Mitsubishi Electric A1SJ71AP23Q-U-HW User Manual

Local station data link module

Hide thumbs

Table Of Contents

Quick Links

Download this manual

MELSECNET, MELSECNET/B

Local Station Data Link

A1SJ71AP23Q, A1SJ71AR23Q

Thank you for purchasing the Mitsubishi programmable controller

MELSEC-A series.

Prior to use, please read this and relevant manuals thorougly to fully

understand the product.

User's Manual

A1SJ71AT23BQ

MODEL A1SJ71AP23Q-U-HW

MODEL

CODE

IB(NA)-0800372-B(0710)MEE

Module

(Hardware)

13JY19

Table of Contents

Need help?

Do you have a question about the A1SJ71AP23Q-U-HW and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Electric A1SJ71AP23Q-U-HW

Page 1 (Hardware) A1SJ71AP23Q, A1SJ71AR23Q A1SJ71AT23BQ Thank you for purchasing the Mitsubishi programmable controller MELSEC-A series. Prior to use, please read this and relevant manuals thorougly to fully understand the product. MODEL A1SJ71AP23Q-U-HW MODEL 13JY19 CODE IB(NA)-0800372-B(0710)MEE © 2007 MITSUBISHI ELECTRIC CORPORATION...
Page 2: Safety Precautions
SAFETY PRECAUTIONS (Always read these instructions before using this product) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable controller system, please read the User's Manual for the CPU module used.
Page 3 [DESIGN PRECAUTIONS] DANGER To control a running programmable controller (data modification) by connecting GX Developer to a CPU module or connecting a personal computer to an intelligent function module (special function module), create an interlock circuit on the sequence program so that the entire system will function safely all the time.
Page 4 [WIRING PRECAUTIONS] DANGER Be sure to shut off all phases of the external power supply before installation or wiring. Failure to do so may result in an electric shock or damage to the product. CAUTION Properly solder a connector for coaxial cable. Failure to do so may cause malfunction.
Page 5 [START-UP AND MAINTENANCE PRECAUTIONS] CAUTION Do not disassemble or remodel each of the modules. Doing so may cause failure, malfunctions, personal injuries and/or a fire. When using a wireless communication device such as a mobile phone, keep a distance of 25cm (9.84inch) or more from the programmable controller in all directions.
Page 6 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
Page 7: Table Of Contents
CONTENTS 1. OVERVIEW..................... 1 2. PERFORMANCE SPECIFICATIONS ............. 2 3. HANDLING ..................... 7 3.1 Handling Precautions ................7 4. PART NAMES AND SETTINGS ..............8 5. WIRING......................11 5.1 Optical Fiber Cable................. 12 5.2 Coaxial Cable ..................13 5.3 Shielded Twisted Pair Cable ..............16 6.
Page 8: About Manuals
A/QnA to Q conversion support tool (Version 1.02 or later) This is a tool to support the creation of a program for link data refresh and program for receiving the LRDP/LWTP instruction. It can be downloaded from the MITSUBISHI ELECTRIC FA NETWORK SERVICE website free. (http://www.MitsubishiElectric.co.jp/melfansweb)
Page 9: Overview
1. OVERVIEW This manual describes the specifications and part names of the data link module shown below used in the MELSECNET or MELSECNET/B data link system (hereinafter referred to as a local module). • A1SJ71AP23Q type MELSECNET local station data link module •...
Page 10: Performance Specifications
2. PERFORMANCE SPECIFICATIONS This chapter describes the performance specifications of the MELSECNET or MELSECNET/B data link system and the local module. For the general specifications, refer to the QCPU User's Manual (Hardware Design, Maintenance and Inspection). (1) Performance specifications of MELSECNET data link system and A1SJ71AP23Q Table 2.1 Performance specifications of MELSECNET data link system and A1SJ71AP23Q Specifications...
Page 11 0.33A (5VDC) Weight 0.30kg Connecting an optical fiber cable with a connector requires professional skills and special tools. Also, a connector dedicated to an optical fiber cable is required. For purchase, contact your local Mitsubishi Electric System Service or representative.
Page 12 (2) Performance specifications of MELSECNET data link system and A1SJ71AR23Q Table 2.2 Performance specifications of MELSECNET data link system and A1SJ71AR23Q Specifications MELSECNET data link system Item MELSECNET MELSECNET II MELSECNET II mode mode composite mode Maximum Up to the maximum number of I/O points for the CPU module Input (X) applicable link used in the master station is applicable.
Page 13 (3) Performance specifications of MELSECNET/B data link system and A1SJ71AT23BQ Table 2.3 Performance specifications of MELSECNET/B data link system and A1SJ71AT23BQ Specifications MELSECNET/B data link system Item MELSECNET MELSECNET II MELSECNET II mode mode composite mode Maximum Up to the maximum number of I/O points for the CPU module Input (X) applicable link used in the master station is applicable.
Page 14 Remarks Overall cable distance (1) MELSECNET data link system The overall cable distance refers to a distance from OUT of the master station to IN of the master station via a slave station. Overall cable distance of MELSECNET MELSECNET Figure 2.1 Overall cable distance of MELSECNET (2) MELSECNET/B data link system The overall cable distance refers to a distance between stations at both ends.
Page 15: Handling
3. HANDLING [INSTALLATION PRECAUTIONS] CAUTION Use the programmable controller in the environment conditions given in the general specifications of the User's Manual for the CPU module used. Failure to do so may cause an electric shock, fire, malfunction, or damage to or deterioration of the product.
Page 16: Part Names And Settings
4. PART NAMES AND SETTINGS This chapter describes the part names and settings of the local module. Figure 4.1 Outside drawing of local module Table 4.1 Part names and settings Name Description Name Status Description Data link normal Data sending Data receiving Forward loop side receives data (OFF: F.LOOP...
Page 17 Table 4.1 Part names and settings(Continued) Name Description LED (Continued) TIME Data link monitoring time is over. DATA The data of error code has been received. UNDER ON (OFF Internal processing of send data is not if normal) executed constantly. UND.
Page 18 Table 4.1 Part names and settings(Continued) Name Description Communication Sets communication speed. speed setting switch Communication speed (A1SJ71AT23BQ) 125kbps 250kbps 500kbps 1Mbps Unusable (If set, the local module goes into offline 4 to F status (X0=ON).) Connector Connects an optical fiber cable. (A1SJ71AP23Q) Reverse loop send Foward loop receive...
Page 19: Wiring
5. WIRING DANGER Be sure to shut off all phases of the external power supply before installation or wiring. Failure to do so may result in an electric shock or damage to the product. CAUTION Properly solder a connector for coaxial cable. Failure to do so may cause malfunction.
Page 20: Optical Fiber Cable
5.1 Optical Fiber Cable This section describes how to connect an optical fiber cable with the local module. (1) Precautions for wiring (a) Securing of wiring space When an optical fiber cable is connected with the local module, a cable bend radius is restricted. For details, check the specifications of the cable to be used.
Page 21: Coaxial Cable
5.2 Coaxial Cable This section describes how to connect a coaxial cable with the local module. (1) Precautions for wiring (a) Securing of wiring space When a coaxial cable is connected with the local module, a cable bend radius is restricted. Local module Figure 5.2 Allowable bend radius of coaxial cable...
Page 22 (3) Connection of cable for coaxial cable The following shows how to connect a BNC connector (connector plug for coaxial cable) and a cable. (a) Components of BNC connector and coaxial cable Components of coaxial cable Components of BNC connector External conductor External sheath Insulator...
Page 23 4) Solder a contact to the internal conductor. Solderd 5) Insert a contact assembly in 4) to a plug shell and screw a nut into the plug shell. POINT When soldering an internal conductor and a contact, pay attention to the following points.
Page 24: Shielded Twisted Pair Cable
5.3 Shielded Twisted Pair Cable This section describes how to connect a shielded twisted pair cable with the local module. (1) Precautions for wiring (a) Laying shielded twisted pair cable When laying a shielded twisted pair cable, pay attention to the following points so that it will not be affected by noise or surge induction.
Page 25: External Dimensions
6. EXTERNAL DIMENSIONS 6.1 A1SJ71AP23Q Printed-circuit board 93.6 34.5 (0.26) (3.69) (1.36) Unit: mm (inch) Figure 6.1 A1SJ71AP23Q For details, contact your local Mitsubishi Electric System Service or representative.
Page 26: A1Sj71Ar23Q
6.2 A1SJ71AR23Q Printed-circuit board 34.5 93.6 (0.26) (3.69) (1.36) Unit: mm (inch) Figure 6.2 A1SJ71AR23Q...
Page 27: A1Sj71At23Bq
6.3 A1SJ71AT23BQ Printed-circuit board 71.6 (2.82) 34.5 (0.55) (1.36) 93.6 (0.26) (3.69) Unit: mm (inch) Figure 6.3 A1SJ71AT23BQ...
Page 28: Warranty
