ROCK
INSTRUCTION MANUAL -
TRANSLATION OF ORIGINAL INSTRUCTIONS
LINEAR ROD ACTUATOR
EN
Force 500 N – Strokes 100, 200 and 300 mm
Electrical supply:
█ 110-230V~ 50/60Hz, █ 24V
NEKOS
S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa (VI) – ITALY
+39 0424 411011 – +39 0424 411013 - www.nekos.it - info@nekos.it
4420134 - Rev. 3 of June 2022
Advertisement
Table of Contents
Related Manuals for nekos ROCK
Summary of Contents for nekos ROCK
- Page 1 Force 500 N – Strokes 100, 200 and 300 mm Electrical supply: █ 110-230V~ 50/60Hz, █ 24V NEKOS S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa (VI) – ITALY +39 0424 411011 – +39 0424 411013 - www.nekos.it - info@nekos.it 4420134 - Rev. 3 of June 2022...
-
Page 2: Table Of Contents
Nekos products have been manufactured in accordance with safety standards and conforms to the stipulations of current standards in force. When correctly assembled, installed and used according to the present instructions, they will not generate any danger for persons, animals or items. -
Page 3: General Information
GENERAL INFORMATION Before starting or using the actuator, read and understand all the parts of this instruction manual. This manual is an integral part of the actuator and must be kept for future reference. This documentation is intended for specialised companies and end users. All installation, maintenance and repair work should be carried out by suitably trained technical personnel. -
Page 4: Installer Instructions
IMPROPER INSTALLATION CAN SERIOUSLY ENDANGER SAFETY. The Nekos electrical actuators comply with the Machinery Directive (2006/42/EC), Standard IEC 60335-2-103 (Particular requirements for drives for gates, doors and windows) and other directives and regulations indicated in the attached Declarations of Incorporation and Conformity (at the end of the manual). -
Page 5: Field Of Application
FIELD OF APPLICATION The ROCK actuator is intended for use in the ventilation and air conditioning of rooms through windows, sunscreen blades, louvre windows or jalousies. The movement is obtained with 110/230V~ or low-voltage (24V SELV) electrical energy that powers a gear motor controlled by a functional electronic device. -
Page 6: Technical Operating Information
TECHNICAL OPERATING INFORMATION ROCK is fitted with control electronics. It is equipped with a stiff rod that moves the levers of sunscreen blades or pushes the sash of a window or domed rooflight. The stroke of the rod can be programmed along its entire stroke length by means of a magnetic switch (magnet-holder screw) (see section 12 - Programming the actuator). -
Page 7: Technical Data
LOSE LACK REEN communication signal. ROCK actuator in the 24V version can also be powered by a control unit with emergency batteries or a safety power supply of at least Class II, with an output voltage of 24V (min. 20,4V , max. -
Page 8: Choice Of Power Cable Diameter
8.1. Choice of power cable diameter The voltage drop caused by the flow of current in conductors is a critical aspect for the safety and proper functioning of the device. It is therefore important to correctly calculate the diameter of the conductors in relation to the length of the cables. The following table shows the cable lengths for a gearmotor connected to a rated load. -
Page 9: Preparing To Mount The Actuator
The motor capacity must be sufficient for the required usage movements, without encountering obstacles of any kind; the limits indicated in the product technical data table (art. 7) may not be exceeded; otherwise eliminate any difficulties. Check that the electrical supply used corresponds to that specified on the AUTION “technical data”... -
Page 10: Electrical Connection
d) Install the blade control lever attachment accessory and the actuator mounting bracket on the actuator with the M6 bolts supplied. The accessory for sunscreen blades is not supplied and must be requested LEASE NOTE separately, unless the user has accessories of their own available. e) Place the actuator support bracket on the window frame, mark the drill points, drill with a bit of sufficient size and fit the bracket. -
Page 11: Machine Electrical Connections
Green wire "3" is not used, it must be insulated. 11.2. Connection with a K-LOCK electromechanical lock Wiring diagram 24V K-LOCK ROCK (24V - 24V SYNCRO 12. PROGRAMMING THE ACTUATOR Before performing the stroke end-position setting procedure, make sure that the electrical power supplied to the actuator matches that indicated on the technical data label on the machine, ... - Page 12 Supply power to move in either the opening or closing direction. With Syncro³ actuators, the rods move independently from each other. : if a K-LOCK is present (24V ROCK), you must wait around 4 seconds AUTION for it to switch to the O position;...
-
Page 13: Correct Installation Check
CAUTION. In the event that, for whatever reason, the gearmotor has not closed the door/sash correctly, stopping before completing its stroke, the setting procedure or a reset operation must be repeated. In the case of window sash automation, check, with the sash closed, that the gasket is properly compressed, otherwise there is no certainty that the window is fully closed and the lock properly engaged. -
Page 14: Environmental Protection
CAUTION To prevent damage to persons and property, observe the following: Before performing cleaning and maintenance operations, disconnect the actuator from the power outlet, without pulling on the power cord, to quickly disconnect the appliance. Disconnect the power supply to all terminals; remove the fuses if necessary. 15. -
Page 15: Declaration Of Incorporation (For A Partly Completed Machine) And Ec
Questa dichiarazione è fatta dal costruttore / This is declared by the manufacturer: NEKOS SRL - Via Capitoni 7/5 - 36064 Colceresa (Vicenza) - Italy Rappresentato da / Represented by : Giuliano Galliazzo – A.D. / CEO Firma / Valid signature... - Page 16 NEKOS S.r.l. - Via Capitoni, 7/5 36064 Colceresa (VI) – ITALY +39 0424 411011 – +39 0424 411013 www.nekos.it info@nekos.it...
