- Page 1 CPT330B Rugged IOT Edge Computer with Intel® Core™i7-9700TE User’s Manual Revision Date: April. 15. 2020...
-
Page 2: Safety Information
CPT330B User’s Manual Revision Date: April. 15. 2020 Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
Date (yyyy/mm/dd) Changes V1.0 2020/04/15 First release Packing list Item Description Q’ty CPT330B Embedded System Driver CD 3-pin Terminal Block Power Connector (For DC Power Input) If any of the above items is damaged or missing, please contact your local distributor. -
Page 4: Table Of Contents
CPT330B User’s Manual Revision Date: April. 15. 2020 Table Contents SAFETY INFORMATION ..............................1 ................................1 LECTRICAL SAFETY ................................1 PERATION SAFETY ..................................1 TATEMENT REVISION HISTORY ..............................2 PACKING LIST ................................2 TABLE CONTENTS ..............................3 CHAPTER 1: PRODUCT INTRODUCTION ........................4 1.1 K... -
Page 5: Chapter 1: Product Introduction
CPT330B User’s Manual Revision Date: April. 15. 2020 Chapter 1: Product Introduction 1.1 Key Features System CPU Type Gen Intel® Coffee Lake Xeon-E / Core-i LGA1151 Socket Processor TDP Max. 80W Chipset Intel® C246 Memory Type DDR4 2666MHz, 2 x 260-pin SO-DIMM, Max. 32GB... -
Page 6: Front Panel I/O Placement
CPT330B User’s Manual Revision Date: April. 15. 2020 1.2 Front Panel I/O Placement Power Button w/LED USB 3.0 x 2 HDMI x 1 2.5" HDD/ SSD tray x 1 1.3 Rear Panel I/O Placement... - Page 7 CPT330B User’s Manual Revision Date: April. 15. 2020 COM x 2 USB 3.1 x 4 USB 2.0 x 2 DP x 1 DVI-I x 1 LAN x 2 PS/2 x 1 Audio Jack (Mic-in, Line-out) PCIex16 Expansion Slot x 1...
-
Page 8: Mechanical Dimensions
CPT330B User’s Manual Revision Date: April. 15. 2020 1.4 Mechanical Dimensions... -
Page 9: Chapter 2: Jumpers And Connectors
CPT330B User’s Manual Revision Date: April. 15. 2020 Chapter 2: Jumpers and Connectors 2.1 Jumper Setting Power Supply Mode Signal ATX mode AT mode Down COM Mode Switch setting Mode 1-2 COM 1 Mode Switch setting 3-4 COM 2 2.2 Internal Connector Pin Definition... -
Page 10: Sata Power Header
CPT330B User’s Manual Revision Date: April. 15. 2020 +12V +12V +12V SATAHDR_TXP0_C SATAHDR_TXN0_C SATAHDR_RXN0_C SATAHDR_RXP0_C SATA Power Header Signal Name VCC3 +12V +12V SATA Signal Header Signal Name Description Ground SATAHDR_TXP_C SATA DATA Transmit(positive) -
Page 11: Fan Header
CPT330B User’s Manual Revision Date: April. 15. 2020 SATAHDR_TXN_C SATA DATA Transmit(negative) Ground SATAHDR_RXN_C SATA DATA Receive(negative) SATAHDR_RXP_C SATA DATA Receive(positive) Ground Fan Header Signal Ground +12V CPU_FAN_TACH CPU_FAN_CTRL 2.3 External Connector Pin Definition 3-pin terminal block for DC Input... -
Page 12: 2-Pin Terminal Block For Remote Power On/Off And Reset
CPT330B User’s Manual Revision Date: April. 15. 2020 Signal Ground +12V System_FAN_TACH SYSTEM_FAN_CTRL 2-pin Terminal Block for Remote Power ON/OFF and Reset Signal Ground EXT Reset Ground EXT_PWRBT_ON/OFF COM Pin definition... -
Page 13: Chapter 3: Ami Bios Utility
CPT330B User’s Manual Revision Date: April. 15. 2020 Chapter 3: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 3.1 Starting To enter the setup screens, perform the following steps: ... -
Page 14: Main Page
CPT330B User’s Manual Revision Date: April. 15. 2020 3.3 Main Page The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. System Date Use this function to change the system date. Select System Date using the Up and Down <Arrow> keys. Enter the new values through the keyboard. -
Page 15: Advanced Page
CPT330B User’s Manual Revision Date: April. 15. 2020 3.4 Advanced Page The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. -
Page 16: Onboard Device
CPT330B User’s Manual Revision Date: April. 15. 2020 3.4.1 Onboard Device ► Onboard Devices Value Onboard Device Configuration Enable/Disable processor Turbo Mode (requires Intel Disabled / *Enabled+ Speed Step or Intel Speed Shift to be available and Turbo Mode enabled). -
Page 17: Cpu Configuration
CPT330B User’s Manual Revision Date: April. 15. 2020 Enabled = HAD will be unconditionally enabled. 3.4.2 CPU Configuration ► CPU Configuration Value CPU Configuration Parameters CPU Configuration Type Intel® xxxx® xxxxxx xxxxxxx 0xXXXX Speed XXXX MHz L1 Data Cache EX. 32KB x 2 L1 Instruction Cache EX. -
Page 18: Trusted Computing
CPT330B User’s Manual Revision Date: April. 15. 2020 3.4.3 Trusted Computing ► Trusted Computing Value Trusted Computing Settings TPM20 Device Found Firmware Version: Vendor: xxxxxx Enables or Disables BIOS support for security device. O.S. will not show Security Device Support *Disabled+ / Enabled Security Device. -
Page 19: Watchdog
CPT330B User’s Manual Revision Date: April. 15. 2020 3.4.4 WatchDog ► WatchDog Value WatchDog Configuration WatchDog *Disabled+ / Enabled Enables or Ddisables WatchDog function. 3.4.5 Super IO Configuration... - Page 20 CPT330B User’s Manual Revision Date: April. 15. 2020 ► Super IO Configuration Value System Super IO Chip Parameters. Super IO Configuration Super IO Chip NCT6116D ► Serial Port 1 Configuration Value Set Parameters of Serial Port 1 (COMA) Serial Port 1 Configuration...
-
Page 21: Nct6116D Hw Monitor
CPT330B User’s Manual Revision Date: April. 15. 2020 Serial Port 2 Configuration Serial Port Enable or Disable Serial Port (COM) Disabled / [Enabled] Device Settings IO=2E8h; IRQ=4 Change settings Select an optimal settings for Super [Auto] / IO=2E8h; IRQ=7 IO Device / IO=3E8h;... -
Page 22: S5 Rtc Wake Setting
CPT330B User’s Manual Revision Date: April. 15. 2020 voltage, temperature, and fan status. If these values are out of range, BIOS display warning message and turn on beep sound. xx ℃ CPU Temperature xx ℃ CPU VR Temperature DIMM Temperature xx ℃... - Page 23 CPT330B User’s Manual Revision Date: April. 15. 2020 using RTC alarm Wake System with Fixed Time *Disabled+ / Fixed Time / Enable or disable System wake on from S5 Dynamic Time alarm event. Select FixedTime, system will wake on the hr::min::sec specified.
- Page 24 CPT330B User’s Manual Revision Date: April. 15. 2020 3.4.9 NVMe Configuration...
-
Page 25: Security Page
CPT330B User’s Manual Revision Date: April. 15. 2020 3.5 Security Page Security Value Description Password Description Administrator Password xxxx Set Administrator Password User Password xxxx Set User Password ► HDD Security drive(EX: HDD Security Configuration for selected drive xxxxxxxxxxxxx) ► Secure Boot Secure Boot configuration ►... - Page 26 CPT330B User’s Manual Revision Date: April. 15. 2020...
- Page 27 CPT330B User’s Manual Revision Date: April. 15. 2020 ► Secure Boot Value Secure Boot configuration System Mode xxxx Secure Boot *Disabled+ / Enabled Secure Boot feature is Active if Secure Boot is Enable, Platform Key(PK) is enrolled and the System is in User mode.
- Page 28 CPT330B User’s Manual Revision Date: April. 15. 2020 mode ► Restore Factory Keys *Yes+ / No Force System to User Mode. Install factory default Secure Boot key database ► Reset To Setup Mode *Yes+ / No Delete all Secure Boot key databases from NVRAM ►...
-
Page 29: Bios Update
CPT330B User’s Manual Revision Date: April. 15. 2020 Update / Append / file: Delete 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External,Mixed ► Authorized TimeStamps *Details+ / Export /... -
Page 30: Boot Page
CPT330B User’s Manual Revision Date: April. 15. 2020 3.6 Boot Page... - Page 31 CPT330B User’s Manual Revision Date: April. 15. 2020 Boot Value Description Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock State On / *Off+ Select the keyboard NumLock state FIXED BOOT ORDER...
-
Page 32: Save & Exit Page
CPT330B User’s Manual Revision Date: April. 15. 2020 Disk / Network / Disable Boot Optoin #5 USB Floppy / CD/DVD / USB CD/DVD Sets the system boot orfer / Hard Disk / *USB Key+ / USB Hard Disk / Network / Disable...
