BATTERY ICONS AND STATUS DESCRIPTIONS
Battery is almost fully charged.
Battery is more than 50% charged.
Rechargeable battery is fully charged. Pump is running on external AC power.
Rechargeable battery is less than 40% charged. External AC
power is connected and is charging the battery.
Rechargeable battery is low. External AC power is connected and is charging the battery.
Rechargeable or disposable batteries are low and have less than 20% life remaining.
AC power is not connected. Replace the batteries or connect pump to AC power
very soon. Icon blinks when the battery life is less than 30 minutes.
Disposable batteries are low and have less than 20% power remaining.
AC power is connected. Replace the batteries soon.
Battery is empty. Infusion has stopped. You should connect
to external AC power or replace the batteries.
Disposable C-Cell batteries have approximately 60% power
remaining. Pump is running on external AC power.
Pump is connected to external AC power and no battery is installed. You should install batteries.
REPLACING BATTERIES OR RECHARGEABLE BATTERY PACK
The CURLIN 8000 pump is powered by either two disposable C-Cell
alkaline batteries or the CURLIN 8000 rechargeable battery pack.
If using C-Cell batteries, Moog recommends using Duracell® Procell® batteries.
1 2
1. If the pump is 2. Slide the lock on
running, stop the the battery door from
pump by pressing left to right. Then,
the PAUSE button
use your thumbs to
and then press grip and slide the
and hold the ON/
door downward,
OFF button to turn
and remove.
off the pump.
Note: If connected to external AC power, you can change the batteries without powering the pump off.
3 4
3. Remove the 4. Insert new C-Cell
batteries. batteries or the
rechargeable battery
pack as shown in
the diagram.
5
5. Replace the battery
door by sliding it
on from the bottom
towards the top of
the pump. Then, slide
the lock to the left
to secure the door.
