INKA 356
INKA356 230V, INKA356 230V Syncro³, INKA356 24V, INKA356 24V Syncro³
INSTRUCTION MANUAL
CHAIN ACTUATOR
EN
Force 350N – Strokes 300, 600, 800, 1000 mm
Electrical feeding 110-230V~ 50/60Hz and 24V
NEKOS S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa – VI – ITALY
+39 0424 411011 – +39 0424 411013 - www.nekos.it - info@nekos.it
4420085 – Rev. 20230428
Advertisement
Table of Contents
Related Manuals for nekos INKA 356 Series
Summary of Contents for nekos INKA 356 Series
- Page 1 Force 350N – Strokes 300, 600, 800, 1000 mm Electrical feeding 110-230V~ 50/60Hz and 24V NEKOS S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa – VI – ITALY +39 0424 411011 – +39 0424 411013 - www.nekos.it - info@nekos.it...
- Page 2 USER INSTRUCTIONS CAUTION. Carefully observe following installation instructions to ensure personal safety. The device is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lacking experience and knowledge. Do not allow children to play with the fixed controls and keep any remote-control units out of their reach.
-
Page 3: Table Of Contents
INSTALLER INSTRUCTIONS nekos products have been manufactured in accordance with safety standards and conforms to the stipulations of current standards in force. When correctly assembled, installed and used according to the present instructions, they will not generate any danger for persons, animals or items. -
Page 4: Security Rules
SAFETY MANDATORY RISK ANALYSIS AND PROTECTION MEASURES The Nekos electrical actuators comply with the Machinery Directive (2006/42/EC), Standard IEC 60335-2-103 (Particular requirements for drives for gates, doors and windows) and other directives and regulations indicated in the attached Declarations of Incorporation and CE Declarations of Conformity (at the end of the manual). -
Page 5: Formulas And Recommendations For Installation
2. FORMULAS AND RECOMMENDATIONS FOR INSTALLATION 2.1. Calculation of opening / closure force Using the formulas on this page, approximate calculations can be made for the force required to open or close the window considering all the factors that determine the calculation. -
Page 6: Maximum Opening According To Height Of Sash
³ version the actuator has been equipped with the new system patented by SYNCRO NEKOS for coordinated synchronisation of a group of actuators (up to eight at the same time). Electronic control of speed is completely automatic device inside the actuator and does not require any external control station: just connect the feeder cable communication wires to each other (see diagram on page 16) and carry out reset procedure. -
Page 7: General Information About The Actuator
4. GENERAL INFORMATION ABOUT THE ACTUATOR The actuator of the INKA 356 series moves the window by means of a chain that runs inside the device. The chain is moved by a gearmotor driven by an electric motor, which in turn is powered and controlled by an electronic card. -
Page 8: Construction And Regulatory References
LOCK electro-lock, a new RESET procedure must be performed. 7. ID PLATE AND MARKING DATA The INKA 356 series actuators have CE marking and comply with the Standards listed in the Declaration of Conformity. They also come with a Declaration of Incorporation, due to their classification by the Machinery Directive as “partly completed machines”. -
Page 9: Electrical Power Supply
IGHT LACK ROWN The additional wiring (R and W ) is for electronic synchronisation (Nekos HITE patent). INKA356 24V, for smoke and heat extraction: runs on 24V , with three wire cable, “1”, connected to the + (positive) closes; B “2”, connected to the +... -
Page 10: Selection Of Power Cable Section
+ (positive) closes; B “2”, connected to the + (positive) opens. LACK A third wire G “3”, is both used or electronic synchronisation (Nekos patent) REEN and for the possible connection to K-LOCK electromechanical lock. Low tension actuators 24V... -
Page 11: Preparation Of Actuator For Assembly
Check that once the actuator has been installed the distance between the fixed part of the window frame (where the actuator is to be assembled) and the mobile part of the window frame (where the bracket is to be fixed) is greater than or equal to 0 mm (Fig. -
Page 12: Assembly With Opening Outwards - Top Hung, Lower Part Opening Towards The Exterior
Screw holes for low-voltage actuators (24V ) on awning windows (hinges at the top, opening outwards from the bottom). Screw holes for 110-230V~ actuators on bottom-hung windows (hinges at the bottom, opening inwards from the top). Screw holes for 110-230V~ actuators on awning windows (hinges at the top, opening outwards from the bottom). -
Page 13: Assembly With Opening Inwards - Bottom Hung, Higher Part Opening Towards The Interior
Figure 2 Figure 3 Figure 4 Figure 5 Mark the centre line "X" of the frame with a pencil (Fig. 2) or divide it equally if fitting several Syncro Use brackets "A" art. 4010118 and hinge "C" art. 4010116 (both sold separately. Fig. 3). Mark the position of the holes to be drilled on the frame as shown in the drawing in #10.4 above. -
Page 14: Electrical Connections
Figure 7 Figure 8 Figure 9 A. Before starting works, at least two flexible mechanical link arms or other form of safety stops MUST be installed to guarantee hold and prevent accidental falling of the window in order to provide safe working conditions. B. -
Page 15: Connections Of Inka356
Before performing the electrical connection consult the table below and check correspondence between the feeder cable and the tension data on the actuator label. Colour of wires Cable Number Tension Wire colours used for length of wires notification IGHT 110-230V~ 50/60Hz LACK ROWN “1”... -
Page 16: Programming The Actuator
For cabling, follow the diagrams below. 110/230V ~ SYNCRO SYNCRO 12. PROGRAMMING THE ACTUATOR 12.1. INKA 356 Programming Closing stroke-end The closing stroke-end is automatic and non-settable. The position at which the actuator stops is determined by the power absorbed by the actuator when the window reaches complete closure and the seals are completely compressed, i.e., the actuator stops when the power absorbed exceeds a preset threshold. -
Page 17: Reset Procedure - Valid For The Single-Actuator Configuration, Syncro³ Configuration Or Configurations With The K-Lock Electro-Lock
When using the INKA 356 Syncro³ model, the RESET procedure and acquisition of the overlap must be performed during installation (see paragraphs 12.2 and 12.3) before the desired opening stroke-end can be selected. We recommend checking the electrical wiring before starting the RESET procedure. If the settings are lost, a new RESET procedure must be performed followed by acquisition of the overlap (see paragraphs 12.2 and 12.3). -
Page 18: Overlap Acquisition
Supply power to the actuators (either by opening or closing). The initializing phase will then start. The actuator will start at once (or after about 8 seconds if there is an electro-lock) and perform a full closing manoeuvre (chain completely retracted) and then an opening manoeuvre of about 5 cm. -
Page 19: Led Light Signals
12.4. LED Light signals If there are any problems during installation or operation of the machines, consult the possible causes listed below: WITH RED LED Number of Type of Error Possible Solution Flashes Check that there are no obstacles Current error: preventing the actuator from completing The actuator has detected an its stroke. -
Page 20: Checking For Correct Assembly
In the event that the window frame should require manual opening due to power failure or problem with the mechanism or for normal maintenance or external cleaning of the window frame, the NEKOS patent allows rapid unhooking of the chain. To perform this operation, proceed as follows: 1. -
Page 21: Environmental Protection
3. Manually open the window frame. – the window could fall as the sash is no longer held in TTENTION DANGER position by the chain. 4. After maintenance and/or cleaning repeat points 1 and 2 in reverse order. 15. ENVIRONMENTAL PROTECTION All materials used in the manufacture of this appliance are recyclable. -
Page 22: Shev Certificate
17. SHEV CERTIFICATE... -
Page 23: Declaration Of Incorporation (For A Partly Completed Machine) And Ec Declaration Of Conformity
Questa dichiarazione è fatta dal costruttore / This is declared by the manufacturer : NEKOS S.r.l. - Via Capitoni 7/5 - 36064 Colceresa – VI - Italy Rappresentato da / Represented by : Giuliano Galliazzo – A.D. / CEO... - Page 24 NEKOS S.r.l. - Via Capitoni, 7/5 36064 Colceresa - VI – ITALY +39 0424 411011 – +39 0424 411013 www.nekos.it info@nekos.it...
