- Page 1 Platinum, Escape X, & Deck Spas XL Heater Made in USA “From the Finest Components Around the World”™ Calspas Home Resorts ™ Owners Manual...
- Page 2 Duplication without written consent is strictly prohibited. Lloyd’s Material Supply Company, Inc. strictly prohibited. Cal Spas®,Adjustable Therapy System™, ATS™, Cal Premium™, Cal Select™, Cal Customer Service Department Stone™, XL™ Heater, and Ultimate Fitness Spa Series™, are registered trade- 1462 East Ninth Street marks.
-
Page 3: Table Of Contents
Table of Contents Important Safety Instructions Spa Operations Preparing for Your New Portable Spa ....Electrical Power Efficiency Tips ....Foundation Planning Requirements ....Jets and LED Lighting ......... 240 Volt Electrical Installation ......Diverters, Air Venturis, and Waterfalls ..Removing Shipping Materials ...... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When using and installing this spa, basic safety precautions should always be followed, including. Danger: RISK OF SEVERE INJURY OR DROWNING! • NO DIVING, diving may result in injury or death. •... - Page 5 Warning: REDUCE RISK OF HEAT RELATED INJURY OR DEATH • Prolonged exposure to hot air or water can induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level between 3°F (2°C) to 6°F (4°C) above the normal body temperature of 98.6°F (37°C).
-
Page 6: Preparing For Your New Portable Spa
Preparing for Your New Portable Spa Preparing for Your New Portable Spa Pre-Delivery Checklist � Pre-Delivery Checklist Most cities and counties require permits for Most cities and counties require permits for exterior Before Delivery □ exterior construction and electrical circuits. construction and electrical circuits. -
Page 7: Preparing A Good Foundation
Preparing a Good Foundation Preparing a Good Foundation NOTE: We strongly recommend that a qualified, licensed contractor prepare the foundation for your spa. Note: We strongly recommend that a qualified, licensed contractor prepare the foundation for your spa. Damage caused by inadequate or improper foundation support is not covered by the warranty. It is the Damage caused by inadequate or improper foundation support is not covered in your warranty. -
Page 8: Removing Shipping Materials
Removing Shipping Materials Your Cal Spa is wrapped with a white shrink wrap designed to protect the acrylic shell from scratches and damage. Thoroughly inspect the plastic wrapping for any tears and or damage that may have occurred during shipping. It is expected to see some scuffs or small tears at the base and corners of the spa, as the spa is pushed and shifted around in transport. -
Page 9: Clearance For Service Access
Opening the Front Panel For Electrical Access Cal Spas are designed with innovative snap in panels and corners. In order to access the control box for electrical hook up, plumbing, or pumps inside of your spa, you will need to remove the corner panels and the front panel. - Page 10 Step 2 Once the corner is removed, place aside with great care of not bending or stepping on the protruding clamps behind the corner. Repeat the removal process with the corner panel of the other end of the front of the spa. Step 3 Once both corners are removed, place one hand under the front panel and one hand on either...
- Page 11 Step 5 Once the front panel has been removed, your electrician or contractor may perform the nec- essary electrical work to power the spa. Once the required work is completed, retrieve the panel and align the cabinet mounted plastic clamp with the bottom spa mounted plastic retainer.
-
Page 12: Gfci Wiring Diagram For Usa/Canada
GFCI Wiring Diagram for USA & Canada GFCI Wiring Diagram for USA & Canada IN.YE3 (2 Pump System) 40 Amp Four #6 AWG Copper Wires IN.YE5 (3 Pump System 50 Amp Four #6 AWG Copper Wires IN.YE5 (4 Pump system) 60 Amp Four #6 AWG Copper Wires Refer to this diagram... -
Page 13: Filling And Powering Up The Spa
Filling and Powering Up the Spa Filling and Powering Up the Spa If the spa is equipped with a 75 sqft filter (color may vary), turn the skimmer component counterclockwise to unlock the skimmer. Pull the skimmer directly upward, after removal the retainer ring and basket are easily re- moved. - Page 14 If the spa is equipped with a standard 50 sqft filter (black or gray), the skimmer is held in place with a locking ring during shipping. When preparing to fill your spa remember to remove the locking ring and remove the bobbing skimmer. Remove the filter by gently twisting the canister counter clockwise Equipped on Deck Spas Teleweirfilter skimmer •...
- Page 15 Step 3. Fill the Spa Place the water hose inside the filter canister. Fill your spa with regular tap water about six inches from the top. If the water level is too low or too high, your spa will not operate correctly. NOTE: Never fill with soft water.
- Page 16 Note: Cal Spas are designed to retain heat, if it is desired to lower the water temperature the spa does not contain a cooling feature. To lower internal temperature of the spa, lower the set temperature on the con- trol panel and open the tub during the evening or night to help release the heat captured within.
-
Page 17: Priming The Pump
Priming the Pump Priming the Pump New owners often have difficulty the first time they start their spa and the pumps fail to prime. This can be frustrating but these instructions should help you resolve any issues with air pockets inside of the primary pump or other priming issues. -
Page 18: Xl Heater Operation
The heating element carries a unique 10 year warranty, at any point within 10 years of ownership if a defect were to arise, Cal Spas will offer a replacement heating element. The XL Heater provides superior heating to bring your hot tub experience to the next level. When a spa is equipped with an XL Heater it brings the temperature of the spa water up much faster than traditional spa heaters, allowing more heat to dissipate or absorb into the water inside of the spas heater. - Page 19 This Page is Intentionally Blank.
-
Page 20: Spa Touch 2 Control Panel
Spa Touch 2 Control Panel Spa Touch 2 Control Panel Spa Touch Control System Certain Cal Spa models are offered with an upgraded control panel, the Spa Touch 2 control system. The elegant 4 1�2’’ touch display offers easy navigation of all of your spas equipment, with an elegant color LCD screen. -
Page 21: Main Screen & Legend
Important information can be found on the main screen, such as temperature adjustment, current spa operations, pump activation, lights, and the settings tab. Certain icons or options may not appear on your display, this dependent on the options your spa is equipped with. -
Page 22: Adjusting Temperature & Navigation
This icon indicates that a message is waiting for you to review, it can be an error code or a general message code. After 30 seconds the display will enter sleep mode and power off, you can tap the display to wake up. You can press the up and down arrows once to see what the spas set temperature is, this is shown by the temperature values changing in color to... -
Page 23: Changing Languages
Changing Languages Changing Languages Step 1. Touch the Settings Icon at the lower right portion of the screen. Appuyez sur l’icône Paramètres dans la partie inférieure droite de l’écran. Toque el ícono de Configuración en la parte inferior derecha de la pantalla. Step 2. - Page 24 Once you select the language icon, the screen will open up a list of languages you can select, use the up and down arrows to navigate down the list of available languages. Une fois que vous avez sélectionné l’icône de langue, l’écran ouvrira une liste de langues que vous pouvez sélectionner, utilisez les flèches haut et bas pour parcourir la liste des langues disponibles.
-
Page 25: Priming Mode & Temp Sensors
Priming Mode [Initial Start Up] When your spa is first powered on the unit will enter a mode called priming mode, this also occurs when- ever the power to the unit is cut off from a GFCI trip or a power surge. This modes purpose it to ensure the primary pump is clear of any air pockets or obstructions, and allows your temperature sensors to calibrate and read the water temperature to begin the heating process or to disengage the heater if the spa is already within its desired range. -
Page 26: Pumps, Navigation & Selection
Pump Speed Indicator Fig. 1-01 The spa screen shows all available equipment to control based on your spa options. The icons shown in this screen may vary based on the number of pumps or additional options the spa is equipped/ordered with. Some pumps have more than one speed, indicated by Figure 1-01, some spas have only one dual speed pump, and others can be equipped with one dual speed pump with additional single speed pumps. -
Page 27: Navigation Between Pages
Navigation Between Pages : Certain menus contain more than one page to access all options. Use the navigation arrows as illustrated bellow to move page to page Next Page Previous Page Similarly you will press these arrows to navigate up and down. Line/Page Up Depending on the screen these arrow icons can be used to change... -
Page 28: Dual Temperature Ranges
Dual Temperature Ranges By pressing the icon you will be able to ac- cess and control the heat range and heat mode of your spa. Heat Modes: Your spas heating system activates whenever the temperature falls below the set spa tem- perature, this is called “Ready”... -
Page 29: Adjusting Filtration
Adjusting Filtration Filter Cycles are very important in maintaining water clarity within your spa. Each setting can be adjusted by increments of 15 minutes. Most spa owners are able to maintain water clarity with a total of 3-4 hours of filtration per day. Your spa is able to have two separate filter cycle times based on your spa usage. -
Page 30: Utilities & Fault Log
Utilities The Utilities icon on the settings screen will take you to the Utilities screen. This screen contains several options that can modify the operation of the touch panel, as well as testing tools and the spa fault logs. Panel Selecting the Panel icon allows you to choose the duration of time that the control panel remains activated before entering back into sleep mode. - Page 31 Additional Settings Units The units screen allows you to change the units of the display from either imperial inches or Metric Reminders The reminders Icon takes you to the reminders screen. Choosing to have reminders activated will allow you to get maintenance remind- ers on the display of your spa.
-
Page 32: General Messages & Heater Messages
& Water is too hot - M029 The heater is too hot - M030 The system has detected water temp of 110°F This code occurs when, one of the water temp (43.3°C)or more, spa functions are disabled. The sensors has detected 118°f (47.8°C) in the heater. system will auto reset when the spa water temp is When this happens the spas current operations below 108°F (42.2°C). -
Page 33: Sensor & System Related Messages
Test software installed The control system is operating with test software. Contact your spa dealer for service or to reformat the unit. Sensors are out of sync - M015 When this error code appears, the temperature sensors may be out of sync by 3°F. Call your Settings have been reset - M021 dealer for service, if this message does not disappear within a few minutes. -
Page 34: Reminder Messages
Check the PH Change the filter May appear on a regular schedule, i.e. every 7 May appear on a regular schedule every 365 days. Check pH with a test kit and adjust pH with days. Filters when properly maintained should be the appropriate chemicals. -
Page 53: Electrical Power Efficiency Tips
Electrical Power Efficiency Tips Electrical Power Efficiency Tips Your new spa comes equipped with a premium 5.5kWh titanium electric heater. Follow the directions listed below, it will help ensure the most efficient spa operation. Some models have the option to combine your spa with a Gecko “in-Temp”... -
Page 54: Diverter Knobs
To decrease the amount of airflow through the jets, rotate the handle to the right (clockwise) Waterfall (option) Waterfall (option) Some Cal Spas are equipped with a waterfall feature, with LED lights inside the housing. -
Page 55: Ats Therapy Seat System (Option)
ATS Therapy Seat System ATS Therapy Seat System Pump Button (On/Off): Press the “Pump” button to activate the ATS system. The pump will turn on full speed with letter “H” displayed in the LCD pan- el, the pump LED light will turn on. Press the pump button a second time to tun off the ATS system. -
Page 56: Throttle Seat Vms Massage Seat
Throttle Seat Variable Speed System Throttle Seat Variable Speed System (option) (option) Massage Pump Some spas have the option to install a variable speed pump with its very own control panel, that can be used in a massage therapy seat. This pump has the ability to pulse and activate on an interval to mas- sage the body of the user sitting in a spa seat connected to this variable speed pump. - Page 57 After selecting a massage mode Massage Adjustments within your Cal Spas Throttle Seat, you may fine tune your experience, by adjusting the pumps intensity or adjusting the rhythm of the massage to your preference.
- Page 58 • You can press the flip display button to rotate the display 180 degrees. Flip Display Note: Certain options like “Lights” within this control system, are not intended to function. The throttle seat uses its own independent control system, the primary control system controls filtration, lighting, heating, and all other spa feature.
-
Page 60: Water Clarity
Water Clarity Water Clarity This section is intended for new spa owners who are not familiar with adjusting spa water chem- istry. Everyone’s knowledge with maintaining water quality is different, but there are some general concepts you need to know. Water maintenance is not difficult, however it is something that requires regular attention. -
Page 61: Water Quality Terms And Definitions
Water Quality Terms and Definitions Water Quality Terms and Definitions... -
Page 62: Water Testing Methods
Water Testing Methods Water Testing Methods There are two testing methods to choose from: The reagent test kit is a method which provides a high level of accuracy but is more expensive and Test strips are a convenient testing method more difficult to use if not experienced with this commonly used by spa owners. -
Page 63: Balancing Water Chemistry Levels
Balancing Water Chemistry Levels Balancing Water Chemistry Levels Maintaining spa water chemistry can be tricky, especially since there are many methods of keeping your water clear and clean. Note: We do not recommend a specific brand of chemicals. See a spa dealer for guidance and recommendations on spa chemicals and supplied needed, as water chemistry varies from region to region. -
Page 64: Balancing The Ph
Before you fill your spa, you need to decide which chemical sanitizer you wish to use. Consult your Cal Spas dealer for the right decision with regards to your lifestyle and spa usage. We recommend granulated chlorine or bromine as your sanitizer. Both work well when maintained regularly Note: DO NOT USE Trichlor. - Page 65 Starting & Maintaining Sanitizer Levels After you choose a sanitizer, you will need to establish a baseline and maintain it regularly. Sanitizing your spa with chlorine or bromine is very similar. Each sanitizer has its advantages and disad- vantages. Sanitizer helps neutralize bacteria that can cause illness and other organic matter. Bromine: Creates less odor and skin irritation than chlorine, bromine is less likely to do so.
-
Page 66: Filtration And Cleaning
Shocking the Water In addition to using a chemical sanitizer, you will periodically need to shock the water. Shocking the water helps remove burned-out chemicals, bacteria, and other organic material from your spa’s water and im- proves your sanitizer’s effectiveness. Do not use chlorinating shock, which can damage the spas jets and pump seals. -
Page 67: General Water Care Schedule
General Water Care Schedule General Water Care Schedule Each time you refill the spa Each time you refill the spa Generic Names for Chemicals Generic Names for Chemicals... -
Page 68: Common Water Chemistry Questions
Common Water Chemistry Questions Common Water Chemistry Questions Question : Why is the use of a floater not recommended to sanitize my spa water? Answer: We do not recommend the use of a floater for three reasons: • The floater is unable to control the rate at which the sanitizer is dissolved into the water. When a floater is placed into a spa the sanitizer levels inside the spa can be extremely high. -
Page 69: Do's And Dont's
Question : When I open my spa, I smell chlorine. How to I get rid of the smell? Answer: There are two types of chlorine in your spa. the first is “Free Chlorine” which is chlorine molecules that are available to sanitize your spa. This free chlorine does not have an odor. -
Page 70: Bather Loads
(go to the next higher filtration number) then if wa- ter quality is still not adequate, consult the advice of your Cal Spas dealer for additional chemical or system recommendations. Be sure to give them your bather load information. -
Page 71: Chemical Abuse
Chemical Abuse Chemical Abuse Chemical abuse is defined as negligent/careless use of both recommended spa chemicals, and use of prohibited chemicals. The spa shell is designed to last for many years, but when the shell is exposed to excessive chemicals, or improper chemical application; this can cause reactions on the shell that can cause pitting, cracks, bubbling, and other blemishes on the shell. -
Page 72: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance Removing and Re-seating Pillows You can remove the pillows for clean- ing and maintenance quickly and easily. This method works for all pillow types. Grab the lower edge of the pillow with both hands and firmly pull up, as you do this the pillows inserts will pop out of the holes. -
Page 73: Spa Cover And Locking System Installation
Spa Cover and Locking System Installation Spa Cover and Locking System Installation The spa cover can be considered one of the most important parts of your spa. The spa cover helps retain the heat inside of your spa in all different types of weather. The cover works as a lid on a thermos, when the spa is not in use the cover helps lower the amount of time the spas heater has to run for. - Page 74 Use a screwdriver to finish screwing in the three screws, repeat this process for the remaining Step 4 3 corners. Keep the cover fastened down at all times when not in use, locking hardware may be locked Step 5 with a key (provided in the packaging of the spa cover) The provided key will allow you to Step 6 lock down your spa cover.
-
Page 75: Draining Your Portable Spa
Draining Your Portable Spa Draining Your Portable Spa Your spa should be drained every four to six months for cleaning and maintenance and refilled with fresh tap water. Before you begin turn the power off to the spa at the breaker and remove your filters. Step 1. -
Page 76: Winterizing (Cold Climate Draining)
Winterizing (Cold Climate Draining) Winterizing (Cold Climate Draining) Depending on your region in your country, the temperature could drop below 32F(0°C). If you are one of those regions, we recommend that you always have your spa full of water and running at normal spa tem- peratures between 80°F - 100°F (26.7°C - 37.8°C). -
Page 77: Cleaning Your Spa
Cleaning Your Spa Cleaning Your Spa Spa Cover and Pillows Due to constant punishment your spa cover and pillow receive, you should protect them by applying a vi- nyl and leather cleaner as part of your monthly maintenance plan. Use a product that is designed specific to spa covers and pillows, to protect them from UV ray damage without leaving an oily residue. - Page 78 The fastest tool to find replacement parts and accessories Buying replacement filters, parts, or accessories is part of spa ownership, but finding commonly replaced or ordered parts for your spa model is made easy, and just a few clicks away. Using your spa serial number, you may look up and find your exact spa model and find these components.
-
Page 79: Replacement Parts
Replacement Parts 1 to 3 ext cord LIT16100335 1 to 1 port ext cord LIT16100338 Interior Light with Logic (7 LEDs) LIT16100337 Interior Light without Logic (7 LEDs) LIT16100333 Main Light Housing ( LED Lens, nut fitting, grommet/gasket) LIT630-7048 Filter Cartridge 75 sqft FIL517-4619LC-DSG Filter Cartridge 50 sqft FIL50-%D13H15FCT-3... - Page 80 FIL11700338 5 Inch Jet Insert Power Storm Internal, Roto, HLG Vector X Style, Metal, With O-Ring on Diffuser PLUCS2247049S-HLG 5 inch Jet Insert - (5T) Adjustable Whirlpool Internal, Vector X Style, Metal PLUCS2394029S-HLG Cal Spas Cascade Pillow (Off White) ACC01401103-W...
- Page 81 E/B, Vector X Style, Metal, With O-Ring on Diffuser HLG PLUCS2446009SSHLG 4.5 Inch Jet Insert Poly Storm Internal, Metal Roto E/B - HLG Vector X Style, Metal, With O-Ring on Diffuser PLUCS2446029SSHLG Cal Spas Y- Pillow (Off White) ACC01401102-W...
- Page 82 4.5 inch Jet Insert Poly Storm Internal, Wa- terway Roto E/B - HLG Vector X Style, Metal, With O-Ring on Diffuser PLUCS2446039SHLG 4.5 Inch Jet Insert Poly Storm Internal, Tur- bine, HLG Vector X Style, Metal, With O-Ring on Diffuser PLUCS2446069S-HLG 5 Inch Jet Insert (5D) Power Storm Internal, Metal Directional E/B - HLG ...
- Page 83 1 LED Light String LIT16100330 2 LED Light String LIT16100331 4 LED Light String LIT16100332 Spa Cover Locks and Keys ACC01800026, ACC01800020 Waterfall LED Spillway, 18’’ Large PLU21801039...
- Page 85 P P g g 1 1 2 2...
- Page 88 This Page is Intentionally Blank.
-
Page 89: Limited Warranty
To obtain service in the event of a defect covered by this Limited Warranty, notify your Cal and materials Spas dealer or Cal Spas as soon as possible and use all reasonable means to protect the spa from further damage. Upon proof of purchase, a designated service representative will correct the defect subject to the terms and conditions contained in this Limited Warranty. - Page 90 Structural This limited warranty covers defects within the spas fiberglass structural shell. This includes sudden spa shell col- lapse, leaking through the shell, and separation between the spa shell and spa acrylic, caused by faulty bonding. This does not include separation due to micro-abrasions, pin holes in the shell, or warping/bubbling due to sun exposure.
- Page 91 If a defect is found within the first 90 days of ownership, your Cal Spas dealer and Cal Spas can directly assist the spa owner filing a claim and replacing the spa cover if deemed necessary.
- Page 92 The servicing dealer may charge the owner a travel/service fee as well as a diagnose fee if the cause of the issue is unknown, these charges are not covered under warranty. Your spa dealer nor Cal Spas is re- sponsible for damages or costs to rebuild decks, cement structures, or other decor/structures placed against the sides of the spa.
- Page 93 Warranty limitations This Limited Warranty is void if Cal Spas or its designated representative determines that the spa has been sub- jected to alteration, neglect, misuse or abuse, or freight damage caused by the common carrier; any repairs have been attempted by anyone other than a designated representative; or if the failure is caused by accident, acts of God or other causes beyond the control of the Manufacturer including acts of nature (damage caused by ani- mals, rodents, or other pests) are not covered by this warranty.
- Page 94 Spa owners who have purchased a Cal Spa, and the spas final resting place is not in the United States or Canada, Cal Spas will be able to send components and parts directly to the spa customer if the original Cal Spa dealer is not within range of the spa.
- Page 95 This Page is Intentionally Blank...
- Page 96 Please visit the Cal Spas website for information and accessories to enhance your backyard spa experience. Contact Information For customer service or service technicians, please contact your authorized dealer immediately. If you need additional information and/or assistance, contact Lloyd’s Material Supply Company, Inc.
