REF 2 157 5
1 Person
30 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
*
Algunos componentes se suministran montados.
Some components are supplied assembled.
KAWASAKI KLR650 '22-
U
N
T
I
N
G
OIL CARTE R G UAR D - PR OT E C T O R DE C ÁR TE R
DESCRIPCIÓN
Protector de aluminio
Amortiguador antivibratorio
silentblock Ø30x25 ( M8x15, int M8x8)
Amortiguador antivibratorio
silentblock Ø25x30 ( M6X18, int M6x6)
Casquillo Ø14 x Ø8,5 x 10mm
Tornillo Allen M6 x30 DIN7991
Tornillo Allen M6 x8 DIN7991
Tornillo Allen M8 x10 DIN7991
www.puig.tv
www.puigusa.com
I
N
S
T
R
DESCRIPTION
Aluminum protection plate
Amortiguador antivibratorio
silentblock Ø30x25 ( M8x15, int M8x8)
Amortiguador antivibratorio
silentblock Ø25x30 ( M6X18, int M6x6)
Ø14 x Ø8,5 x 10mm Arrowhead
M6 x30 DIN7991 Allen screw
M6 x8 DIN7991 Allen screw
M8 x10 DIN7991 Allen screw
Pg. 1/2
info@puigusa.com
U
C
T
I
O
N
QTY
1
2
2
2
2
2
2
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
Nº 10
ALLEN
Nº24
Nº26
REF
SOPOR1P3--21575
SILENTBLOCK-540
SILENTBLOCK-533
CASQUI------576
TORNIAD7991-062
TORNI-D7991-918
TORNI-D7991-922
V0.05/24
Advertisement
Related Manuals for PUIG 21575
Summary of Contents for PUIG 21575
- Page 1 ALLEN EASY Nº24 Nº26 PIEZA/PART DESCRIPCIÓN DESCRIPTION Protector de aluminio Aluminum protection plate SOPOR1P3--21575 Amortiguador antivibratorio Amortiguador antivibratorio SILENTBLOCK-540 silentblock Ø30x25 ( M8x15, int M8x8) silentblock Ø30x25 ( M8x15, int M8x8) Amortiguador antivibratorio Amortiguador antivibratorio SILENTBLOCK-533 silentblock Ø25x30 ( M6X18, int M6x6) silentblock Ø25x30 ( M6X18, int M6x6)
