Fig. I 产品标签 / Production label
29.
23.
42.
21.
15.
45.
46. 47.
48.
49.
1.
3.
29.
23.
4.
5.
55.
7.
14.
15.
61.
VF9460B (07/2020)
装配手册 / Assembly manual
39.
1.
4.
5.
55.
44.
43.
60.
14.
61.
34.
50.
51.
56.
57.
52.
53.
58.
59.
30.
31.
32.
20.
21.
8..
41.
9.
10.
60.
26.
2.
40.
41.
35.
54.
30.
31.
13.
11.
27.
28.
39.
29.
4.
5.
10.
45.
23.
9.
2.
41.
15.
14.
61.
60.
38.
37.
22.
32.
1.
55.
33.
34.
35
36.
3
Advertisement
Related Manuals for Vostermans Ventilation Multifan Basket Fan 50
Summary of Contents for Vostermans Ventilation Multifan Basket Fan 50
- Page 1 Fig. I 产品标签 / Production label 46. 47. VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 2 Fig. II 工具 / Tools Fig. III 零件 / Parts 50 cm, 63 cm, 71 cm 92 cm 1X MOTOR 1X ROVB092BF05ZW 1X ROVB092BF04ZW VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 3 2X YOKEVD1539 1X IMPELLER 1X WKG170ZW 1X ZBM12RVS 4X BZKM8X12RVSKL 1X SRM12X24RVS 4X SRM8X16RVS 1X SP6X6X40 2X POSITIESTRIP01 4X BVKM6X16RVS 4X ZBRM6RVS VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 4 Fig. IV 装配 / Assembly 92 cm 13. (2x) 14. (4x) P. (2x) 6. (2x) 10. (4x) 9. (4x) 22 Nm VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 5 50 cm, 63 cm, 71 cm, 92 cm 2. (1x) A. (1x) VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 6 Fig. V 安装支架 / Mounting yoke 10A. 8,5 Nm ≤400 rpm 13A. VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 7 FIG. VI 悬挂 / Suspension 外流塞子 Condense plug ≥ 2,7 m. VF9460B (07/2020) 装配手册 / Assembly manual...
- Page 8 FIG. VII 接线图 / Connection diagram 原理图 II/schema II 原理图 I / schema I 黄色/绿色 ; Yellow/green (6)热保护: TP 棕色 ; Brown 一相: 250V 2,5A cosφ =1 蓝色 ; Blue 三相: 250V 10A cosφ =1 白色 ; White 黑色 ; Black (6)TP: Thermal Protection: 灰色 ; Grey - At 1 phase: 250V 2,5A cosφ =1 红色 ; Red - At 3 phase: 250V 10A cosφ =1 电缆 ; Cable Vostermans Ventilation B.V. Vostermans Ventilation Inc. Vostermans Ventilation B.V. develops, manufactures and P.O. Box 3025 2439 S.Main St. – USA distributes the full line of:...
- Page 9 FANS Basket Fan 50, 63, 71 and 92 User Manual Specialist in Air VF9460B...
-
Page 10: Table Of Contents
Table of contents 01. Introduction 02. Scope of delivery 03. General instructions 04. Technical specifications 05. Explanation production label 06. Assembly / Mounting / Installation 07. Storage / Transport 08. Start-up 09. Putting out of service 10. Disposal / Recycling 11. Maintenance and maintenance diagram 12. Malfunctions / Repair 13. Complaints / questions Read this manual completely and carefully before using the fan. The original manual is written in Dutch. All other languages are translations of the original manual. -
Page 11: General Instructions
General instructions • Read this manual completely and carefully before using the fan • This manual is an integral part of the product. File this manual therefore accurately for future references • Use this fan only in the scopes mentioned on the production label • The Basket Fan has been developed for indoor use. For outdoor use, contact your supplier Technical specifications • Check the production label for technical specifications • Check voltage and frequency before use • Sound pressure (measured towards the human ear in dB(A)) according to the ‘free field method’ at a distance of 7 meters • Technical specifications regarding performances are guaranteed until 1000 meters above sea level Explanation production label Article number VV 22. Bar code 43. Part number customer Serial number 23. Winding diagram 44. Weight (kg) Wiring diagram 24. Weather proof 45. -
Page 12: Assembly / Mounting / Installation
Assembly / Mounting / Installation • Mounting, electric connection and start-up may be executed by qualified personnel only. • It is the installer’s responsibility that the installation and safety instructions are in accordance with current standards and regulations • Every fan has to be grounded according to the current standard • Do not use the fan as part of a construction • In case the moving part of the fan (the impeller) is below 2.7 m (measured from the floor to the lowest point of the fan), a protective wire guard (according to EN-ISO 13857) is mandatory. • Remove the red condense plug, mounted at the lowest point of the motor. Keep the condense plug in a safe place, for it is necessary to use it during cleaning and maintenance work. • Keep the water outlets open at all times. • Using the optional suspension set is recommended. • Always attach the cover on the hub. This avoids humidity penetrating the bearings, causing a serious reduction of the life span. • Assemble the fan according to the instruction, see FIG IV in the assembly manual. CAUTION: In case of speed regulation, the fan may vibrate when incorrectly mounted/installed. Check this before completing the installation. -
Page 13: Start-Up
Start-up Before connecting the fan to mains power supply be sure that the specifications on the production label match the local voltage and frequency. Make sure that the controller is suitable for the fan and that the fan is suitable for the controller. CAUTION: If the fan is provided with a cable and the type label states AAxx, wiring diagram I of FIG VII applies. CAUTION: If the fan is provided with a cable and the type label states ABxx or ACxx, wiring diagram II of FIG VII applies. -
Page 14: Maintenance And Maintenance Diagram
Maintenance and maintenance diagram CAUTION: Never carry out mainenance work on a working/rotating fan! Always disconnect from mains power supply before maintenance work. During all maintenance of the fan: • the mains voltage has to be switched off. • the power circuit has to be disconnected an secured against reconnection. • all rotating parts have to be brought to a complete standstill • all safety and work regulations have to comply with EN 50110-1. • all work has to be carried out by qualified personnel (according to EN 50110-1). Servicing: •... -
Page 15: Malfunctions / Repair
Malfunctions / Repair Caution: In case the fan does not rotate, this may be caused by the thermal protection. The fan turns on again automatically. Contact your installer in case of malfunction. To be checked by the installer: Is there a problem with the mains power supply? Is the fuse blown? Is the wiring loose? Have the bearings seized? Is the impeller blocked? - Page 16 Notes: Vostermans Ventilation B.V. Vostermans Ventilation Inc. Vostermans Ventilation B.V. develops, manufactures and P.O. Box 3025 2439 S.Main St. – USA distributes the full line of: NL-5902 RA Venlo – Holland Bloomington, IL 61704 Tel. +31 (0)77 389 32 32 Tel. +1 309 827 - 9798 Fax +31 (0)77 382 08 93 Fax +1 309 829 - 1993 ventilation@vostermans.com ventilation@vostermansusa.com www.vostermans.com www.vostermansusa.com Vostermans Ventilation S.A.R.L. Vostermans Ventilation Sdn. Bhd. B.P. 1801 330, Lot 2593, Jln Seruling 59, Kws3, 27018 Evreux Cedex Tmn Klang Jaya, 41200, Klang, France Selangor D.E., Malaysia Tel. +33 (0)2 32 38 11 00 Tel. +60 (0)33324 3638 (HL) Fax +33 (0)2 32 33 37 12 Fax +60 (0)33324 1239 ventilation@vostermansfrance.com ventilation@vostermansasia.com www.vostermans.com www.vostermans.com All rights reserved. Vostermans Companies is not responsible for inaccurate or incomplete data.
