Star Lake AV600-RH-AB User Manual

Military ip65 gpu computer intel 13th raptor lake-h i7-13800hre processor, nvidia mxm a2000 gpu
Hide thumbs

Advertisement

Quick Links

Download this manual
AV600-RH-AB
Military IP65 GPU Computer
th
Intel 13
Raptor Lake-H i7-13800HRE Processor,
Nvidia MXM A2000 GPU
User's Manual
Revision Date: Mar.13 2025

Advertisement

loading
Need help?

Need help?

Do you have a question about the AV600-RH-AB and is the answer not in the manual?

Questions and answers

Related Manuals for Star Lake AV600-RH-AB

Summary of Contents for Star Lake AV600-RH-AB

  • Page 1 AV600-RH-AB Military IP65 GPU Computer Intel 13 Raptor Lake-H i7-13800HRE Processor, Nvidia MXM A2000 GPU User’s Manual Revision Date: Mar.13 2025...
  • Page 2 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
  • Page 3 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Revision History Packing list   If any of the above items is damaged or missing, please contact your local distributor.
  • Page 4 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Index 1: P ....................5 HAPTER RODUCT NTRODUCTION ............................. 5 ............................6 ............................. 7 2: J ............... 8 HAPTER UMPERS AND ONNECTORS OCATIONS ......................8 3: BIOS SETUP ITEM ....................10 HAPTER ............................
  • Page 5 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 .............................. 29 ............................ 30 ............................30 ..............................32...

  • Page 6: Product Introduction

    AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 1: P HAPTER RODUCT NTRODUCTION *All specifications and photos are subject to change without notice.
  • Page 7 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025...
  • Page 8 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025...

  • Page 9: Jumpers And Connectors Locations

    AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 2: J HAPTER UMPERS AND ONNECTORS OCATIONS...
  • Page 10 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025...

  • Page 11: Chapter 3: Bios Setup Items

    AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 3: BIOS SETUP ITEM HAPTER The following section describes the BIOS setup program. The BIOS setup program can be used to view and change the BIOS settings for the module. Only experienced users should change the default BIOS setting.
  • Page 12 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Use this menu for basic system configurations, such as time, date etc. Feature Description Options Detailed System Information The date format is <Day>, <Month> <Date> <Year>. Use System Date [＋] or [－] to configure system Date.
  • Page 13 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 CPU Configuration Parameters. Feature Description Options Number of P-cores to enable in each processor Active Performance- package. Note: Number of Cores and E-cores are ★All, 5, 4, 3, 2, 1 cores looked at together. When both are {0,0}, Pcode will...
  • Page 14 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 minimum speed when all cores enter C-State. Disable, C1 ,C3 , ★C1 C-State Auto Configure C-State Auto Demotion Demotion and C3 Disable, C1 ,C3 , ★C1 C-State Un-demotion Configure C-State Un-demotion and C3 Package C State ★Disabled, Enabled...
  • Page 15 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Configuration Graphics Settings. Feature Description Options Select which of IGFX/PEG/PCI Graphics ★Auto, IGFX, PEG, PCI Primary Display device should be Primary Display Or select SG for Switchable Gfx. Keep IGFX enable based on the setup ★Auto, Disable, Enable...
  • Page 16 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 PANEL 1 Configuration. Feature Description Options ★VESA and JEIDA 18 bpp, VESA Color depth and Select Color depth and data format data format 24 bpp, JEIDA 24 bpp ★Single Channel, Dual Channel...
  • Page 17 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 System Power Control Configuration Parameters. Feature Description Options Enables or Disables System ability to Hibernate Disabled, ★Enabled Enable Hibernation (OS/S4 Sleep State). This option may be not effective with some operating system...
  • Page 18 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 PCI Express Root Port Settings. Feature Description Options COMe PEG Port Disabled, ★Enabled Control the PCI Express Root Port. 0,8, 12 Set the ASPM Level: Force L0s – Force all links to L0s State ★Disabled, L0s, L1,...
  • Page 19 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Configuration On Board LAN Device. Feature Description Options ★Enabled , Onboard LAN Enable/Disable onboard NIC Disabled Controller #1 ★Enabled , PCIE_WAKE Control PCIE wake# pin for Wake On Lan function Disabled (Wake on LAN) ★Disabled,...
  • Page 20 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 SATA/NVMe Device Options Settings. Feature Description Options SATA And RST Configuration SATA Device Options Settings NVMe Configuration NVMe Device Options Settings Feature Description Options SATA ★Enabled , Disabled Enable/Disable the SATA Device.
  • Page 21 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 ★Disabled, Enabled Hot Plug Designates this port as Hot Pluggable ★Hard Disk Drive,Solid SATA Device Identify the SATA port is connected to Solid Type State Drive or Hard Disk Drive State Drive USB Configuration Parameters.
  • Page 22 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Trust Computing Settings. Feature Description Options Enables or Disables BIOS support for security Security Device device. O.S. will not show Security Device. TCG Disabled, ★Enabled Support EFI protocol and INT1A Interface will not be available.
  • Page 23 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 System Super IO Chip Parameters. Feature Description Options ★Disabled, Watch Dog Timer Enable/Disable Watch Dog Timer Enabled Watch Dog Timer [Enable] ★Second, Minute Timer Unit Select Timer count unit of WDT ★20...
  • Page 24 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Set Parameters of Serial Port 2. Feature Description Options ★Enabled, Disabled Serial Port 2 Enable or Disable Serial Port (COM) Monitor hardware status. Feature Description Options ★Disabled, Module Fan Enable/Disable the smart fan control...
  • Page 25 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Module Fan Full In Thermal Cruise Mode: Full Speed Temperature ★60 Target Temp Module Fan Low In Thermal Cruise Mode: Low end of fan speed ★5 (0~100%) ★Disabled, Carrier Fan Enable/Disable the smart fan control...
  • Page 26 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Feature Description Options Emulation: ANSI: Extended ASCII char set. VT100: ASCII VT100,★VT100 Terminal char set. VT100+: Extends VT100 to support color , function Plus, VT-UTF8, keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode...
  • Page 27 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 ★Disabled, Resolution Enables or disables extended terminal resolution Enabled 100x31 ★VT100, LINUX,XTERMR Putty KeyPad Select FunctionKey and KeyPad on Putty SCO,ESCN,VT4 EC Firmware Update. Feature Description Options Select File Select ROM image...
  • Page 28 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Feature Description Options [Setup] check password when enter setup screen. ★Setup, Password Check Mode [Power on] check password on every time system Power on power on. Administrator Password Set Administrator Password...
  • Page 29 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Feature Description Options Number of seconds to wait for setup activation ★1 Setup Prompt Timeout key. 65535(0xFFFF) means indefinite waiting. ★On, Off Bootup NumLock State Select the keyboard NumLock state ★Disabled CSM Support Enable/Disable CSM support ★Disabled,...
  • Page 30 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Feature Description Options Save Changes and Reset the system after saving the changes. Reset Discard Changes and Reset system setup without saving any changes. Reset Restore Defaults Restore/Load Default values for all the setup options.
  • Page 31 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 PCOM-B658VGL only support BIOS/EC update under UEFI shell environment, refer the following step, please. Step 1. Unzip update file to the USB DOK (USB DOK must be FAT or FAT32 format) Step 2. Make sure “Boot mode select” item is “UEFI” in the BIOS “Boot” page Shown as below picture.
  • Page 32 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Step 5. Then change the folder with updated file and use command: “ update “ and press enter Step 6. The updating process will start and show the updating progress Step 7. Please power off and restart the system once updating finished...
  • Page 33 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Step 1. Unzip EC binary file to the USB DOK (USB DOK must be FAT or FAT32 format) Step 2. Select “EC Firmware Update” item in BIOS setup menu Step 3. Select EC binary file by option item shown as below...
  • Page 34 AV600-RH-AB User’s Manual Revision Date: Mar. 13. 2025 Step 4. Select “Yes” to start EC update (Please don’t turn off power during firmware update) Step 5. Turn off power to make system into G3 status once updating finished, then power on the...
