Summary of Contents for Cal Spas Patio Plus

Page 1 ® Patio & Patio Plus Made in USA “From the Finest Components Around the World”™ Cal Spas Home Resorts ™ Owner’s Manual...
Page 2 Copyright 2025 Lloyd’s Material Supply Company, Inc. All rights reserved. Duplication without written consent is strictly prohibited. Lloyd’s Material Supply Company, Inc. Cal Spas®,Adjustable Therapy System™, ATS™, Cal Premium™, Cal Select™, Cal Customer Service Department Stone™, XL™ Heater, and Ultimate Fitness Spa Series™, are registered trade- 1462 East Ninth Street marks.
Page 3 Copyright 2023 Lloyd’s Copyright Lloyd’s Material Supply Inc. Lloyd’s Copyright Lloyd’s Material Supply Inc. All rights reserved. Duplication without consent is strictly prohibited. LTR2023.1000, REV. F-3 6/15/2023...
Page 4 Table of Contents Important Safety Instructions ..........Invert Display (Flip Display) ..........Preparing for Your Spa Setting Filter Cycles ............... Planning the Best Location ............Spa Operations Clearance for Service Access ........... LED Lighting & Diverter Knobs ......... Preparing a Good Foundation ..........Air Venturis &...
Page 5 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When using and installing this spa, basic safety precautions should always be followed, including. Danger: RISK OF SEVERE INJURY OR DROWNING! • NO DIVING, diving may result in injury or death. •...
Page 6 Warning: REDUCE RISK OF HEAT RELATED INJURY OR DEATH • Prolonged exposure to hot air or water can induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level between 3°F (2°C) to 6°F (4°C) above the normal body temperature of 98.6°F (37°C).
Page 7 Preparing for Your Spa Preparing for Your Spa Pre-Delivery Checklist � Pre-Delivery Checklist Most cities and counties require permits for Most cities and countries require permits for exterior Before Delivery □ construction and electrical circuits. In addition, some exterior construction and electrical circuits. Plan your delivery route □...
Page 8 Clearance for Service Access Clearance for Service Access While you are planning where to locate your spa, you need to determine how much access you will need for service. All spa models require a minimum of three feet (one meter), of access to all sides of the spa for potential service.
Page 9 Opening the Front Panel For Electrical Access Cal Spas are designed with innovative snap in panels and corners. In order to access the control box for electrical hook up, plumbing, or pumps inside of your spa, you will need to remove the corner panels and the front panel.
Page 10 Step 3 Once both corners are removed, place one hand under the front panel and one hand on either corner. Once prepared, pull both the center and your cho- sen corner at the same time to release the panel. Caution: Brace for the weight of the panel once it is removed.
Page 11 Step 6 Once the panel is aligned, apply medium pressure to the bottom center of the panel to secure it into place. Similarly apply pressure to the top center of the panel as well. You may also use the bottom of your fist to tap the panel back into place.
Page 12 This Page is Intentionally Blank...
Page 13 Removing Shipping Materials Your Cal Spa is wrapped with a white shrink wrap designed to protect the acrylic shell from scratches and damage. Thoroughly inspect the plastic wrapping for any tears and or damage that may have occurred during shipping. It is expected to see some scuffs or small tears at the base and corners of the spa, as the spa is pushed and shifted around in transport.
Page 14 240 Volt Electrical Installation 240 Volt Electrical Installation GFCI Wiring Requirements GFCI Wiring Requirements a Model Control System GFCI Breaker Wires required Wiring Diagram 519L / PZ-535L / BP-501G1 110 Volts / 15 Amps Cord with 15 Amp GFCI See page 9 for reference See page 11 for 636L provided...
Page 15 GFCI Wiring Diagram (Balboa) GFCI Breaker Box GFCI (Bottom View) Front ViewofGFCI � � � � ...J � � � � � � System Box House Breaker Box (HOT) GROUND TERMINAL BLOCK (ATTACHED TO OUTSIDE OF SYSTEM BOX) � GREEN (GROUND) �...
Page 16 If the GFCI trips while the spa is in use, press the RESET button. If the GFCI does not reset, unplug the spa and call your local Cal Spas dealer for service. DO NOT USE THE SPA! Test the GFCI breaker prior to first use and periodically when the spa is powered. To test the GFCI breaker.
Page 17 Filling and Powering Up your Portable Spa Filling and Powering Up your Portable Spa Step 1. Inspect the Spa Equipment. Inspect all plumbing connections in the equipment area of your spa. • Make sure unions connected to the equipment pack are tight (do not over-tighten) •...
Page 18 Step 3. Fill the Spa Place the water hose inside the filter canister. Fill your spa with regular tap water about six inches from the top. If the water level is too low or too high, your spa will not operate correctly. NOTE: Never fill with soft water.
Page 19 Note: Cal Spas are designed to retain heat, if it is desired to lower the water temperature the spa does not contain a cooling feature. To lower internal temperature of the spa, lower the set temperature on the con- trol panel and open the tub during the evening or night to help release the heat captured within.
Page 20 Priming the Pump Priming the Pump New owners often have difficulty the first time they start their spa and the pumps fail to prime. This can be frustrating but these instructions should help you resolve any issues with air pockets inside of the primary pump or other priming issues.
Page 21 Navigation / TP-500 Navigation / TP-500 Navigating the entire menu structure is done with 2 or 3 buttons on the control panel. Navigating the entire menu structure is done with 2 or 3 buttons on the control panel. Some panels have separate WARM (Up) and COOL Some panels have separate WARM (Up) and COOL (Down) buttons, while others have a single (Down) buttons, while others have a single...
Page 31 This Page is Intentionally Blank...
Page 39 -- -- -- -- --...
Page 41 The TP 700 Control System The TP 700 Control System The TP 700 control panel offered only on spas operating two or more pumps. Continue to the following pages to learn how to navigate, operate, and program your spas operation. Both control panels use the same software and use the same operation procedures. Two Pump Controller Three Pump Controller...
Page 45 Main Screen CHANGE THE SET TEMPERATURE Follow these steps to change the Set Temperature: 1 - Start at the Main screen (A). Press the SELECT navigation button to view the temperature menu (E). 2 - Press the RIGHT and/or LEFT navigation buttons to change the Set Temperature.
Page 46 HEAT SETTINGS HEAT MODES Follow these steps to view the current Heat Mode and/or change the Heat Mode: 1 - Navigate to Heat (A).* 2 - Press the SELECT navigation button to view the Heat screen (B). The current Heat Mode will appear here (C).
Page 47 RESTRICT OPERATIONS The control can be restricted to prevent unwanted use or temperature adjustments. Locking the Panel (D) prevents the controller from being used, but all automatic functions are still active. Locking the Settings (C) allows Jets and other features to be used, but the Set Temperature and other programmed settings cannot be adjusted.
Page 48 SET TIME-OF-DAY Be sure to set the Time-of-Day Setting the Time-of-Day can be important for determining water filtration times and other background features. Follow these steps to set the time-of-day: 1 - Navigate to Time (A).* 2 - Press the SELECT navigation button, and the Time screen will appear (B).
Page 49 Range: About 20 feet Range limit: Limited to the range HOW TO CONNECT TO IT: Install the app on your phone or device -- see the following section “Installing the app”. Range: About 50 feet Range limit: Limited to the range of your home router’s signal HOW TO CONNECT TO IT: 1.
Page 50 (clockwise) Waterfall (option) Waterfall (option) Some Cal Spas are equipped with a wa- terfall feature, with LED lights inside the housing. The flow of the waterfall water can be adjusted in most spa models by turning the primary water diverter inside of your spa.
Page 51 Cool Off Seat Cool Off Seat The cool off seat,is designed in some Cal Spa models. The seat is designed to help cool down spa users that are using their spa in higher therapeutic water tem- peratures. This helps in avoiding the negative effects of hyperthermia (Overheating of the body).
Page 52 Water Clarity Water Clarity This section is intended for new spa owners who are not familiar with adjusting spa water chem- istry. Everyone’s knowledge with maintaining water quality is different, but there are some general concepts you need to know. Water maintenance is not difficult, however it is something that requires regular attention.
Page 53 Water Quality Terms and Definitions Water Quality Terms and Definitions...
Page 54 Water Testing Methods Water Testing Methods There are two testing methods to choose from: The reagent test kit is a method which provides a high level of accuracy but is more expensive and Test strips are a convenient testing method more difficult to use if not experienced with this commonly used by spa owners.
Page 55 Balancing Water Chemistry Levels Balancing Water Chemistry Levels Maintaining spa water chemistry can be tricky, especially since there are many methods of keeping your water clear and clean. Note: We do not recommend a specific brand of chemicals. See a spa dealer for guidance and recommendations on spa chemicals and supplied needed, as water chemistry varies from region to region.
Page 56 Before you fill your spa, you need to decide which chemical sanitizer you wish to use. Consult your Cal Spas dealer for the right decision with regards to your lifestyle and spa usage. We recommend granulated chlorine or bromine as your sanitizer. Both work well when maintained regularly.
Page 57 Starting & Maintaining Sanitizer Levels After you choose a sanitizer, you will need to establish a baseline and maintain it regularly. Sanitizing your spa with chlorine or bromine is very similar. Each sanitizer has its advantages and disad- vantages. Sanitizer helps neutralize bacteria that can cause illness and other organic matter. Bromine: Creates less odor and skin irritation than chlorine, bromine is less likely to do so.
Page 58 Shocking the Water In addition to using a chemical sanitizer, you will periodically need to shock the water. Shocking the water helps remove burned-out chemicals, bacteria, and other organic material from your spa’s water and im- proves your sanitizer’s effectiveness. Do not use chlorinating shock, which can damage the spas jets and pump seals.
Page 59 General Water Care Schedule General Water Care Schedule Each time you refill the spa Each time you refill the spa Generic Names for Chemicals Generic Names for Chemicals...
Page 60 Common Water Chemistry Questions Common Water Chemistry Questions Question : Why is the use of a floater not recommended to sanitize my spa water? Answer: We do not recommend the use of a floater for three reasons: • The floater is unable to control the rate at which the sanitizer is dissolved into the water. When a floater is placed into a spa the sanitizer levels inside the spa can be extremely high.
Page 61 Question : When I open my spa, I smell chlorine. How to I get rid of the smell? Answer: There are two types of chlorine in your spa. the first is “Free Chlorine” which is chlorine molecules that are available to sanitize your spa. This free chlorine does not have an odor.
Page 62 (go to the next higher filtration number) then if water quality is still not adequate, consult the advice of your Cal Spas dealer for additional chemical or system recommendations. Be sure to give them your bather load information.
Page 63 Chemical Abuse Chemical Abuse Chemical abuse is defined as negligent/careless use of both recommended spa chemicals, and use of prohibited chemicals. The spa shell is designed to last for many years, but when the shell is exposed to excessive chemicals, or improper chemical application; this can cause reactions on the shell that can cause pitting, cracks, bubbling, and other blemishes on the shell.
Page 64 Cleaning and Maintenance Cleaning and Maintenance **Note: Images are for illustration purposes only, color and styles are subject to change Removing and Re-seating Pillows You can remove the pillows for clean- ing and maintenance quickly and easily. This method works for all pillow types.
Page 65 Draining Your Portable Spa Draining Your Portable Spa Your spa should be drained every four to six months for cleaning and maintenance and refilled with fresh tap water. Before you begin turn the power off to the spa at the breaker and remove your filters. Step 1.
Page 66 Winterizing (Cold Climate Draining) Winterizing (Cold Climate Draining) Depending on your region in your country, the temperature could drop below 32F(0°C). If you are one of those regions, we recommend that you always have your spa full of water and running at normal spa tem- peratures between 80°F - 100°F (26.7°C - 37.8°C).
Page 67 Spa Cover and Locking System Installation Spa Cover and Locking System Installation The spa cover can be considered one of the most important parts of your spa. The spa cover helps retain the heat inside of your spa in all different types of weather. The cover works as a lid on a thermos, when the spa is not in use the cover helps lower the amount of time the spas heater has to run for.
Page 68 Use a screwdriver to finish screwing in the three screws, repeat this process for the remaining Step 4 3 corners. Keep the cover fastened down at all times when not in use, locking hardware may be locked Step 5 with a key (provided in the packaging of the spa cover) The provided key will allow you to Step 6 lock down your spa cover.
Page 69 Spa Cover and Shell Maintenance Spa Cover and Shell Maintenance Spa Cover and Pillows Due to constant punishment your spa cover and pillows receive, you should protect them by applying a vinyl and leather cleaner as part of your monthly maintenance plan. Use a product that is specifically designed to protect spa covers and pillows from chemical and ultraviolet light damage without leaving an oily residue behind that is normally associated with common automotive vinyl protectants.
Page 73 BALBOA WATER GROUP Setting up The CalConnect Wifi Module Setting up The CalConnect Wifi Module BWA APP FOR IOS & ANDROID DEVICES Access Your spa through a direct connection, local wifi, or bwa™ for Android™ bwa™ for iOS® through the cloud to monitor you spa when you are away. This guide will show you how to.
Page 74 INITIAL SETUP BALBOA WATER GROUP BWA APP FOR IOS & ANDROID DEVICES INITIAL SETUP 1. O 2. Pr 1. O 2. P 3. Yo 3. Yo 4. Th 4. Th 5. Te 5. Te 5- Launch the BWA app and select initial set up. 6- Once selected follow the steps presented to you within the app, it will attempt to communicate with the module to establish its first initial connection.
Page 75 BALBOA WATER GROUP BWA APP FOR IOS & ANDROID DEVICES LOCAL CONNECT 9- Once there is confirmation that the app communicates to the spa select the setting icon in the top right corner. 10- Select under settings the “Wifi”option. 11- Enter your home wifi’s network information to begin pairing the spa to the home network.
Page 76 BALBOA WATER GROUP BWA APP FOR IOS & ANDROID DEVICES LOCAL CONNECT (continue) 13- If you have successfully entered your home wifi network information, you will get a prompt to leave the device running for a few minutes. The spas wifi module is now attempting to pair with your home wifi.
Page 77 BALBOA WATER GROUP BWA APP FOR IOS & ANDROID DEVICES CLOUD CONNECT 1. While in LOCAL CONNECT, press the MENU button and then “CLOUD CONNECT” 1- Select the Menu option on the top center of the app. 2. Press “Account Setup” and then “CREATE ACCOUNT” 2- Select Cloud Connect, the app will prompt you to a log in screen.
Page 78 The fastest tool to find replacement parts and accessories Buying replacement filters, parts, or accessories is part of spa ownership, but finding commonly replaced or ordered parts for your spa model is made easy, and just a few clicks away. Using your spa serial number, you may look up and find your exact spa model and find these components.
Page 79 2’’ Cluster Storm Directional Velocity PLUCS2441009S-CDCL 3’’ Mini storm Directional Velocity PLUCS2442009SS-CDCL 3’’ Mini Storm Massage Directional Velocity PLUCS2442059S-CDCL 4’’ Poly Storm Directional Velocity PLUCS2443009SS-CDCL 4’’ Poly Storm Roto Velocity PLUCS2443039SSCDHL 5’’ Power Storm Tri-Directional Velocity PLUCS24444019S-CDCL 5’’ Adjustable Whirlpool Velocity With Valve PLUCS2394009S-CDCL Velocity 2’’...
Page 80 50 SQ FT Ultra Filter FIL50-5D13H15FCT-3 Main Suction Fitting PLU21400203 2’’ Cluster Storm Twin Velocity PLUCS2441029S-CDCL 3’’ Mini Storm Twister Velocity PLUCS2442009SS-CDCL 5’’ Power Storm Directional Velocity PLUCS2441009SS-CDCL 5’’ Power Storm Multi Massage Velocity PLUCS2444059S-CDCL 5’’ Power Storm Twister Velocity PLUCS2444049S-CDCL...
Page 81 ALX WATERFALL CASCADE SUB ASSEMBLY (Rectangle) Off White PLU21800835 1 LED Light String LIT16100330 2 LED Light String LIT16100331 4 LED Light String LIT16100332 1 to 3 LED extension cord LIT16100335 1 to 1 LED Extension cord LIT16100338 Interior Light without Logic LIT16100337 Main Light Housing, LED lens LIT630-7048...
Page 82 Additional Parts 50 Sq Ft Filter Housing Grey Primary Suction Fitting Part#: FIL517-4909LC-HLG Part#:PLU644-5419-HLGV...
Page 83 To obtain service in the event of a defect covered by this Limited Warranty, notify your Cal and materials Spas dealer or Cal Spas as soon as possible and use all reasonable means to protect the spa from further damage. Upon proof of purchase, a designated service representative will correct the defect subject to the terms and conditions contained in this Limited Warranty.
Page 84 Structural This limited warranty covers defects within the spas fiberglass structural shell. This includes sudden spa shell col- lapse, leaking through the shell, and separation between the spa shell and spa acrylic, caused by faulty bonding. This does not include separation due to micro-abrasions, pin holes in the shell, or warping/bubbling due to sun exposure.
Page 85 If a defect is found within the first 90 days of ownership, your Cal Spas dealer and Cal Spas can directly assist the spa owner filing a claim and replacing the spa cover if deemed necessary.
Page 86 The servicing dealer may charge the owner a travel/service fee as well as a diagnose fee if the cause of the issue is unknown, these charges are not covered under warranty. Your spa dealer nor Cal Spas is re- sponsible for damages or costs to rebuild decks, cement structures, or other decor/structures placed against the sides of the spa.
Page 87 Spa owners who have purchased a Cal Spa, and the spas final resting place is not in the United States or Canada, Cal Spas will be able to send components and parts directly to the spa customer if the original Cal Spa dealer is not within range of the spa.
Page 88 Contact Information For customer service or service technicians, please contact your authorized dealer immediately. If you need additional information and/or assistance, contact Lloyd’s Material Supply Company, Inc. Customer Service Department Lloyd’s Material Supply Company, Inc. 1462 East Ninth Street LTR.2023.1000, REV. LTR.2025.1000 Pomona, CA 91766 G-3 10/11/2023...
