Vostermans Ventilation Multifan V-FloFan T4D40A Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FANS
V-FloFan
Assembly manual
Specialist in Air
VF9400G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multifan V-FloFan T4D40A and is the answer not in the manual?

Questions and answers

Related Manuals for Vostermans Ventilation Multifan V-FloFan T4D40A

Summary of Contents for Vostermans Ventilation Multifan V-FloFan T4D40A

  • Page 1 FANS V-FloFan Assembly manual Specialist in Air VF9400G...
  • Page 2 Table of Contents Contents Table of Contents Fig. I Production label Fig. II Tools Fig. III Parts Fig. IV Mounting Fig. V Dimensions FIG. VI Suspension FIG. VII Connection diagram Options Suspension bracket User Manual VF9400G (05/2016) Assembly manual...

  • Page 3: Fig. I Production Label

    3900 m³/h Art: FM0114M1G0007 0.00 in.wg: 2750 CFM 123456789012 0.20 in.wg: 2300 CFM Vostermans Ventilation B.V. The Netherlands Vostermans Ventilation B.V. P.O. Box 3025 5902 RA Venlo The Netherlands ST043022 RP1310X30 H1500 Vostermans Ventilation B.V. A/FLA min⁻¹ P₀:kW / Hp Cos Phi C µF/V...

  • Page 4: Fig. Ii Tools

    Fig. II Tools 10 (2x) / 13 (2x) Fig. III Parts 1x V-Flofan VF9400G (05/2016) Assembly manual...

  • Page 5: Fig. Iv Mounting

    Fig. IV Mounting MOUNTING INSTRUCTIONS Pos. Dimensions Legend Climate Screens ± 18m min 2,0m Pillar min 0,5m No obstacles within a 2m wide range of the fan min 0m for optimal results the maximum recommended installation height is 5m Never use horizontal fans at the same time with the V-Flofan Keep all windows and doors closed Screw on bolts and nuts Unscrew bolts...

  • Page 6: Fig. V Dimensions

    Disassemble motor cover Connect cable gland and cable and replace motor cover Guide the cable upwards via frame of the greenhouse. Use the optional suspension brace. Fig. V Dimensions Ø mm VF9400G (05/2016) Assembly manual...

  • Page 7: Fig. Vi Suspension

    FIG. VI Suspension Use the optional adjustable suspension brace. Fig. 2 Never use a rope, chain or strip. Fig. 1 • Use only profiles for the suspension of the fan as shown below. The profile must have a resistance to bending in all directions. Dimensions are dependent on the cross-sectional profile length of the profile to be used.
  • Page 8 Fig. 3: ≥30 mm ≥15 mm Minimum dimensions, maximum length 2m. . Fig. 4: ≥30 mm Example: Fig. 3 • In case the moving part of the fan (the impeller) is below 2.7 m (measured from the floor to the lowest point of the fan), a protective wire guard (according to EN-ISO 13857) is mandatory.

  • Page 9: Fig. Vii Connection Diagram

    FIG. VII Connection diagram TP: Thermal Protection: - At 1 phase: 250V 2,5A cosφ =1 - At 3 phase: 250V 10A cosφ =1 VF9400G (05/2016) Assembly manual...
  • Page 10 Vostermans Ventilation B.V. Vostermans Ventilation Inc. Vostermans Ventilation B.V. develops, manufactures and P.O. Box 3025 2439 S.Main St. – USA distributes the full line of: NL-5902 RA Venlo – Holland Bloomington, IL 61704 Tel. +31 (0)77 389 32 32 Tel. +1 309 827 - 9798...
  • Page 11 FANS V-FloFan Options Specialist in Air VF9400G...

  • Page 12: Options

    Suspension bracket Tools 13 (2x) Parts STTB0001 8x M8 2x BEVESBEUG04 4x M8x80 8x M8 2x BEVESBEUG05 / 2x BEVESBEUG06 VF9400G (05/2016) Options...
  • Page 13 Mounting 6. (2x) BEVESBEUG05 / BEVESBEUG06 3. (4x) 5. (4x) 1. (2x) 3. (4x) 5. (4x) 4. (4x) Check the connection of the bolts every 6 months. VF9400G (05/2016) Options...

  • Page 14: User Manual

    FANS V-FloFan User Manual Specialist in Air VF9400G...

  • Page 15: Table Of Contents

    Table of contents Introduction Scope of delivery General instructions Technical specifications Explanation production label Assembly / Mounting / Installation Storage / Transport Start-up Putting out of service Disposal / Recycling Declaration of Conformity Maintenance and maintenance diagram Malfunctions / Repair Complaints / questions VF9400G (05/2016) Translation of the original manual...

  • Page 16: Introduction

    Introduction Read this manual completely and carefully before using the fan. The original manual is written in Dutch. All other languages are translations of the original manual. This fan is made for moving or recirculating air or air mixtures. Using this fan in explosive environments for moving or circulating gas, substances, sprays, fumes or a mixture thereof is not permitted.

  • Page 17: Explanation Production Label

    at 0 Pa Item number Controllability* dB (A) 230V 50Hz 1330 RPM T4E40A4M81160 5250 230/400V 50Hz 1330 RPM T4D40A5M81160 1,1 / 0,7 5250 240V 60Hz 1575 RPM T4E40K6M81160 5400 240/420V 60Hz 1575 RPM T4D40K8M81160 1,0 / 0,6 5400 120V 60Hz 1575 RPM T4E40K7M81160 5400...

  • Page 18: Assembly / Mounting / Installation

    Assembly / Mounting / Installation • Mounting, electric connection and start-up may be executed by qualified personnel only (according to EN 50110-1 and IEC 60364). • It is the installer’s responsibility that the installation and safety instructions are in accordance with current standards and regulations (according to EN-ISO 13857 and EN ISO 12100-1).

  • Page 19: Storage / Transport

    Storage / Transport • Transport and store the fan only in its original packaging. • Storage temperature: –40˚C to + 60˚C. • Avoid impacts and unnecessary loads to packaging and/or fan. • In case the packaging is damaged check for damages on the fan. Start-up Before connecting the fan to mains power supply be sure that the specifications on the production label match the local voltage and frequency.

  • Page 20: Declaration Of Conformity

    Declaration of Conformity EC Declaration of Conformity (according to Annex II.1.A. of Directive 2006/42/EC Machinery) Manufacturer: Vostermans Ventilation B.V. Parlevinkerweg 54 5928 NV Venlo, The Netherlands Documentation Manager: R. van As Manager R&D This declaration of conformity is issued under the sole responsibility of the manufacturer.

  • Page 21: Maintenance And Maintenance Diagram

    Maintenance and maintenance diagram CAUTION: Never carry out maintenance work on a working/rotating fan! Always disconnect from mains power supply before maintenance work. During all maintenance of the fan: • The mains voltage has to be switched off. • The power circuit has to be disconnected an secured against reconnection. •...

  • Page 22: Malfunctions / Repair

    Malfunctions / Repair Caution: In case the fan does not rotate, this may be caused by the thermal protection. The fan turns on again automatically. Contact your installer in case of malfunction. To be checked by the installer: Is there a problem with the mains power supply? Is the fuse blown? Is the wiring loose? Have the bearings seized?
  • Page 23 Vostermans Ventilation B.V. Vostermans Ventilation Inc. Vostermans Ventilation B.V. develops, manufactures and P.O. Box 3025 2439 S.Main St. – USA distributes the full line of: NL-5902 RA Venlo – Holland Bloomington, IL 61704 Tel. +31 (0)77 389 32 32 Tel. +1 309 827 - 9798...
