- Page 1 EN User Manual | Cooker LKG604002X LKG604002W...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 • Only a qualified person must install this appliance and replace the cable. • This appliance is intended for use up to an altitude of 2000 m above sea level. • This appliance is not intended to be used on ships, boats or vessels.
-
Page 5: Safety Instructions
• WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. -
Page 6: Gas Connection
• The shock protection of live and insulated CAUTION! parts must be fastened in such a way that it cannot be removed without tools. The use of a gas cooking appliance • Connect the mains plug to the mains results in the production of heat, moisture socket only at the end of the installation. -
Page 7: Care And Cleaning
2.5 Care and Cleaning • Open the appliance door carefully. The use of ingredients with alcohol can cause a mixture of alcohol and air. WARNING! WARNING! Risk of injury, fire, or damage to the appliance. Risk of damage to the appliance. •... -
Page 8: Internal Lighting
2.7 Internal lighting • Use original spare parts only. 2.9 Disposal WARNING! Risk of electric shock. WARNING! • Concerning the lamp(s) inside this product Risk of injury or suffocation. and spare part lamps sold separately: • Contact your municipal authority for These lamps are intended to withstand information on how to dispose of the extreme physical conditions in household... - Page 9 3.2 Technical data Dimension Voltage 220 - 240 V Height Frequency 50 - 60 Hz Width Appliance class Depth 3.3 Other technical data Appliance category: II2H3B/P Gas original: G20 (2H) 20 mbar Gas replacement: G30/G31 (3B/P) 30/30 mbar 3.4 Bypass diameters BURNER Ø...
- Page 10 3.7 Gas burners for LPG G31 30 mbar BURNER NORMAL REDUCED POWER INJECTOR NOMINAL GAS POWER kW MARK 1/100 FLOW g/h Rapid 0.63 Semi-rapid 0.38 Auxiliary 0.85 0.31 Oven 0.78 3.8 Gas connection In installation always use the pipe holder and the gasket.
- Page 11 WARNING! Before you replace the injectors, make sure that the gas knobs are in the Off position. Disconnect the appliance from the electrical supply. Let the appliance cool down. There is a risk of injury. The appliance is set to default gas. To change the setting always use the gasket sealing.
- Page 12 Changing from liquid gas to natural 1. Unscrew approximately one turn the bypass screw position A. 2. Put the knob for the hob back. 3. Connect the appliance to the electricity. WARNING! Put the mains plug into the mains socket only if all parts are back into their initial position.
-
Page 13: Anti-Tilt Protection
dismount the control panel before 9. Set the maximum gas flow position on the adjustment start. knob for the oven functions and let the 3. With a thin and flat screwdriver adjust the oven heat for at least 10 minutes. bypass screw A. -
Page 14: Electrical Installation
CAUTION! If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to the centre of the appliance. 3.16 Electrical installation WARNING! 1. Install the anti-tilt protection 232 - 237 The manufacturer is not responsible if mm down from the top surface of the you do not follow the safety precautions... -
Page 15: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Button for the spark generator Knobs for the hob Knob for the Minute Minder Grill indicator Knob for the oven functions Button for the lamp Heating element Lamp Turnspit hole Shelf support, removable Shelf positions 4.2 Cooking surface layout Auxiliary burner Steam outlet - number and position... -
Page 16: Before First Use
5. BEFORE FIRST USE 1. Set the maximum temperature. WARNING! 2. Let the appliance operate for approximately 20 minutes. Refer to Safety chapters. 3. Set the function and the maximum 5.1 Initial Cleaning temperature. The maximum temperature for this function is 210 °C. Remove all accessories and removable shelf 4. -
Page 17: Turning The Burner Off
A. Burner cap B. Burner crown C. Ignition candle In the absence of electricity you can D. Thermocouple ignite the burner without an electrical device. In this case approach the burner 6.3 Turning the burner off with a flame, push the relevant knob down and turn it to maximum position. -
Page 18: Hob - Care And Cleaning
7.2 Diameters of cookware WARNING! Do not put unstable or damaged pots on WARNING! the burner to prevent spills and injuries. Use cookware with diameters applicable to the size of burners. CAUTION! Make sure that pot handles are not Burner Diameter of cook‐... -
Page 19: Pan Supports
difficult lighting and check that the burner 2. The enamel coating occasionally can crown holes are not obstructed. have rough edges, so be careful when you wash the pan supports by hand and 8.4 Pan supports dry them. If necessary, remove stubborn stains with a paste cleaner. - Page 20 Oven safety device: Do not keep the knob for the oven The gas oven has a thermocouple. It functions pushed for more than 15 stops the gas flow if the flame goes out. seconds. If the oven burner does not light after 15 seconds, release the knob for 1.
-
Page 21: Oven - Clock Functions
melted butter to keep them moist during • You should turn over the food during cooking. cooking, as you require. • You may place accompaniments such as To deactivate this function, turn the knob to tomatoes and mushrooms underneath the the off position. - Page 22 11.2 Using the turnspit 5. Install the first fork on the spit, then put the meat on the turnspit and install the second fork. Make sure that the meat is in WARNING! the middle of the spit. Be careful when you use the turnspit. The forks and the spit are sharp.
-
Page 23: Oven - Hints And Tips
12. OVEN - HINTS AND TIPS You can extend the baking time by 10 – 15 WARNING! minutes if you bake cakes on more than one shelf position. Refer to Safety chapters. Trays in the oven can distort during baking. When the trays are cold again, the distortions disappear. - Page 24 Food Pre‐ Thermo‐ Grilling Total cook‐ Shelf Accessories heating stat po‐ time ing time posi‐ time sition (min) at (min) tion (min) the end Burgers Grill - on wire shelf and tray on level 70 - 80 Toast Grill - on 3 - 4 wire shelf Turn over after 40 min.
-
Page 25: Oven - Care And Cleaning
13. OVEN - CARE AND CLEANING WARNING! Refer to Safety chapters. 13.1 Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild cleaning agent. To clean metal surfaces, use a dedicated cleaning agent. -
Page 26: Cleaning The Oven Door
13.5 Cleaning the oven door The oven door has two glass panels. You can remove the oven door and the internal glass panel to clean it. The oven door may close if you try to remove the internal glass panel before you remove the oven door. -
Page 27: Replacing The Lamp
The drawer below the oven can be removed for cleaning. 1. Pull the drawer out until it stops. 8. Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher. -
Page 28: Service Data
14.1 What to do if... Problem Possible cause Remedy There is no spark when you try to The hob is not connected to an elec‐ Check if the hob is correctly connec‐ activate the spark generator. trical supply or it is connected incor‐ ted to the electrical supply. -
Page 29: Energy Efficiency
......... Product number (PNC) ......... Serial number (S.N.) ......... 15. ENERGY EFFICIENCY 15.1 Product Information according to EU Ecodesign Regulations for hob Model identification LKG604002X LKG604002W Type of hob Hob inside Freestanding Cooker Number of gas burners Energy efficiency Left rear - Auxiliary... -
Page 30: Oven - Energy Saving
5.67 MJ/cycle Number of cavities Heat source Volume 59 l Type of oven Oven inside Freestanding Cooker LKG604002X 42.0 kg Mass LKG604002W 42.0 kg EN 15181 Measuring method of the energy consumption of gas fired ovens. 15.4 Oven - Energy saving... - Page 32 867365958-C-222023...
