This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com English 13...

  • Page 14: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. 01 Auto dispenser 02 Release lever...
  • Page 15 Spanner Bolt caps Hose guide Cold water hose Hot water hose Accessories (not supplied) • Stacking kit : SK-DH Staking kit is required to stack a dryer on a washing machine. NOTE • Spanner: For removing the shipping bolts and levelling the washing machine. •...

  • Page 16: Installation Requirements

    • Improperly connected grounding conductors may cause electric shock. Drain Samsung recommends a standpipe 60-90 cm high. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose.
  • Page 17 Flooring Alcove installation For best performance, the washing machine must Minimum clearance for stable operation: be installed on a solid floor. Wood floors may need Sides 25 mm to be reinforced to minimise vibration and/or 25 mm unbalanced loads. Carpeting and soft tile surfaces Rear 50 mm do not resist vibration well and may cause the...

  • Page 18: Step-By-Step Installation

    Installation Step-by-step installation STEP 1 Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 °C) •...
  • Page 19 1. Locate the shipping bolts (marked with circle in the figure) on the rear side of the washing machine. CAUTION Do not remove the screw (A) that fixes the hose clip. 2. Using the supplied spanner, loosen all the shipping bolts by turning them anticlockwise.
  • Page 20 Installation 3. Insert the bolt caps (B) to the holes (marked with circle in the figure). English U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 20 2022/4/16 11:05:17...
  • Page 21 STEP 3 Adjust the levelling feet 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet. 2. Level the washing machine by manually adjusting the levelling feet. 3. When levelling is complete, tighten the nuts using the spanner. CAUTION When installing the product make sure the levelling feet is not pressing the power cord.
  • Page 22 If there is a water leak, stop operating the washing machine and disconnect it from the electrical supply. Then, contact a local Samsung service centre in case of a leak from the water hose, or contact a plumbing technician in case of a leak from the water tap. Otherwise, this may cause electric shock.
  • Page 23 Connecting to a non-threaded water tap 1. Remove the adaptor (A) from the water hose (B). 2. Use a Phillips screwdriver to loosen four screws on the adaptor. 3. Hold the adaptor and turn part (C) in the arrow direction to loosen it by 5 mm (*). 4.
  • Page 24 Installation 6. While pulling down part (D) on the water hose, connect the water hose to the adaptor. Then, release part (D). The hose fits into the adaptor with a clicking sound. 7. To complete connecting the water hose, see 2 and 3 on the “Connecting to a threaded water tap”...
  • Page 25 Aqua stop hose (applicable models only) The aqua stop hose alerts users of a risk of water leaks. It senses the water flow and turns red on the centre indicator (A) in case of a leak. NOTE The end of the aqua stop hose must be fitted to the water tap and not the machine. English 25 U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 25 2022/4/16 11:05:19...
  • Page 26 Installation STEP 5 Position the drain hose The drain hose can be positioned in three ways: Over the edge of a wash basin The drain hose must be placed between 60 cm and 90 cm (*) above from the floor. To keep the spout of the drain hose bent, use the supplied plastic hose guide (A).
  • Page 27 In a sink drain pipe branch The drain pipe branch must be above the sink siphon so that the end of the hose is at least 60 cm above the ground. (*) : 60 cm CAUTION Remove the lid on the sink drain pipe branch before connecting the drain pipe to it.

  • Page 28: Before You Start

    Before you start NOTE Before doing your laundry for the first time, you must run a complete wash cycle without any items in the drum. Initial setup • When you turn on the washing machine for the first time, the screen shows the initial setup process. Follow the on-screen instructions to complete it.

  • Page 29: Laundry Guidelines

    Laundry guidelines STEP 1 Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon. • colour: Separate whites from colours. • Size: Mixing different sized items together in the drum improves the washing performance. •...
  • Page 30 Before you start STEP 5 Determine the load capacity Do not overload the washing machine. Overloading may cause the washing machine to not wash properly. For the load capacity for the type of clothing, see page 39. NOTE When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be reduced.
  • Page 31 Laundry capsules To get the best results from using laundry capsules, please follow these instructions. 1. Put the capsule in the bottom of the empty drum towards the rear. 2. Put the laundry in the drum on top of the capsule. CAUTION For cycles using cold water or cycles that complete in less than one hour, the capsule may not dissolve completely.

  • Page 32: Detergent Recommendation

    Before you start Detergent recommendation The recommendations apply to the temperature ranges given in the cycle chart. Recommended Liquid detergent only   – Not recommended Powder detergent only  Detergent Cycle Temp. (°C) Delicates and Universal Specialist woollens Eco 40-60 40~60 ...

  • Page 33: Detergent Drawer Guidelines

    Detergent drawer guidelines The automatic dispenser models provide a three-compartment dispenser: two compartments for auto- dispensing and another part for manual input. With the automatic dispensing option on, the washing machine dispenses an adequate amount of detergent or fabric softener for each load. See below for details: A.
  • Page 34 Before you start CAUTION • Do not operate the washing machine with the compartments not placed in the detergent drawer. A water leak may cause electric shock or injury. • Do not use the following types of detergent in the drawer. Tablet, capsule, ball, or net types.
  • Page 35 1. Pull the detergent drawer to open. 2. Turn the auto detergent compartment cover (A) anticlockwise to open. 3. Apply an appropriate amount of detergent to the auto detergent compartment (B). After you finish, put the cover back and turn it clockwise to close.
  • Page 36 Before you start CAUTION • Do not apply detergent/softener to the drawer without the detergent/softener compartment. If you do, clean the drawer and then reinsert both compartments. • Use only liquid detergent/softener with the detergent/softener compartments. Do not use powdered detergent.

  • Page 37: Operations

    Operations NOTE The cycle and function names that appeared in this manual may differ from your product. Control panel Tap to turn the washing machine on or off. • If you do not manipulate the control panel for 10 minutes after the washing machine is turned on, the washing machine automatically turns off.

  • Page 38: Operating A Cycle

    Operations Tap to activate or deactivate the Smart Control function. Tap and hold to enter pairing mode to connect to the SmartThings app. 10 Smart Control • When the Smart Control function is activated, you can control your washing machine remotely using the SmartThings app on your smartphone or tablet (Android or iOS).

  • Page 39: Cycle Overview

    Cycle overview Cycle descriptions Max load (kg) Cycle Description • For cleaning normally soiled cotton items which are declared to be washable at 40 °C or 60 °C, together Eco 40-60 in the same cycle. This cycle is used to assess the Max Max Max compliance with the EU Ecodesign legislation.
  • Page 40 Operations Max load (kg) Cycle Description • For bed spreads, bed sheets, bedding covers, etc. Bedding • For best results, wash only 1 type of bedding. • For shirts, blouses that are made of cotton, synthetic Shirts fiber. • Cotton and linen fabric which have been in direct contact with the skin, such as underwear.
  • Page 41 Max load (kg) Cycle Description • Cleans the drum by removing dirt and bacteria from it. Drum Clean+ • Cleans the rubber door gasket by removing dirt from (WD**T9*****, the gasket. WD**T8*****, • Perform once every 40 washes with no detergent or WD**T7*****, bleach applied.

  • Page 42: Additional Functions

    Operations Additional functions Using Additional Functions 1. Tap 2. Turn the Navigation dial to select the desired additional function. 3. Tap to change the selected function’s settings or start the function. NOTE • To return to the main screen, tap again or turn the Navigation dial to select Back and tap •...
  • Page 43 Prewash You can add a preliminary washing cycle before the main wash cycle. 1. Select a cycle and change the cycle settings as necessary. 2. Tap 3. Turn the Navigation dial to select Prewash, and then tap 4. Tap and hold Bubble Soak This function helps remove a wide variety of stubborn stains.
  • Page 44 Operations My Cycles Add or remove cycles to create a personal cycle list. 1. Tap 2. Turn the Navigation dial to select My Cycles, and then tap You can only edit a cycle to create a personal cycle when the washing machine is not operating. 3.
  • Page 45 Child Lock To prevent children or infants from accidentally starting or setting the washing machine, Child Lock locks all buttons except for 1. Tap 2. Turn the Navigation dial to select Child Lock, and then tap 3. Tap to select On or Off. The Child Lock icon turns on when the function is on.

  • Page 46: System Functions

    Operations System functions Using System Functions 1. Tap and hold for 3 seconds. 2. Turn the Navigation dial and select the desired system function, and then tap 3. Tap to change the selected function’s settings or start the function. NOTE To return to the main screen, tap again or turn the Navigation dial to select Back and tap Water Hardness...
  • Page 47 Alarm You can turn on or off the melody of cycle completion. However, the other sounds stay active. 1. Tap and hold for 3 seconds. 2. Turn the Navigation dial to select Alarm, and then tap 3. Tap to select On or Off. The default setting is On.

  • Page 48: Special Features

    Operations Language You can change the system language. 1. Tap and hold for 3 seconds. 2. Turn the Navigation dial to select Language, and then tap 3. Turn the Navigation dial to select the desired language, and then tap Factory Reset You can reset the washing machine.
  • Page 49 CAUTION • Do not open the AddWash door if suds have formed inside the drum that rise above the level of the AddWash door. • Do not attempt to open the AddWash door while the machine is operating without first tapping and holding .
  • Page 50 Operations • Check your router if you experience any Internet connection problem after connecting your washing machine with the SmartThings app. • If the Wi-Fi is off, tap and hold for 3 seconds to enter the System functions menu, and select Wi-Fi to turn it on.

  • Page 51: Smartthings

    You don’t need a separate app to create your account. NOTE If you have a Samsung account, use the account to log in. A registered Samsung smartphone or tablet user automatically logs in. To register your appliance to SmartThings 1.

  • Page 52: Open Source Announcement

    (Please use the “Inquiry” menu.) It is also possible to obtain the complete corresponding source code in a physical medium such as a CD- ROM;...

  • Page 53: Maintenance

    Maintenance Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Drum clean+ Perform this cycle regularly to clean the drum by removing bacteria from it. This cycle heats the water between 60 °C and 70 °C, and it also removes accumulated dirt from the rubber door gasket. 1.

  • Page 54: Emergency Drain

    Maintenance Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off and unplug the washing machine from the electrical outlet. 2. Open the filter cover . TYPE 1: Push down the latch of the filter cover to open.

  • Page 55: Cleaning

    Cleaning Surface of the washing machine Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine. AddWash door (applicable models only) 1. Open the AddWash door. 2. Use a wet cloth to clean the AddWash door. Do not use cleaning agents.
  • Page 56 Maintenance Mesh filter Clean the mesh filter of the water hose once or twice a year. 1. Turn off the washing machine, and unplug the power cord. 2. Close the water tap. 3. Loosen and disconnect the water hose from the back of the washing machine.
  • Page 57 Debris filter It is advisable to clean the debris filter every 2 months to prevent its clogging. A clogged debris filter may reduce the bubble effect. 1. Turn off the washing machine, and unplug the power cord. 2. Drain the remaining water inside the drum. See the Emergency drain section.
  • Page 58 Maintenance Detergent drawer To prevent the detergent residue buildup in the detergent drawer, clean the detergent drawer once or twice a month, and whenever you refill or change the detergent or softener. CAUTION • Make sure to turn off the washer and unplug the power cord before cleaning. •...
  • Page 59 4. Insert the detergent drawer back into the washing machine. NOTE • Make sure the drawer recess is completely dry before inserting the detergent drawer. • Cover the tops of both compartments and re-insert them into the drawer. CAUTION Do not spray water into the detergent drawer recess. It may cause electric shock or fire. English 59 U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 59 2022/4/16 11:05:27...

  • Page 60: Defrosting Your Washing Machine

    Maintenance Defrosting your washing machine The washing machine may freeze when it drops below 0 °C. 1. Turn off the washing machine, and unplug the power cord. 2. Pour warm water over the water tap to loosen the water hose. 3.

  • Page 61: Troubleshooting

    Troubleshooting If there is any problem, check the information message on the LCD screen and follow the on-screen instructions. If the problem persists, please contact the service center. Checkpoints If you encounter a problem with the washing machine, first check the table below and try these suggestions.
  • Page 62 Troubleshooting Problem Action • Make sure the washing machine is installed on a level, solid floor that is not slippery. If the floor is not level, use the levelling feet to adjust the height of the washing machine. • Make sure the shipping bolts are removed. •...
  • Page 63 Problem Action • Make sure you use the recommended types of detergent as appropriate. • Use high efficiency (HE) detergent to prevent oversudsing. Excessive suds. • Reduce the detergent amount for soft water, small loads, or lightly soiled loads. • Non-HE detergent is not recommended. Cannot add additional •...
  • Page 64 Troubleshooting Problem Action • Make sure the door is properly closed. • Make sure all hose connections are tight. • Make sure the end of the drain hose is correctly inserted and secured to the drain system. • Avoid overloading. Leaks water.

  • Page 65: Information Codes

    Information codes If the washing machine fails to operate, you may see an information code on the screen. Check the table below and try the suggestions. Code Action Water is not draining. • Make sure the drain hose is not frozen or clogged. •...
  • Page 66 Water has overflowed. • Restart after spinning. • If the information code remains on the display, contact a local Samsung service centre. Check the drain hose. • Make sure the end of the drain hose is not placed on the floor.
  • Page 67 The drying heater is not working properly. • Turn the machine off, and restart the cycle. • If the information code remains, contact a local Samsung service centre. If any information code keeps appearing on the screen, contact a local Samsung service centre. English 67 U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 67...

  • Page 68: Specifications

    Specifications Fabric care chart Bleaching The following symbols provide garment care direction. The Clothing care labels include Any bleach allowed. symbols for drying, bleaching, drying and ironing, or dry cleaning when necessary. The use of Only oxygen bleach allowed. symbols ensures consistency among garment Do not bleach.

  • Page 69: Protecting The Environment

    Ironing Professional dry-cleaning in hydrocarbons (heavy benzines) with Iron at maximum sole plate normal process. temperature of 200 °C. Professional dry-cleaning in Iron at maximum sole plate hydrocarbons (heavy benzines) with temperature of 150 °C. gentle process. Iron at maximum sole plate temperature of 110 °C.

  • Page 70: Spare Parts Guarantee

    • Door, door hinges and seals, other seals, door locking assembly, and plastic peripherals such as detergent dispensers. • Listed parts can be purchased at below website. http://www.samsung.com/support Specification sheet “*” Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
  • Page 71 Type Front loading washing machine Model name WD1*T***** A (Width) 600 mm B (Height) 850 mm C (Depth) 600 mm Dimensions 690 mm (WD**T*8****, WD**T*5****) 680 mm (WD**T*3****, WD**T*0****) 1120 mm Water pressure 50-1000 kPa Net weight 80 kg Washing and 10.5 kg spinning Maximum load capacity...
  • Page 72 Specifications Type Front loading washing machine WD9*T7***** Model name WD9*T9***** WD9*T6***** WD9*T5***** A (Width) 600 mm 600 mm B (Height) 850 mm 850 mm C (Depth) 600 mm 650 mm 690 mm (WD**T*8****, 740 mm (WD**T*8****, Dimensions WD**T*5****) WD**T*5****) 680 mm (WD**T*3****, 730 mm (WD**T*3****, WD**T*0****) WD**T*0****)
  • Page 73 Type Front loading washing machine WD8*T7***** WD8*T9***** WD8*T6***** Model name WD8*T8***** WD8*T5***** WD8*T4***** A (Width) 600 mm 600 mm B (Height) 850 mm 850 mm C (Depth) 600 mm 600 mm 690 mm (WD**T*8****, 690 mm (WD**T*8****, Dimensions WD**T*5****) WD**T*5****) 680 mm (WD**T*3****, 680 mm (WD**T*3****, WD**T*0****)
  • Page 74 Specifications Type Front loading washing machine Model name WD7*T****** A (Width) 600 mm B (Height) 850 mm C (Depth) 550 mm Dimensions 630 mm (WD**T*5****) 620 mm (WD**T*3****, WD**T*0****) 1070 mm Water pressure 50-1000 kPa Net weight 63 kg Washing and 7.0 kg spinning Maximum load capacity...
  • Page 75 Indicative information (According to EU 2019/2023) (WD********* models only) Energy Water Maximum Remaining Program Time Spinning Model Cycles Capacity (kg) Consumption Consumption (L/ Temperature Moisture (HH:MM) Speed (RPM) (kWh/Cycle) cycle) (°C) Content (%) 3:05 0.795 72.0 53.0 1400 Eco 40-60 2:18 0.381 42.0...
  • Page 76 Specifications Energy Water Maximum Remaining Program Time Spinning Model Cycles Capacity (kg) Consumption Consumption (L/ Temperature Moisture (HH:MM) Speed (RPM) (kWh/Cycle) cycle) (°C) Content (%) 3:42 0.966 73.0 53.0 1400 Eco 40-60 2:54 0.527 42.0 53.0 1400 2:44 0.265 35.0 53.0 1400 Cotton 20 °C...
  • Page 77 Energy Water Maximum Remaining Program Time Spinning Model Cycles Capacity (kg) Consumption Consumption (L/ Temperature Moisture (HH:MM) Speed (RPM) (kWh/Cycle) cycle) (°C) Content (%) 3:28 1.130 63.0 53.0 1400 Eco 40-60 2:42 0.547 36.0 53.0 1400 2:42 0.207 29.0 53.0 1400 Cotton 20 °C 3:19...

  • Page 78: Contact Information

    DENMARK 707 019 70 www.samsung.com/dk/support FINLAND 030-6227 515 www.samsung.com/fi/support SWEDEN 0771 726 786 www.samsung.com/se/support AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support www.samsung.com/ch/support (German) SWITZERLAND 0800 726 786 www.samsung.com/ch_fr/support (French) HUNGARY 0680SAMSUNG (0680-726-7864) www.samsung.com/hu/support CZECH 800 - SAMSUNG (800-726786) www.samsung.com/cz/support...
  • Page 79 0800872678. ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support 8009 4000 only from landline, toll CYPRUS free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) only from land line GREECE (+30) 210 6897691 from mobile and land line 801-172-678* lub +48 22 607-93-33* POLAND http://www.samsung.com/pl/support/ * (opłata według taryfy operatora)
  • Page 80 U-PJT_COMBO-AD_SimpleUX_WEB_SSEC-02__EU_English.indd 80 2022/4/16 11:05:32...
